KW-XR416
Installation/Connection Manual
/
ENGLISH /
0110DTSMDTJEIN
EN, TH
© 2010 Victor Company of Japan, Limited
GET0656-010A
[UH]
• To prevent short circuits:
– Disconnect the battery’s negative terminal and make all electrical connections before installing the unit.
– Cover the terminals of the UNUSED leads with insulating tape.
• Be sure to ground this unit to the car’s chassis again after installation.
• Replace the fuse with one of the specified rating.
• Connect speakers with a maximum power of more than 50 W (impedance of 4 Ω to 8 Ω). Otherwise,
change the <AMP GAIN> setting. (See page 16 of the INSTRUCTIONS.)
• The heat sink becomes very hot after use. Be careful not to touch it when removing this unit.
•
:
–
–
•
•
• 50 W ( 4 Ω 8 Ω)
<AMP GAIN> (
16 )
•
12 V DC, NEGATIVE ground /
12 V,
To the car system /
You need the installation kits which corresponds to your car. /
Check the battery system in your car /
WARNINGS /
Heat sink /
INSTALLATION /
The following illustration shows a typical installation. If you have any questions or require information
regarding installation kits, consult your JVC car audio dealer or a company supplying kits.
JVC
In-dash mounting /
In-dash
Audio system originally
installed in the car /
Car dashboard /
If there is an interfering tab on
the mounting bracket, bent it
flat. /
Screw removed from the car /
Mounting bracket removed from the car /
Firmly attach the ground wire to the metallic body of the car using the screw
originally fixed to the metallic body of the car. /
Installing with the mounting brackets from the car /
Install the unit at an angle of less than 30˚.
30˚
Part list /
A Flat countersunk screws—M5 × 8 mm /
—M5 × 8 . (×8)
B Round head screws—M5 × 8 mm /
—M5 × 8 . (×8)
C Plate for use with a Nissan car /
(×1)
D Power cord / (×1)
When installating the unit in a Nissan car /
Fix the supplied plate as illutrated. /
To Next Page
