IMPORTANT PREPARE USE SETTING TROUBLE?
ENGLISH
z A Conditional Access Module for watching pay-TV digital channels can be installed. (P. 8)
z DC power can be supplied to the indoor aerial. (P. 61)
z We may change the design and specifications without notice.
Main unit
Model LT-42DP8BG LT-37DP8BG LT-32DP8BG
Broadcasting systems CCIR I / B / G / D / K / L (See “Technical Information”, P. 61)
Colour systems
TV broadcast: PAL, SECAM
External input: PAL, SECAM, NTSC 3.58/4.43 MHz
Channels and frequencies
z Digital:
Frequency: 174-230 MHz / 470-862 MHz
z Analogue:
E2-E12 / E21-E69, F2-F10 / F21-F69, IR A-IR J, ITALY A-H / H+1 / H+2,
R1-R12 / R21-R69, S1-S41, X / Y / Z / Z+1 / Z+2,
French cable channels (Frequency: 116-172 MHz / 220-469 MHz)
Sound-multiplex systems NICAM (I / B / G / D / K / L), A2 (B / G / D / K)
Teletext systems
Digital: EBU TEXT
Analogue: FLOF (Fastext), TOP, WST (standard system)
Power requirements AC 220 V - 240 V, 50 Hz
Audio output (Rated power output)
10 W + 10 W
Speakers (5.5 cm x 20 cm) oval x 2 (5.5 cm x 15 cm) oval x 2 (5.5 cm x 15 cm) oval x 2
Power consumption
[standby]
220 W
[0.5 W]
164 W
[0.5 W]
156 W
[1.0 W]
Screen size
(visible area size measured
diagonally)
105 cm 94 cm 80 cm
Dimensions (W x H x D: mm)
[without stand]
1030 x 719.2 x 296
[1030 x 672 x 122.4]
919 x 654.2 x 230
[919 x 603.8 x 124.1]
800 x 595.4 x 230
[800 x 545 x 115.4]
Weights
[without stand]
28.5 kg
[26.4 kg]
20.3 kg
[18.8 kg]
16.6 kg
[15.1 kg]
Accessories (See “Check accessories”, P. 5)
Terminals / Connectors
Terminal name Terminal type Signal type (IN)
Signal type
(OUT)
Notes
Input /
Output
terminals
EXT-1
Euroconnector x 1
(SCART connector)
Composite video, S-Video,
Analogue RGB
Audio L / R
TV out
EXT-2
Euroconnector x 1
(SCART connector)
Composite video, S-Video,
Analogue RGB
Audio L / R
Dubbing out
“T-V LINK”
compatible
Input
terminals
EXT-3
RCA connectors x 3,
S-VIDEO connector x 1
Composite video, S-Video
Audio L / R
EXT-4 RCA connectors x 5
Analogue component
(576i (625i) / 480i (525i),
Progressive: 576p (625p) /
480p (525p),
HD: 1080i (1125i), 720p (750p))
Audio L / R
EXT-5
(HDMI-1)
HDMI connector x 2
HDMI
(576i (625i) / 480i (525i) /
576p (625p) / 480p (525p),
1080i (1125i), 720p (750p))
“HDMI CEC”
compatible
(P. 63)
EXT-6
(HDMI-2)
PC IN D-SUB (15 pins) x 1 Analogue PC signal (P. 61)
Output
terminals
AUDIO OUT RCA connectors x 2 Audio L / R
DIGITAL
AUDIO OUT
OPTICAL connector x1
Digital audio
(48 kHz, 16 bit
linear PCM /
Dolby Digital)
Headphone
Stereo mini-jack x 1
(3.5 mm in diameter)
Headphone
output
Specifications
