10
You can listen to the playback sounds with
cordless headphones—KS-HP2.
Installing the batteries
CAUTIONS:
• The supplied batteries are not rechargeable.
DO NOT recharge them; otherwise, battery
leakage or explosion may result.
• Insert the batteries with the correct polarity
“+” and “–” to prevent the battery leakage
or explosion.
Before using the cordless headphones:
The headphones give the best results when used
within about 1.8 m from the IR transmitters.
These headphones need to receive infrared
(IR) signals sent from IR transmitters on the
monitor. Therefore, if you use the headphones
where the signals cannot be received in a
straight line of sight, noises may be generated.
Main elements and features
1 IR sensors
• DO NOT cover the IR sensors, as
reception will become poor.
2 ON/OFF button
• Turns the power on and off.
• The power automatically shuts off in the
following cases:
– The headphones are used for about 4
hours.
– No signal is received for about 4
minutes.
3 POWER lamp
4 VOL (volume) control
Playback sounds are transmitted through IR
transmitters to the cordless headphones.
When using the headphones, select
“HEADPHONE” (or “HEADPHONE/AUX”)
for the monitor menu item “AUDIO.” (See page
14.)
WARNING:
DO NOT use the headphones while driving.
Shutting out all outside sounds while driving
is dangerous and may result in a traffic
accident.
Headphones — KS-HP2
Left side Right side
IR transmitters
POWER
VOL
Batteries (R03/AAA)
—supplied only
for initial setup
purpose
Inst_KS-JA0502-4[U].indb 10Inst_KS-JA0502-4[U].indb 10 09.11.10 3:30:22 PM09.11.10 3:30:22 PM
