Page #154 background imageLoading...
Page #154 background image
3-8(No.YA369)
R128 T1001-00073A C RESISTOR 10K
Ω
1/16W J
R129 T1001-00073A C RESISTOR 10K
Ω
1/16W J
R130 TA40-00016A C RESISTOR 1K
Ω
1/16W J
R131 T3711-00034 C RESISTOR 1.5K
Ω
1/16W J
R132 T1001-00086A C RESISTOR 47K
Ω
1/16W J
R133 T2401-BT101O C RESISTOR 220
Ω
1/16W J
R134 T1001-00073A C RESISTOR 10K
Ω
1/16W J
R136 T1001-00085A C RESISTOR 27K
Ω
1/16W J
R138 T1001-00073A C RESISTOR 10K
Ω
1/16W J
R210 2401-002075 C RESISTOR 270
Ω
1/16W J
R211 T2401-FT0R1A C RESISTOR 100
Ω
1/16W J
R214 TA40-00016A C RESISTOR 1K
Ω
1/16W J
R215 TA40-00016A C RESISTOR 1K
Ω
1/16W J
R216 TA40-00016A C RESISTOR 1K
Ω
1/16W J
R217 T3722-00054A C RESISTOR 1K
Ω
1/16W J
R218 T3722-00054A C RESISTOR 1K
Ω
1/16W J
R219 T3722-00054A C RESISTOR 1K
Ω
1/16W J
R220 T3722-00054A C RESISTOR 1K
Ω
1/16W J
R223 T2801-00011A C RESISTOR 470
Ω
1/16W J
R224 T2203-FC152D C RESISTOR 33
Ω
1/16W J
R225 T2203-FC392D C RESISTOR 75
Ω
1/16W J
R226 T2203-FC152D C RESISTOR 33
Ω
1/16W J
R227 T2203-FC392D C RESISTOR 75
Ω
1/16W J
R228 T2203-FC152D C RESISTOR 33
Ω
1/16W J
R229 T2203-FC392D C RESISTOR 75
Ω
1/16W J
R230 T2203-FC152D C RESISTOR 33
Ω
1/16W J
R231 T2203-FC152D C RESISTOR 33
Ω
1/16W J
R232 T2801-00011A C RESISTOR 470
Ω
1/16W J
R233 T2203-FC221E C RESISTOR 33
Ω
1/16W J
R235 T2203-FC392D C RESISTOR 75
Ω
1/16W J
R236 T2203-FC392D C RESISTOR 75
Ω
1/16W J
R237 T2203-FC104E C RESISTOR 82
Ω
1/16W J
R238 T2203-FC104E C RESISTOR 82
Ω
1/16W J
R239 T2203-FC104E C RESISTOR 82
Ω
1/16W J
R242 T2203-FC471D C RESISTOR 75
Ω
1/16W J
R243 T3722-00054A C RESISTOR 1K
Ω
1/16W J
R244 T3722-00040A C RESISTOR 1K
Ω
1/16W J
R245 T2203-FC471D C RESISTOR 75
Ω
1/16W J
R246 T2203-FC471D C RESISTOR 75
Ω
1/16W J
R247 T2203-FC471D C RESISTOR 75
Ω
1/16W J
R248 T1001-00064A C RESISTOR 10K
Ω
1/16W J
R249 T1001-00064A C RESISTOR 10K
Ω
1/16W J
R255 T2401-FT0R1A C RESISTOR 100
Ω
1/16W J
R256 T2203-FC471D C RESISTOR 75
Ω
1/16W J
R260 T2203-FC472D C RESISTOR 75
Ω
1/16W J
R261 T1001-00085A C RESISTOR 27K
Ω
1/16W J
R262 T2203-FC472D C RESISTOR 75
Ω
1/16W J
R263 T2203-FC472D C RESISTOR 75
Ω
1/16W J
R264 T2203-FC472D C RESISTOR 75
Ω
1/16W J
R267 T2203-FC472D C RESISTOR 75
Ω
1/16W J
R271 T2401-FT0R1A C RESISTOR 100
Ω
1/16W J
R272 T2401-FT0R1A C RESISTOR 100
Ω
1/16W J
R273 2401-002075 C RESISTOR 270
Ω
1/16W J
R274 T2401-FT0R1A C RESISTOR 100
Ω
1/16W J
R275 T2203-FC060D C RESISTOR 0
Ω
1/16W J
R277 T2203-FC060D C RESISTOR 0
Ω
1/16W J
R278 T3722-00040A C RESISTOR 1K
Ω
1/16W J
R279 T3722-00040A C RESISTOR 1K
Ω
1/16W J
R280 T3722-00040A C RESISTOR 1K
Ω
1/16W J
R281 T2203-FC104E C RESISTOR 82
Ω
1/16W J
R282 T2203-FC104E C RESISTOR 82
