KS-FX483R/KS-FX480R/KS-FX43R
3-14
Item
Parts number Parts name Area
Electrical parts list (Front board)
Remarks
Block No. 03
A
C 651 NCB31EK-103X C CAPACITOR
C 652 NBE20JM-475X TS E CAPACITOR
C 653 NCB31HK-681X C CAPACITOR
CP701 VMC0335-001 CONNECTOR
D 601 SML-310LT/MN/-X LED
D 602 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 602 LNJ308G81/1-3/X L.E.D.
FX480R
D 603 LNJ308G81/1-3/X L.E.D.
FX480R
D 603 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 604 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 604 LNJ308G81/1-3/X L.E.D.
FX483R
D 605 LNJ308G81/1-3/X L.E.D.
FX480R
D 605 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 606 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 606 LNJ308G81/1-3/X L.E.D.
FX480R
D 607 LNJ308G81/1-3/X L.E.D.
FX480R
D 607 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 608 SML-310VT/JK/-X L.E.D.
FX480R
D 608 LNJ308G81/1-3/X L.E.D.
FX483R
D 610 LNJ308G81/1-3/X L.E.D.
FX480R
D 610 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 611 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 611 LNJ308G81/1-3/X L.E.D.
FX480R
D 612 LNJ308G81/1-3/X L.E.D.
FX480R
D 612 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 613 LNJ308G81/1-3/X L.E.D.
FX480R
D 613 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 614 LNJ308G81/1-3/X L.E.D.
FX480R
D 614 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 615 LNJ308G81/1-3/X L.E.D.
FX480R
D 615 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 616 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 616 LNJ308G81/1-3/X L.E.D.
FX480R
D 617 LNJ308G81/1-3/X L.E.D.
FX480R
D 617 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 618 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 618 LNJ308G81/1-3/X L.E.D.
FX480R
D 619 LNJ308G81/1-3/X L.E.D.
FX480R
D 619 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 620 SML-310DT/KL/-X L.E.D.
FX483R/FX43R
D 620 LNJ308G81/1-3/X L.E.D.
FX480R
D 654 MA152WK-X SI DIODE
IC651 LC75823W IC
PL601 QLL0152-001 LAMP
FX480R
PL601 QLL0076-001 LAMP
FX483R/FX43R
PL603 QLL0076-001 LAMP
FX483R/FX43R
PL603 QLL0152-001 LAMP
FX480R
R 601 NRSA63J-821X MG RESISTOR
R 602 NRSA63J-821X MG RESISTOR
R 603 NRSA63J-122X MG RESISTOR
R 604 NRSA63J-182X MG RESISTOR
R 605 NRSA63J-272X MG RESISTOR
R 607 NRSA63J-821X MG RESISTOR
R 608 NRSA63J-821X MG RESISTOR
R 609 NRSA63J-122X MG RESISTOR
R 610 NRSA63J-182X MG RESISTOR
R 611 NRSA63J-272X MG RESISTOR
R 613 NRSA63J-821X MG RESISTOR
R 614 NRSA63J-821X MG RESISTOR
R 615 NRSA63J-122X MG RESISTOR
R 616 NRSA63J-182X MG RESISTOR
R 617 NRSA63J-272X MG RESISTOR
R 618 NRSA63J-392X MG RESISTOR
R 634 NRSA02J-152X MG RESISTOR
FX480R
R 635 NRSA02J-821X MG RESISTOR
R 636 NRSA02J-122X MG RESISTOR
R 637 NRSA02J-122X MG RESISTOR
FX483R/FX43R
R 637 NRSA02J-821X MG RESISTOR
FX480R
R 638 NRSA02J-122X MG RESISTOR
R 639 NRSA02J-122X MG RESISTOR
FX483R/FX43R
R 639 NRSA02J-821X MG RESISTOR
FX480R
R 640 NRSA02J-122X MG RESISTOR
FX483R
R 640 NRSA02J-152X MG RESISTOR
FX480R/FX43R
R 641 NRSA02J-152X MG RESISTOR
FX480R/FX43R
R 641 NRSA02J-122X MG RESISTOR
FX483R
R 642 NRSA02J-122X MG RESISTOR
FX483R/FX43R
R 642 NRSA02J-821X MG RESISTOR
FX480R
R 643 NRSA02J-821X MG RESISTOR
FX480R
R 643 NRSA02J-122X MG RESISTOR
FX483R/FX43R
R 644 NRSA02J-122X MG RESISTOR
FX483R/FX43R
R 644 NRSA02J-561X MG RESISTOR
FX480R
R 645 NRSA02J-621X MG RESISTOR
FX480R
R 645 NRSA02J-122X MG RESISTOR
FX483R/FX43R
R 646 NRSA02J-122X MG RESISTOR
FX483R/FX43R
R 646 NRSA02J-821X MG RESISTOR
FX480R
R 647 NRSA02J-821X MG RESISTOR
FX480R
R 647 NRSA02J-122X MG RESISTOR
FX483R/FX43R
R 648 NRSA02J-122X MG RESISTOR
FX483R/FX43R
R 648 NRSA02J-821X MG RESISTOR
FX480R
R 649 NRSA02J-122X MG RESISTOR
FX483R/FX43R
R 649 NRSA02J-152X MG RESISTOR
FX480R
R 651 NRSA02J-152X MG RESISTOR
R 652 NRSA02J-473X MG RESISTOR
R 653 NRSA02J-184X MG RESISTOR
R 654 NRSA02J-103X MG RESISTOR
R 655 NRSA02J-103X MG RESISTOR
R 656 NRSA02J-103X MG RESISTOR
S 601 NSW0124-001X TACT SW
S 602 NSW0124-001X TACT SW
S 603 NSW0124-001X TACT SW
S 604 NSW0124-001X TACT SW
S 605 NSW0124-001X TACT SW
S 606 NSW0124-001X TACT SW
S 608 NSW0124-001X TACT SW
S 609 NSW0124-001X TACT SW
S 610 NSW0124-001X TACT SW
S 611 NSW0124-001X TACT SW
S 612 NSW0124-001X TACT SW
S 614 NSW0124-001X TACT SW
S 615 NSW0124-001X TACT SW
S 616 NSW0124-001X TACT SW
S 617 NSW0124-001X TACT SW
S 618 NSW0124-001X TACT SW
S 619 NSW0124-001X TACT SW
S 620 NSW0124-001X TACT SW
S 621 NSW0124-001X TACT SW
Item
Parts number Parts name Area
Remarks
A
D 608 SML-310DT/KL/-X L.E.D.
FX43R
