JVC KS-FX43R - Page 43

KS-FX483R/KS-FX480R/KS-FX43R
3-7
Item
Parts number Parts name Area
A
Parts list (Cassette mechanism)
Q'ty
Description
Block No. MPMM
67 1-0036-4008S
PROGRAM ARM SPG
1
68 1-0036-4010S
ADJUST ARM SP(A
1
69 1-0036-4011S
ADJUST ARM SP(B
1
70 1-0036-4015S
DASH SPG
1
71 1-0036-4017S
CHANGING ARM SP
1
72 1-0036-4023S
CENTER PLT SP(B
1
73 1-0038-4014S
RATCHET SPG
1
74 1-0138-4001S
BACK TEMSION SP
2
76 1-0363-4003S
PINCH ARM SPG F
1
77 1-0363-4004S
PINCH ARM SPG R
1
78 1-0363-4005S
EJECT LEVER SPG
1
79 1-0036-4005S
EJECT CAM SPG
1
80 1-0036-5020S
MAIN BELT(AL)
1
81 1-0363-5007S
RETURN LINK
1
82 1-0036-5001S
SUB BELT
1
83 1-0363-5003S
SELECTOR LINK B
1
85 1-0036-7002S
WIRE(A)
1
86 1-0036-7003S
WIRE(B)
1
87 1-0036-7073S
WIRE(AL)
1
89 X-0363-7006S
MOTOR ASSY
1
93 1-0363-7001S
MUTE SW
1
94 1-0363-7002S
SLIDE SW
1
95 1-0363-7008S
SLIDE SW PWB
1
96 1-0036-7016S
HEAD
1
97 1-0363-7005S
POWER SW
1
100 1-0036-7089S
6P WIRE ASY(JVC
1
101 1-0036-7088S
5P WIRE ASY(JVC
1
105 2-1816-0032-E8S
MYLAR WASHER(S)
2
106 2-1812-0030-D2S
POLY WASHER(S)
3
107 1-0036-5024S
PSW(REEL)
5
109 2-1712-0050-16S
E RING
5
110 2-1712-5060-16S
E RING
1
114 1-0363-7015S
MUTE SW PWB
1
115 2-1331-7040-C2S
SCREW S
1
116 2-1331-7060-C2S
SCREW S
1
117 2-1382-0030-C2S
SCREW B
5
118 2-1332-0040-C1S
SCREW S
1
119 2-1032-0070-C2S
SCREW
2
120 2-1032-0025-C2S
SCREW
2
121 2-1012-0040-C2S
SCREW
1
122 2-1012-0030-F2S
SCREW
1
123 1-0138-5002S
AZIMUTH SCREW
3
