JVC KS-FX460R

3-7
KS-FX460R/KS-FX463R
Item Parts number Parts name Area
A
Parts list(Cassette mechanism)
Q'ty Description
Block No. M2MM
67 1-0036-4008S PROGRAM ARM SPG 1
68 1-0036-4010S ADJUSTER ARM SP 1
(
A
)
69 1-0036-4011S ADJUSTER ARM SP 1
(
B
)
70 1-0036-4015S DASH SPG 1
71 1-0036-4017S S.SELECT ARM SP 1
72 1-0036-4023S CENTER PLT SP
(
B 1
73 1-0038-4014S RATCHET SPG 1
74 1-0138-4001S BACK TENSION SP 2
76 1-0363-4003S PINCH ARM SPG F 1
77 1-0363-4004S PINCH ARM SPG R 1
78 1-0363-4005S EJECT LEVER SPG 1
79 1-0036-4005S EJECT CAM SPG 1
80 1-0036-5020S MAIN BELT
(
AL
)
1
81 1-0363-5007S RETURN LINK 1
82 1-0036-5001S SUB BELT 1
83 1-0363-5003S SELECTOR LINK
(
B 1
85 1-0036-7002S WIRE
(
A
)
1 BLACK 60MM
86 1-0036-7003S WIRE
(
B
)
1 RED 60MM
87 1-0036-7073S WIRE
(
AL
)
1 YELLOW 55MM
89 X-0363-7006S MOTOR ASSY 1
93 1-0363-7001S MUTE SWITCH 1
94 1-0363-7002S SLIDE SWITCH 1
95 1-0363-7008S SLIDE SW PWB 1
96 1-0036-7016S HEAD 1
97 1-0363-7005S POWER SWITCH 1
100 1-0036-7089S 6P WIRE ASY
(
JVC 1
101 1-0036-7088S 5P WIRE ASY
(
JVC 1
105 2-1816-0032-E8S LMW-S 2
106 2-1812-0030-D2S PSW-S 3
107 1-0036-5024S PSW
(
REEL
)
B 5
109 2-1712-0050-16S E RING 5
110 2-1712-5060-16S E RING 1
114 1-0363-7015S MUTE SW PWB 1
115 2-1331-7040-C2S SCREW S 1
116 2-1331-7060-C2S SCREW S 1
117 2-1382-0030-C2S SCREW B 5
118 2-1332-0040-C1S SCREW S 1
119 2-1032-0070-C2S SCREW 2
120 2-1032-0025-C2S SCREW 2
121 2-1012-0040-C2S SCREW 1
122 2-1012-0030-F2S SCREW 1
123 1-0138-5002S AZIMUTH SCREW 3
