3-12(No.YA369)
LED P.W. BOARD ASS'Y (QAL0827-001)
KEY P.W. BOARD ASS'Y (QAL0828-001)
RC1 T2007-JC224J C RESISTOR 220K Ω J
RC2 T2007-JC224J C RESISTOR 220K Ω J
RC3 T2007-JC224J C RESISTOR 220K
Ω J
RS1 T2003-ETR15A R-WIRE 0.2
Ω 3W J
RS2 T2003-ETR62A R-WIRE 0.62 Ω 3W J
RS3 T2003-ET0R2A R-WIRE 0.2 Ω 3W J
SC1 T0501-00011A SCR 0.8A 30V
 VX1 T1405-0011A VARISTOR
 VX4 T1405-0011A VARISTOR
ZD1 T0408-00007A Z DIODE
ZD2 T0408-00006A Z DIODE
ZD3 T0408-00008A Z DIODE
ZD4 T0408-00007A Z DIODE
ZD5 T0408-00005A Z DIODE
ZD6 T0408-00005A Z DIODE
ZD7 T0408-00005A Z DIODE
ZD8 T0408-00008A Z DIODE
ZD9 T0408-00007A Z DIODE
ZD10 T0408-00006A Z DIODE
 Ref No. Part No. Part Name Description Local
IR201 TA59-00037A IR RECEIVER
Q201 T0507-00001A TRANSISTOR
Q204 T0507-00001A TRANSISTOR
C237 T2203-FC102D C CAPACITOR 1000pF 50V K
R201 2007-000084 C RESISTOR 4.7K Ω 1/16W J
R202 2007-000078 C RESISTOR 1K Ω 1/16W J
R203 2007-000309 C RESISTOR 10 Ω 1/16W J
R204 2007-000081 C RESISTOR 2.7K Ω 1/16W J
R297 2007-000090 C RESISTOR 10K Ω 1/16W J
R298 2007-000090 C RESISTOR 10K Ω 1/16W J
CE201 2401-001495 E CAPACITOR 47uF 16V M
J210 T3711-00034 CONNECTOR
J211 T3711-00034 CONNECTOR
LD201 T0601-00002A LED POWER
 Ref No. Part No. Part Name Description Local
D201 T0407-00004A DIODE
C246 T2203-FC332D C CAPACITOR 3300pF 50V K
C247 T2203-FC332D C CAPACITOR 3300pF 50V K
R205 2007-000122 C RESISTOR 1.2K Ω 1/16W J
R206 2007-000120 C RESISTOR 680
Ω 1/16W J
R207 2007-000124 C RESISTOR 2.2K Ω 1/16W J
R208 2007-000122 C RESISTOR 1.2K
Ω 1/16W J
R209 2007-000120 C RESISTOR 680
Ω 1/16W J
R293 2007-000113 C RESISTOR 33 Ω 1/16W J
L226 T2901-AC002A CHIP BEAD 80
Ω
L227 T2901-AC002A CHIP BEAD 80 Ω
L240 T2901-CC004A CHIP BEAD 500 Ω
J207 T3722-0043A JACK HEADPHONE
J209 T3711-00035 CONNECTOR
S201 T3404-00004A TACT SWITCH POWER
S202 T3404-00004A TACT SWITCH TV/AV
S203 T3404-00004A TACT SWITCH MENU/OK
S204 T3404-00004A TACT SWITCH CH+
S205 T3404-00004A TACT SWITCH CH-
S206 T3404-00004A TACT SWITCH VOL+
S207 T3404-00004A TACT SWITCH VOL-
ZD228 T0408-00002A Z DIODE
ZD229 T0408-00002A Z DIODE
 Ref No. Part No. Part Name Description Local
