JVC KS-AX3300 Service Manual

3-4
Electrical parts list
AMP board
Block No. [0][1]
 Symbol No. Part No. Part Name Description Local
IC301 NJM4565M IC AC08-086-002 TE1
IC302 NJM4565M IC AC08-086-002 TE1
IC303 NJM4565M IC AC08-086-002 TE1
IC901 UPC494GS-E1-A IC AC08-004-002
IC902 PS2501-1 IC A149-5233-008
Q101 2SC3326 TRANSISTOR
AC04-083-003
TE85R F
Q102 2SA1618 TRANSISTOR
AC04-178-003
TE85L F
Q103 2SC4207 TRANSISTOR
AC04-177-004
TE85R F
Q104 2SA988F TRANSISTOR AT04-095-005
Q105 2SC1841F TRANSISTOR AT04-094-005
Q106 2SD637 TRANSISTOR A148-5484-002
Q107 2SA1037AK TRANSISTOR
AC04-051-005
T146
Q108 2SC2235 TRANSISTOR
AT04-219-004
TPE6 F
Q109 2SA965 TRANSISTOR
AT04-220-004
TPE6 F
Q110 2SC5100 TRANSISTOR
A148-5363-005
LF719
Q111 2SA1908 TRANSISTOR
A148-5364-005
LF719
Q112 DTC114EKA TRANSISTOR
AC04-311-003
T146
Q201 2SC3326 TRANSISTOR
AC04-083-003
TE85R F
Q202 2SA1618 TRANSISTOR
AC04-178-003
TE85L F
Q203 2SC4207 TRANSISTOR
AC04-177-004
TE85R F
Q204 2SA988F TRANSISTOR AT04-095-005
Q205 2SC1841F TRANSISTOR AT04-094-005
Q206 2SD637 TRANSISTOR A148-5484-002
Q207 2SA1037AK TRANSISTOR
AC04-051-005
T146
Q208 2SC2235 TRANSISTOR
AT04-219-004
TPE6 F
Q209 2SA965 TRANSISTOR
AT04-220-004
TPE6 F
Q210 2SC5100 TRANSISTOR
A148-5363-005
LF719
Q211 2SA1908 TRANSISTOR
A148-5364-005
LF719
Q212 DTC114EKA TRANSISTOR
AC04-311-003
T146
Q301 DTA114EKA TRANSISTOR
AC04-310-003
T146
Q302 2SC2412K TRANSISTOR
AC04-050-005
T146
Q303 2SC1815 TRANSISTOR
AT04-075-006
TPE2 F
Q304 2SC1815 TRANSISTOR
AT04-075-006
TPE2 F
Q305 2SA1015 TRANSISTOR
AT04-101-006
TPE2 F
Q306 2SA1015 TRANSISTOR
AT04-101-006
TPE2 F
Q307 2SC2412K TRANSISTOR
AC04-050-005
T146
Q308 2SC2412K TRANSISTOR
AC04-050-005
T146
Q309 2SC1815 TRANSISTOR
AT04-075-006
TPE2 F
Q310 2SA1015 TRANSISTOR
AT04-101-006
TPE2 F
Q311 DTA114EKA TRANSISTOR
AC04-310-003
T146
Q901 DTC114EKA TRANSISTOR
AC04-311-003
T146
Q902 2SB1132 TRANSISTOR
AC04-044-003
T100
Q903 2SC2412K TRANSISTOR
AC04-050-005
T146
Q904 DTC114EKA TRANSISTOR
AC04-311-003
T146
Q905 DTA144EKA TRANSISTOR
AC04-310-005
T146
Q906 DTC114EKA TRANSISTOR
AC04-311-003
T146
Q907 DTC114EKA TRANSISTOR
AC04-311-003
T146
Q908 2SC3326 TRANSISTOR
AC04-083-003
TE85R F
Q909 2SC3326 TRANSISTOR
AC04-083-003
TE85R F
Q910 FKV550N FET A148-5560-001
Q911 FKV550N FET A148-5560-001
D101 DAN202K DIODE ARRAY
AC04-053-002
T146
D102 DAN202K DIODE ARRAY
AC04-053-002
T146
D201 DAN202K DIODE ARRAY
AC04-053-002
T146
D202 DAN202K DIODE ARRAY
AC04-053-002
T146
D301 UDZS6.8B Z DIODE
AC04-312-068 TE-
17
D302 DAN202K DIODE ARRAY
AC04-053-002
T146
D303 FCH08A15 DIODE ARRAY A148-5550-002
D304 FRH08A15 DIODE ARRAY A148-5551-002
D305 UDZS13B Z DIODE
AC04-312-130 TE-
17
D306 UDZS15B Z DIODE
AC04-312-150 TE-
17
D307 DAN202K DIODE ARRAY
AC04-053-002
T146
D901 DAN202K DIODE ARRAY
AC04-053-002
T146
D902 DAN202K DIODE ARRAY
AC04-053-002
T146
D903 DAN202K DIODE ARRAY
AC04-053-002
T146
D904 UDZS16B Z DIODE
AC04-312-160 TE-
17
C101 AC03-430-101 C CAPACITOR 100pF 50V
C102 AC03-430-101 C CAPACITOR 100pF 50V
C103 AC03-430-470 C CAPACITOR 47pF 50V
C104 AC03-430-101 C CAPACITOR 100pF 50V
C105 AC03-430-101 C CAPACITOR 100pF 50V
C106 AT03-B80-105 E CAPACITOR 1uF 50V
C107 AC03-428-474 C CAPACITOR 0.47uF 10V
C108 AC03-432-104 C CAPACITOR 0.1uF 25V
C109 AT03-B77-107 E CAPACITOR 100uF 16V
C110 AC03-430-101 C CAPACITOR 100pF 50V
C111 AT03-B80-105 E CAPACITOR 1uF 50V
C112 AC03-430-470 C CAPACITOR 47pF 50V
C113 AC03-430-220 C CAPACITOR 22pF 50V
C114 AC03-432-104 C CAPACITOR 0.1uF 25V
C115 AC03-432-104 C CAPACITOR 0.1uF 25V
C116 AC03-432-104 C CAPACITOR 0.1uF 25V
C201 AC03-430-101 C CAPACITOR 100pF 50V
C202 AC03-430-101 C CAPACITOR 100pF 50V
C203 AC03-430-470 C CAPACITOR 47pF 50V
C204 AC03-430-101 C CAPACITOR 100pF 50V
C205 AC03-430-101 C CAPACITOR 100pF 50V
C206 AT03-B80-105 E CAPACITOR 1uF 50V
C207 AC03-428-474 C CAPACITOR 0.47uF 10V
C208 AC03-432-104 C CAPACITOR 0.1uF 25V
C209 AT03-B77-107 E CAPACITOR 100uF 16V
C210 AC03-430-101 C CAPACITOR 100pF 50V
C211 AT03-B80-105 E CAPACITOR 1uF 50V
C212 AC03-430-470 C CAPACITOR 47pF 50V
C213 AC03-430-220 C CAPACITOR 22pF 50V
C214 AC03-432-104 C CAPACITOR 0.1uF 25V
C215 AC03-432-104 C CAPACITOR 0.1uF 25V
C216 AC03-432-104 C CAPACITOR 0.1uF 25V
C301 AC03-433-224 C CAPACITOR 0.22uF 16V
C302 AT03-B77-227 E CAPACITOR 220uF 16V
 Symbol No. Part No. Part Name Description Local
