KS-FX483R/KS-FX480R/KS-FX43R
3-6
Item
Parts number Parts name Area
A
Parts list (Cassette mechanism)
Q'ty
Description
Block No. MPMM
1 X-0363-1001S
MAIN CHASSIS AS
1
2 X-0363-1002S
HEAD PLATE ASSY
1
3 X-0363-1004S
FR CONV ARM (A)
1
4 X-0363-6001S
REEL BASE ASSY
1
5 X-0363-6007S
LEVER BRKT ASSY
1
6 X-0363-6003S
TU GEAR ARM ASS
1
7 X-0363-6004S
PINCH ARM(R) AS
1
8 X-0363-6005S
PINCH ARM(F) AS
1
9 X-0363-6006S
DETECTOR CAM AS
2
10 X-0363-2005S
REEL SPINDLE AS
2
12 X-0363-1019S
EJ.CAM LOCK ASY
1
15 1-0363-6010S
FLYWHEEL ASSY F
1
16 1-0363-6011S
FLYWHEEL ASSY R
1
19 1-0036-1065S
FF LEVER(JVC)
1
20 1-0036-1066S
REW LEVER(JVC)
1
21 1-0036-1007S
EJECT LEVER
1
22 1-0036-1013S
LOCK ARM
1
23 1-0036-1015S
SPG SUPPORT PLT
1
24 1-0036-1018S
CENTER PLATE
1
25 1-0036-1023S
CHANGE LEVER(B)
1
26 1-0036-1026S
FR ARM(B)
1
30 1-0138-1002S
CASSETTE HANGER
1
31 1-0138-1006S
ADJUSTER SHIN(X
1
32 1-0138-1010S
CASSETTE HOLDER
1
35 1-0363-1003S
EJECT CAM
1
37 1-0036-2001S
IDLE GEAR
1
38 1-0036-2003S
REDUCT.GEAR(B)
1
39 1-0036-2004S
REDUCT.GEAR(A)
1
40 1-0036-2007-5S
RATCHET
1
41 1-0036-2009S
SENSOR ARM
1
42 1-0036-2010S
SELECTOR GEAR
1
43 1-0036-2014S
DETECTOR GEAR
1
44 1-0038-2014S
GEAR LOCK ARM
1
45 1-0038-2018S
TAPE GUIDE
1
46 1-0363-2006S
ADJUSTER LINK(B
1
47 1-0138-2005-3S
ADJUSTER ARM(B)
1
48 1-0036-2005S
PULLEY GEAR
1
49 1-0032-2007S
TAPE HOOKER
1
50 1-0058-2021-5S
IDLER PULLEY(A)
1
53 1-0363-3018S
FF ROLLER
1
54 1-0036-3018S
COLLER
1
57 1-0363-3007S
HP ROLLER(A)
1
58 1-0363-3011S
PROGRAM ROLLER
1
61 1-0036-4001S
FF/REW LEVER SP
2
62 1-0036-4002S
LOCK LEVER SPG
1
63 1-0036-4003S
GEAR LOCK ARM S
1
65 1-0036-4006S
HEAD PLATE SPG
1
66 1-0036-4007S
EJ.CAM LOCK SPG
1
