3-8(No.YA408)
EXPLODED VIEW PARTS LIST -3 [37 inch models]
Ref.No. Part No. Part Name Description Local
101 LC12817-001A-U JACK COVER
102 LC42532-002A-C STAND BASE UNIT Inc. 102A LT-37DR7BJ,LT-37DR7BJP
102 LC42532-001A-C STAND BASE UNIT Inc. 102A LT-37DR7SJ,LT-37DR7SJP
102A T0176-01 STAND COVER
103 LC42531-001A-C SUPPORT UNIT
104 QYSPSPD5014MA SCREW M5 x 14mm(x4)
105 QYSPSPD5014MA SCREW M5 x 14mm(x4)
106 LC12671-001A-U REAR COVER ASSY
107 QYSBSFG4016MA TAP SCREW M4 x 16mm(x10)
108 LC42446-002A SCREW (x2)
109 QYSBSF3010MA TAP SCREW M3 x 10mm(x5)
110 QAU0420-002 DIGITAL TUNER UNIT
111 WJX0033-001A-E E-COAXIAL ASSY DIGITAL TUNER UNIT-RF SPLITTER
112 WJZ0192-001A-E E-HARNESS ASSY ANALOG UV UA-DIGITAL PL207 PL200
113 QJJ064-100600-E SIN CR C-C WIRE ANALOG S-D-AMP CN00S
114 WJZ0207-001A-E E-HARNESS ASSY SPEAKER
115 QUQL05-5009AA-E FFC WIRE ANALOG CN001-DIGITAL CN001
116 QUQL05-4009AA-E FFC WIRE ANALOG CN002-DIGITAL CN002
117 QJJ009-151010-E SIN CR C-C WIRE DIGITAL CN0DC-DC-DC DC
118 WJJ0692-001A-E E-SI C WIRE C-C DIGITAL ID-DIGITAL TUNER UNIT
119 QQR0490-001 NOISE FILTER (x3)
120 LC42446-001A SCREW
121 LC42340-001B-HK SERVICE COVER
122 LC42446-001A SCREW
123 QNB0036-001 CONN ACCESSORY (x2)
124 QYSPSP3004ZA SCREW M3 x 4mm
125 LC12497-011A-HK SHIELD TERMINAL
126 QJJ009-150710-E SIN CR C-C WIRE ANALOG H-DC-DC H
127 LC12507-005B-0K TUNER BASE
128 LC42446-002A SCREW (x2)
129 LC12506-005B-0K TERMINAL BASE
130 QYSBSF3010MA TAP SCREW M3 x 10mm(x3)
131 QNB0036-001 CONN ACCESSORY (x2)
132 QJJ009-151010-E SIN CR C-C WIRE POWER A-DC-DC 10A
133 QJJ015-043024-E SIN CR C-C WIRE POWER F-D-AMP CN10F
134 QMPN390-170-JC POWER CORD(EK) 1.7m BLACK
135 QQR1211-001 CORE FILTER
136 LC22007-003A-0K POWER CORD HOLDER
137 QQR0490-001 NOISE FILTER (x2)
201 SFL-6222A-U2 D-AMP PWB
202 SFL0D266A-U2 DIGITAL PWB LT-37DR7BJ,LT-37DR7SJ
202 LCA10599-95B DIGITAL PWB LT-37DR7BJP,LT-37DR7SJP
203 SFL-1247A-U2 ANALOG PWB
204 SFL-9153A-U2 DC-DC PWB
205 SFL-9047A-U2 POWER PWB
To Next Page
