KS-FX483R/KS-FX480R/KS-FX43R
3-13
Item
Parts number Parts name Area
Electrical parts list (Mecha board)
Remarks
Block No. 02
A
C 101 QDGB1HK-821Y C CAPACITOR
C 102 QEKJ1HM-474Z E CAPACITOR
.47MF 20% 50V
C 103 QCBB1HK-101Y C CAPACITOR
100PF 10% 50V
C 104 QEKJ0JM-476Z E CAPACITOR
47MF 20% 6.3V
C 105 QFV61HJ-103Z MF CAPACITOR
.010MF 5% 50V
C 201 QDGB1HK-821Y C CAPACITOR
C 202 QERF1HM-474Z E CAPACITOR
.47MF 20% 50V
C 203 QCBB1HK-101Y C CAPACITOR
100PF 10% 50V
C 204 QEKJ0JM-476Z E CAPACITOR
47MF 20% 6.3V
C 205 QFV61HJ-103Z MF CAPACITOR
.010MF 5% 50V
C 901 QEKJ1AM-107Z E CAPACITOR
100MF 20% 10V
CJ901 QGA2002C1-05 CONNECTOR
CP721 QGB1214K1-06S CONN.TERMINAL
CP722 QGA2002F1-06 CONNECTOR
CP901 QGB1214K1-06S CONN.TERMINAL
IC901 UPC1228HA IC
R 101 QRE141J-153Y C RESISTOR
15K 5% 1/4W
R 103 QRE141J-101Y C RESISTOR
100 5% 1/4W
R 104 QRE141J-334Y C RESISTOR
330K 5% 1/4W
R 201 QRE141J-153Y C RESISTOR
15K 5% 1/4W
R 203 QRE141J-101Y C RESISTOR
100 5% 1/4W
R 204 QRE141J-334Y C RESISTOR
330K 5% 1/4W
R 901 QRE141J-101Y C RESISTOR
100 5% 1/4W
