(No.YA408)3-43
DC-DC P.W. BOARD ASS'Y (SFL-9153A-U2)
C9553 QECQ1VM-128 E CAPACITOR 1200uF 35V M
C9554 QECR1EM-687Z E CAPACITOR 680uF 25V M
C9555 QECR1EM-687Z E CAPACITOR 680uF 25V M
C9556 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C9557 QTNC1HM-106Z E CAPACITOR 10uF 50V M
C9558 QECR2AM-156Z E CAPACITOR 15uF 100V M
C9559 QEHR1HM-106Z E CAPACITOR 10uF 50V M
C9560 QEHR1HM-107Z E CAPACITOR 100uF 50V M
C9562 NCB11HK-104X C CAPACITOR 0.1uF 50V K
C9563 QEHR1HM-107Z E CAPACITOR 100uF 50V M
R9001 QRZ0111-474 C RESISTOR 470k
Ω
1/2W K
R9002 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R9003 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9004 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R9005 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9006 QRZ9061-8R2 FUSI RESISTOR 8.2
Ω
R9205 QRZ0216-4R7 UNF WW RESISTOR 4.7
Ω
7W K
R9206 NRS12BJ-104W MG RESISTOR 100k
Ω
1/2W J
R9207 QRE121J-101Y C RESISTOR 100
Ω
1/2W J
R9208 NRSA63J-394X MG RESISTOR 390k
Ω
1/16W J
R9209 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R9210 QRZ9046-685Z C RESISTOR 6.8M
Ω
1/2W K
R9212 NRSA63J-470X MG RESISTOR 47
Ω
1/16W J
R9213 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R9214 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9215 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R9216 NRSA63J-471X MG RESISTOR 470
Ω
1/16W J
R9217 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R9219 QRE121J-220Y C RESISTOR 22
Ω
1/2W J
R9230 NRS12BJ-104W MG RESISTOR 100k
Ω
1/2W J
R9502 QRM059J-R22 MP RESISTOR 0.22
Ω
5W J
R9503 NRS181J-474X MG RESISTOR 470k
Ω
1/8W J
R9504 NRS181J-474X MG RESISTOR 470k
Ω
1/8W J
R9505 NRS181J-334X MG RESISTOR 330k
Ω
1/8W J
R9506 NRSA63D-912X MG RESISTOR 9.1k
Ω
1/16W D
R9507 NRS12BJ-223W MG RESISTOR 22k
Ω
1/2W J
R9508 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R9509 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R9510 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R9511 NRS181J-824X MG RESISTOR 820k
Ω
1/8W J
R9512 NRS181J-824X MG RESISTOR 820k
Ω
1/8W J
R9513 NRS181J-824X MG RESISTOR 820k
Ω
1/8W J
R9514 NRSA63D-183X MG RESISTOR 18k
Ω
1/16W D
R9515 NRSA63D-224X MG RESISTOR 220k
Ω
1/16W D
R9516 NRS181J-334X MG RESISTOR 330k
Ω
1/8W J
R9517 NRS181J-334X MG RESISTOR 330k
Ω
1/8W J
R9518 NRS181J-394X MG RESISTOR 390k
Ω
1/8W J
R9519 NRS181J-474X MG RESISTOR 470k
Ω
1/8W J
R9520 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
R9521 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9522 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R9523 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9524 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9525 NRSA63J-824X MG RESISTOR 820k
Ω
1/16W J
R9526 NRS12BJ-102W MG RESISTOR 1k
Ω
1/2W J
R9527 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9528 NRSA63J-224X MG RESISTOR 220k
Ω
1/16W J
R9529 NRS12BJ-101W MG RESISTOR 100
Ω
1/2W J
R9530 NRS12BJ-220W MG RESISTOR 22
Ω
1/2W J
R9531 QRE121J-105Y C RESISTOR 1M
Ω
1/2W J
R9532 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R9533 NRSA02J-180X MG RESISTOR 18
Ω
1/10W J
R9534 QRK126J-271X UNF C RESISTOR 270
Ω
1/2W J
R9535 NRS12BJ-332W MG RESISTOR 3.3k
Ω
1/2W J
R9536 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9537 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R9538 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9539 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9540 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R9541 QRT029J-1R0 MF RESISTOR 1
Ω
2W J
R9542 QRM059J-R22 MP RESISTOR 0.22
Ω
5W J
