(No.MA171)1-5
SECTION 3
DISASSEMBLY
3.1 Main board
3.1.1 Removing the main board (See Fig.1 ~ 4)
(1) From the bottom of the amplifier, remove the five screws A
attaching the cover.
(2) From the main body of the amplifier, remove the nine
screws B attaching the main board.
(3) Remove the two screws C on top of the rear cover.
(4) Remove the screw D and the two screws E on the front side
of the rear cover.
Fig.1
Fig.2
Fig.3
Fig.4
A
A
B
B
B
C
ED
