Specifications
R Monitor section
Picture Size (W x H)
K W-V41BT: 6.95 inches(diagonal) wide
156.6 mm × 81.6 mm
K W-V215DBT/KW-V21BT/KW-V11:
6.2 inches(diagonal) wide
137.5 mm× 77.2 mm
Display System Transparent TN LCD panel
Drive System TFT active matrix system
Number of Pixels 1152000 (800H × 480V × RGB)
Effective Pixels 99.99%
Pixel Arrangement
RGB striped arrangement
Back Lighting LED
R DVD player section
D/A Converter 24 bit
Audio Decoder Linear PCM/Dolby Digital/MP3/
WMA / WAV
Video Decoder MPEG1/MPEG2/DivX /JPEG
Wow & Flutter Below Measurable Limit
Frequency Response
96 kHz Sampling: 20 Hz – 22000 Hz
48 kHz Sampling: 20 Hz – 22000 Hz
44.1 kHz Sampling: 20 Hz – 20000 Hz
Total Harmonic Distortion
0.010% (1 kHz)
Signal to Noise Ratio
99 dB (DVD-Video 96 kHz)
Dynamic Range 99 dB (DVD-Video 96 kHz)
D
isc Format DVD-Video/VIDEO-CD/CD-DA
Sampling Frequency
44.1 kHz/48 kHz/96 kHz
Quantifying Bit Number
16/20/24 bit
R USB interface section
USB Standard USB 2.0 Full Speed
Compatible Devices
Mass storage class
File System FAT 12/16/32
Maximum Power Supply Current
DC 5 V
1 A
D/A Converter 24 bit
Audio Decoder MP3/WMA / WAV
Video Decoder MPEG1/MPEG2/DivX /JPEG
R Bluetooth section (only for KW-V41BT/
KW-V215DBT/KW-V21BT )
Technology Bluetooth 2.1 + EDR
Frequency 2.402 GHz – 2.480 GHz
Output Power +4 dBm (MAX), 0 dBm (AVE),
Power Class 2
Maximum Communication Range
Line of sight approx. 10 m
Audio Codec SBC
Profile HFP (Hands Free Profile) 1.5
SPP (Serial Port Profile) 1.1
SDP (Service Discovery Profile)
A2DP (Advanced Audio
Distribution Profile) 1.2
AVRCP (Audio/Video Remote
Control Profile) 1.3
OPP (Object Push Profile)
P
BAP (Phonebook Access Profile)
1.0
GAP (Generic Access Profile)