R9543 NRSA02J-562X MG RESISTOR 5.6k
Ω
1/10W J
R9544 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9545 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
R9547 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9548 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9549 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R9551 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R9552 QRK126J-222X UNF C RESISTOR 2.2k
Ω
1/2W J
R9554 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9555 NRSA02J-103X MG RESISTOR 10k
Ω
1/10W J
R9556 NRSA63D-273X MG RESISTOR 27k
Ω
1/16W D
R9557 NRSA63D-682X MG RESISTOR 6.8k
Ω
1/16W D
R9558 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
R9559 NRSA63D-392X MG RESISTOR 3.9k
Ω
1/16W D
R9560 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R9561 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R9562 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R9563 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
Ref No. Part No. Part Name Description Local
R9564 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R9565 QRT039J-1R2 MF RESISTOR 1.2
Ω
3W J
R9566 QRT039J-1R2 MF RESISTOR 1.2
Ω
3W J
R9567 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9569 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9571 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9572 NRSA02J-562X MG RESISTOR 5.6k
Ω
1/10W J
L9201 QQL26AM-5R6Z CHOKE COIL 5.6uH M
L9501 QQR1662-001 CHOKE COIL
L9502 QQR1513-001 CHOKE COIL
L9552 NQLC8CM-150X COIL 15uH M
L9553 NQL932K-101X COIL 100uH K
T9201 QQS0381-001 SW TRANSF
T9501 QQS0347-002 SW TRANSF
T9502 QQS0347-002 SW TRANSF
CP9201 QMFZ052-2R0-E FUSE 2A AC250V
CP9501 QMFZ043-2R0Z-J1 FUSE 2A AC250V
CP9551 QMFZ034-5R0Z-J1 FUSE 5A 125V
CP9552 QMFZ034-5R0Z-J1 FUSE 5A 125V
F9001 QMF5AD2-6R3-J1 FUSE 6.3A AC250V
K9502 QQR0621-002Z FERRITE BEADS
K9503 QQR0621-002Z FERRITE BEADS
K9551 NQR0499-001X FERRITE BEADS
K9552 NQR0499-002X FERRITE BEADS
K9553 NQR0499-002X FERRITE BEADS
K9554 NQR0499-002X FERRITE BEADS
K9555 NQR0499-002X FERRITE BEADS
K9556 NQR0499-002X FERRITE BEADS
K9557 NQR0499-002X FERRITE BEADS
LF9001 QQR1376-002 LINE FILTER
LF9002 QQR1281-005 LINE FILTER
LF9003 QQR1514-001 LINE FILTER
PC9202 PS2581AL2/QW/-W PHOTO COUPLER
PC9501 PS2581AL2/QW/-W PHOTO COUPLER
PC9502 PS2581AL2/QW/-W PHOTO COUPLER
PC9503 PS2581AL2/QW/-W PHOTO COUPLER
RY9001 QSK0162-001 RELAY
RY9002 QSK0162-001 RELAY
VA9001 QAF0060-621 VARISTOR 620V
Ref No. Part No. Part Name Description Local
IC9601 MP1593DN-X IC
IC9602 MP1593DN-X IC
IC9603 LM393DR-X IC
IC9701 MP1580HS-X IC
IC9751 MM1662GH-X IC
IC9801 MP1593DN-X IC
IC9851 BA09FP-X IC 9V
IC9852 BA12FP-X IC 12V
IC9901 MP1593DN-X IC
Q9601 2SC3928A/QR/-X TRANSISTOR
Q9651 2SC3928A/QR/-X TRANSISTOR
Q9801 2SC3928A/QR/-X TRANSISTOR
Q9901 2SC3928A/QR/-X TRANSISTOR
D9601 EC30HA04-X SB DIODE
D9602 1SS355W-X DIODE
D9603 UDZW3.0B-X Z DIODE
D9604 PTZ6.8B-X Z DIODE
D9605 EC30HA04-X SB DIODE
D9606 EC30HA04-X SB DIODE
D9652 EC30HA04-X SB DIODE
D9653 EC30HA04-X SB DIODE
D9654 PTZ16B-X Z DIODE
D9655 1SS355W-X DIODE
D9681 UDZW9.1B-X Z DIODE
D9682 1SS355W-X DIODE
D9701 EC30HA03L-X SB DIODE
D9702 EC30HA03L-X SB DIODE
D9703 PTZ3.9B-X Z DIODE
D9802 EC30HA04-X SB DIODE
D9803 1SS355W-X DIODE
D9804 PTZ6.8B-X Z DIODE
D9901 EC30HA04-X SB DIODE
D9902 EC30HA04-X SB DIODE
D9903 1SS355W-X DIODE
C9601 NCJ41HK-335X-U C CAPACITOR 3.3uF 50V K
C9603 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9604 NCJ41CM-226X-M C CAPACITOR 22uF 16V M
C9605 NCJ41CM-226X-M C CAPACITOR 22uF 16V M
Ref No. Part No. Part Name Description Local