Ω
1/16W J
R283 T2203-BC106E C RESISTOR 82
Ω
1/16W J
R285 T2203-FC473D C RESISTOR 75
Ω
1/16W J
R286 T1001-00085A C RESISTOR 27K
Ω
1/16W J
R287 T2203-FC470D C RESISTOR 4.7
Ω
1/16W J
R288 T2203-FC473D C RESISTOR 75
Ω
1/16W J
R289 T2203-FC473D C RESISTOR 75
Ω
1/16W J
R290 2401-000269 C RESISTOR 100
Ω
1/16W J
R291 2401-000269 C RESISTOR 100
Ω
1/16W J
R292 T3722-00040A C RESISTOR 1K
Ω
1/16W J
R294 T2203-FC470D C RESISTOR 4.7
Ω
1/16W J
R295 T2203-FC473D C RESISTOR 75
Ω
1/16W J
R296 T3722-00040A C RESISTOR 1K
Ω
1/16W J
R299 T2203-FC221E C RESISTOR 33
Ω
1/16W J
R304 2401-000269 C RESISTOR 100
Ω
1/16W J
R305 2401-000269 C RESISTOR 100
Ω
1/16W J
R307 2401-000269 C RESISTOR 100
Ω
1/16W J
R308 2401-001495 C RESISTOR 100
Ω
1/16W J
R310 T1001-00064A C RESISTOR 10K
Ω
1/16W J
R313 2401-001495 C RESISTOR 100
Ω
1/16W J
R314 T3711-00037 C RESISTOR 4.7K
Ω
1/16W J
R315 T2203-FC101D C RESISTOR 10
Ω
1/16W J
R316 T2203-FC101D C RESISTOR 10
Ω
1/16W J
R317 T2203-FC101D C RESISTOR 10
Ω
1/16W J
R318 T3711-00035 C RESISTOR 2.7K
Ω
1/16W J
R319 T2203-FC101D C RESISTOR 10
Ω
1/16W J
R320 2401-001495 C RESISTOR 100
Ω
1/16W J
R321 T3711-00035 C RESISTOR 2.7K
Ω
1/16W J
R322 2401-001495 C RESISTOR 100
Ω
1/16W J
R327 2401-001495 C RESISTOR 100
Ω
1/16W J
R328 T2401-CT470O C RESISTOR 100
Ω
1/16W J
R329 T2203-FC473D C RESISTOR 75
Ω
1/16W J
R330 T3711-00037 C RESISTOR 4.7K
Ω
1/16W J
Ref No. Part No. Part Name Description Local
R331 T2401-CT470O C RESISTOR 100
Ω
1/16W J
R332 T2203-DC104E C RESISTOR 22
Ω
1/16W J
R333 T2203-DC104E C RESISTOR 22
Ω
1/16W J
R335 T1001-00084A C RESISTOR 22K
Ω
1/16W J
R336 T1001-00086A C RESISTOR 47K
Ω
1/16W J
R337 T3711-00036 C RESISTOR 3.3K
Ω
1/16W J
R338 T3711-00036 C RESISTOR 3.3K
Ω
1/16W J
R339 T3711-00036 C RESISTOR 3.3K
Ω
1/16W J
R340 T2203-DC104E C RESISTOR 22
Ω
1/16W J
R341 T2401-CT470O C RESISTOR 100
Ω
1/16W J
R342 T2203-FC101D C RESISTOR 10
Ω
1/16W J
R343 T3722-00040A C RESISTOR 1K
Ω
1/16W J
R344 T2401-CT470O C RESISTOR 100
Ω
1/16W J
R345 T2401-CT470O C RESISTOR 100
Ω
1/16W J
R346 2401-000914 C RESISTOR 100
Ω
1/16W J
R347 2401-000914 C RESISTOR 100
Ω
1/16W J
R348 2401-000914 C RESISTOR 100
Ω
1/16W J
R349 T3711-00037 C RESISTOR 4.7K
Ω
1/16W J
R350 T3711-00037 C RESISTOR 4.7K
Ω
1/16W J
R351 T2203-FC221E C RESISTOR 33
Ω
1/16W J
R352 T2203-FC221E C RESISTOR 33
Ω
1/16W J
R353 T2203-FC221E C RESISTOR 33
Ω
1/16W J
R354 T2203-FC222D C RESISTOR 33
Ω
1/16W J
R355 2401-000914 C RESISTOR 100
Ω
1/16W J
R356 2401-000914 C RESISTOR 100
Ω
1/16W J
R357 T3711-00036 C RESISTOR 3.3K
Ω
1/16W J
R358 2401-000603 C RESISTOR 100
Ω
1/16W J
R359 2401-000603 C RESISTOR 100
Ω
1/16W J
R360 T3711-00036 C RESISTOR 3.3K
Ω
