TROUBLESHOOTING
Symptom Remedy
CD / USB
“CANNOT PLAY” flashes
and/or connected device
cannot be detected.
• Check whether the connected device is compatible with
this unit and ensure the files are in supported formats.
(
 12 )
• Reattach the device.
Correct characters are not
displayed.
This unit can only display uppercase letters, numbers,
and a limited number of symbols.
ANDROID
• Sound cannot be heard
during playback.
• Sound output only from
the Android device.
• Reconnect the Android device.
• If in [
AUDIO MODE ], launch any media player
application on the Android device and start playback.
• If in [
AUDIO MODE ], relaunch the current media player
application or use another media player application.
• Restart the Android device.
• If this does not solve the problem, the connected Android
device is unable to route the audio signal to unit. (
13 )
Cannot playback at [
AUTO
MODE
].
• Make sure JVC MUSIC PLAY APP is installed on the
Android device. ( 5 )
• Reconnect the Android device and select the appropriate
control mode. (
6 )
• If this does not solve the problem, the connected Android
device does not support [
AUTO MODE ]. ( 13 )
“NO DEVICE” or “READING”
keeps flashing.
• Switch off the developer options on the Android device.
• Reconnect the Android device.
• If this does not solve the problem, the connected Android
device does not support [
AUTO MODE ]. ( 13 )
Playback is intermittent or
sound skips.
Turn off the power saving mode on the Android device.
“CANNOT PLAY” • Make sure Android device contains playable audio files.
• Reconnect the Android device.
• Restart the Android device.
If you still have troubles, reset the unit. ( 3)
SPECIFICATIONS
Tuner
FM
Frequency Range 87.5MHz — 108.0MHz (50kHz step)
Usable Sensitivity (S/N=26dB) 8.2dBf (0.71μV/75Ω)
Quieting Sensitivity
(DINS/N=46dB)
17.2dBf (2.0μV/75Ω)
Frequency Response (±3dB) 30Hz — 15kHz
Signal-to-Noise Ratio (MONO) 64dB
Stereo Separation (1kHz) 40dB
AM
Frequency Range Band 1 (AM): 531kHz — 1611kHz
(9kHz step)
Band 2 (SW1): 2940kHz — 7735kHz
(5kHz step)
Band 3 (SW2): 9500kHz — 10135kHz /
11580kHz — 18135kHz
(5kHz step)
Channel Space Selection Band 1: 9kHz
Band 2/3: 5kHz
Usable Sensitivity (S/N=20dB) AM: 29dBμ (28.2μV)
SW: 30dBμ (32μV)
