3-6(No.YA422)
EXPLODED VIEW PARTS LIST -2
Ref.No. Part No. Part Name Description Local
151 QLD0372-002-JMT LCD PANEL UNIT
152 WJW0041-003A-E DIGITAL (LVDS) CABLE DIGITAL CN0LV2-LCD PANEL UNIT
153 WJZ0203-001A-E E-HARNESS ASSY MAN POWER P-LCD PANEL UNIT
154 QQR0490-001 NOISE FILTER LT-Z40SX6A,LT-Z40SX6S
155 LC41913-006A-C SPEAKER ASSY LEFT
156 LC40226-005A-H SPACER (x6)
157 LC41913-005A-C SPEAKER ASSY RIGHT
158 LC41458-002A TAPPING SCREW (x6)
159 LC33125-001B-H LED LENS
160 LC12197-007A-0K FRONT PANEL ASSY
161 WJZ0180-001A-E E-HARNESS ASSY SUB POWER F-D-AMP CN10F
207 SFL-9709A-H2 SUB POWER PWB
208 SFL-8709A-H2 LED PWB
To Next Page
