KS-FX460R/KS-FX463R
Item Parts number Parts name Area
A
Parts list(Cassette mechanism)
Q'ty Description
Block No. M2MM
1 X-0363-1001S MAIN CHASSIS AS 1
2 X-0363-1002S HEAD PLATE ASSY 1
3 X-0363-1004S FR CONVERT ARM 1
(
A
)
4 X-0363-6001S REEL BASE ASSY 1
5 X-0363-6007S LEVER BRACKET 1
(
HD
)
6 X-0363-6003S TU GEAR ARM ASS 1
7 X-0363-6004S PINCH ARM
(
R
)
AS 1
8 X-0363-6005S PINCH ARM
(
F
)
AS 1
9 X-0363-6006S DETECTOR CAM AS 2
(
V
)
10 X-0363-2005S REEL SPINDLE AS 2
12 X-0363-1019S EJ.CAM LOCK ASS 1
15 1-0363-6010S FLYWHEEL ASSY
(
F 1 CPL
16 1-0363-6011S FLYWHEEL ASSY
(
R 1 CPL
19 1-0036-1065S FF LEVER
(
JVC
)
1
20 1-0036-1066S REW LEVER
(
JVC
)
1
21 1-0036-1007S EJECT LEVER 1
22 1-0036-1013S LOCK ARM 1
23 1-0036-1015S SPG SUPPORT PLT 1
24 1-0036-1018S CENTER PLATE 1
25 1-0036-1023S CHANGE LEVER
(
B
)
1
26 1-0036-1026S FR ARM
(
B
)
1
30 1-0138-1002S CASSETTE HANGER 1
(
X
)
31 1-0138-1006S ADJUSTER SHIM 1
(
X
)
32 1-0138-1010S CASSETTE HOLDER 1
(
X
)
35 1-0363-1003S EJECT CAM 1
37 1-0036-2001S IDLE GEAR 1
38 1-0036-2003S REDUCTION GEAR 1
(
B
)
39 1-0036-2004S REDUCTION GEAR 1
(
A
)
40 1-0036-2007-5S RATCHET 1
41 1-0036-2009S SENSOR ARM 1
42 1-0036-2010S SELECTOR GEAR 1
43 1-0036-2014S DETECTOR GEAR 1
44 1-0038-2014S GEAR LOCK ARM 1
45 1-0038-2018S TAPE GUIDE 1
46 1-0363-2006S ADJUSTER LINK
(
B 1
47 1-0138-2005-3S ADJUSTER ARM 1 BLUE
48 1-0036-2005S PULLEY GEAR 1
49 1-0032-2007S TAPE HOOKER 1
50 1-0058-2021-5S IDLE PULLEY
(
A
)
1
53 1-0363-3018S FF ROLLER 1
54 1-0036-3018S COLLAR 1
(
SELECTOR GEAR
)
57 1-0363-3007S HP ROLLER
(
A
)
1
58 1-0363-3011S PROGRAM ROLLER 1
61 1-0036-4001S FF/REW LEVER SP 2
62 1-0036-4002S LOCK LEVER SPG 1
63 1-0036-4003S G.LOCK ARM SPG 1
65 1-0036-4006S HEAD PLATE SPG 1
66 1-0036-4007S EJ.CAM LOCK SPG 1