1/16W J
R361 T3711-00019 C RESISTOR 4.7K
Ω
1/16W J
R363 T2801-00014A C RESISTOR 680
Ω
1/16W J
R364 T2203-FC102D C RESISTOR 10
Ω
1/16W J
R365 T3711-00019 C RESISTOR 4.7K
Ω
1/16W J
R367 2401-000603 C RESISTOR 100
Ω
1/16W J
R370 T1001-00064A C RESISTOR 10K
Ω
1/16W J
R371 T2401-CT471O C RESISTOR 330
Ω
1/16W J
R373 2401-000603 C RESISTOR 100
Ω
1/16W J
R375 T1001-00064A C RESISTOR 10K
Ω
1/16W J
R376 2401-002075 C RESISTOR 270
Ω
1/16W J
R377 T2203-FC060D C RESISTOR 0
Ω
1/16W J
R378 T3722-00040A C RESISTOR 1K
Ω
1/16W J
R380 T1001-00083A C RESISTOR 10K
Ω
1/16W J
R382 2401-000603 C RESISTOR 100
Ω
1/16W J
R383 T2801-00013A C RESISTOR 560
Ω
1/16W J
R385 2401-002235 C RESISTOR 100
Ω
1/16W J
R390 T3711-00019 C RESISTOR 4.7K
Ω
1/16W J
R391 T2203-FC060D C RESISTOR 0
Ω
1/16W J
R392 T3711-00019 C RESISTOR 4.7K
Ω
1/16W J
R393 2401-002235 C RESISTOR 100
Ω
1/16W J
R394 T3722-00040A C RESISTOR 1K
Ω
1/16W J
R395 T2203-FC330D C RESISTOR 0
Ω
1/16W J
R396 T3711-00029 C RESISTOR 3.3K
Ω
1/16W J
R397 T3711-00029 C RESISTOR 3.3K
Ω
1/16W J
R411 T2801-00011A C RESISTOR 470
Ω
1/16W J
R412 T2203-FC334D C RESISTOR 68
Ω
1/16W J
R413 2401-002235 C RESISTOR 100
Ω
1/16W J
R414 T2203-FC222D C RESISTOR 33
Ω
1/16W J
R415 T2801-00014A C RESISTOR 680
Ω
1/16W J
R416 T2203-DC104E C RESISTOR 22
Ω
1/16W J
R417 T2203-DC104E C RESISTOR 22
Ω
1/16W J
R418 T3711-00019 C RESISTOR 4.7K
Ω
1/16W J
R419 T2203-FC100D C RESISTOR 0
Ω
1/16W J
R427 T1001-00052A C RESISTOR 1M
Ω
1/16W J
R429 T2203-FC222D C RESISTOR 33
Ω
1/16W J
R432 T2203-FC222D C RESISTOR 33
Ω
1/16W J
R434 T2203-FC222D C RESISTOR 33
Ω
1/16W J
R436 T2203-FC224D C RESISTOR 33
Ω
1/16W J
R442 T2203-FC331D C RESISTOR 33
Ω
1/16W J
R456 T3711-00038 C RESISTOR 4.7K
Ω
1/16W J
R457 T2203-FC682D C RESISTOR 75
Ω
1/16W J
R458 T2203-FC682D C RESISTOR 75
Ω
1/16W J
R459 T2203-FC682D C RESISTOR 75
Ω
1/16W J
R460 T3711-00038 C RESISTOR 4.7K
Ω
1/16W J
R461 T1001-00070A C RESISTOR 470K
Ω
1/16W J
R462 T3711-00038 C RESISTOR 4.7K
Ω
1/16W J
R501 T1001-00083A C RESISTOR 10K
Ω
1/16W J
R504 T3711-00038 C RESISTOR 4.7K
Ω
1/16W J
R505 T1001-00087A C RESISTOR 100K
Ω
1/16W J
R509 2007-001167 CHIP BEAD 30
Ω
R510 2007-001167 CHIP BEAD 30
Ω
R511 2007-001167 CHIP BEAD 30
Ω
R515 2007-001167 CHIP BEAD 30
Ω
R516 2007-001167 CHIP BEAD 30
Ω
R517 2007-000115 CHIP BEAD 30
Ω
R518 2007-000115 CHIP BEAD 30
Ω
R519 2007-000115 CHIP BEAD 30
Ω
R529 T2203-FC100D C RESISTOR 0
Ω
1/16W J
R540 T2203-FC102D C RESISTOR 10
Ω
1/16W J
R541 2007-000115 CHIP BEAD 30
Ω
R542 2007-000115 CHIP BEAD 30
Ω
R543 2007-000074 CHIP BEAD 30
Ω
R544 T2203-FC104D C RESISTOR 22
Ω
1/16W J
R546 2007-000074 CHIP BEAD 30
Ω
Ref No. Part No. Part Name Description Local
