(No.YA422)3-11
D-AMP P.W. BOARD ASS'Y (SFL-6231A-H2)
R625 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R626 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R634 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R635 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R636 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R638 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R639 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R640 NRSA63J-821X MG RESISTOR 820
Ω
1/16W J
R642 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R644 NRSA63J-392X MG RESISTOR 3.9k
Ω
1/16W J
R645 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R647 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R649 NRSA63J-683X MG RESISTOR 68k
Ω
1/16W J
R650 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R651 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R652 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R653 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
R654 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R661 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R662 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R665 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R666 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R669 NRSA63J-105X MG RESISTOR 1M
Ω
1/16W J
R670 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R671 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R687 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R688 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R689 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R690 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R694 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R695 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R696 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R700 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R701 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R702 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R703 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R704 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R711 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R712 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R713 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R714 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R718 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R719 NRSA63J-563X MG RESISTOR 56k
Ω
1/16W J
R720 NRSA63J-153X MG RESISTOR 15k
Ω
1/16W J
R723 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R751 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R752 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R755 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R756 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R757 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R758 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R759 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R760 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R761 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R764 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R765 NRSA63J-220X MG RESISTOR 22
Ω
1/16W J
R768 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R769 NRSA63J-220X MG RESISTOR 22
Ω
1/16W J
R3006 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3007 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3008 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R3009 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R3010 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3011 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3014 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3015 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3016 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3504 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R3505 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R3506 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R3508 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3511 NRSA63J-222X MG RESISTOR 2.2k
Ω
1/16W J
R3512 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3514 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3515 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3516 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3517 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3518 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R3519 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R3520 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3521 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
R3546 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R3547 NRSA63J-681X MG RESISTOR 680
Ω
1/16W J
R3551 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R3552 NRSA63J-333X MG RESISTOR 33k
Ω
1/16W J
R3553 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R3554 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R3555 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R3556 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
R3557 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
Ref No. Part No. Part Name Description Local
R3558 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
R3559 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R3560 NRSA63J-272X MG RESISTOR 2.7k
Ω
1/16W J
R3561 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R3562 NRSA63J-221X MG RESISTOR 220
Ω
1/16W J
R3563 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R3564 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
L101 NQL79GM-100X COIL 10uH M
L902 NQL52EM-220X COIL 22uH M
L903 NQR0562-010X CHOKE COIL
L906 NQL52EM-220X COIL 22uH M
L3002 NQL79GM-100X COIL 10uH M
L3003 NQL79GM-220X COIL 22uH M
L3502 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L3503 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L3504 NQL79GM-4R7X COIL 4.7uH M
L3506 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L3507 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L3508 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
CN001 QGF0508C2-50W CONNECTOR FFC/FPC (1-50)
CN002 QGF0508C2-40W CONNECTOR FFC/FPC (1-40)
J401 QNZ0726-001 AV JACK VIDEO-1(S/V/L/R)
J402 QNN0650-001 PIN JACK
VIDEO-1(COMPONENT)
J403 QNZ0726-001 AV JACK VIDEO-2(S/V/L/R)
J405 QNN0651-001 PIN JACK VIDEO-3(V/L/R)
J406 QNN0650-001 PIN JACK
VIDEO-3(COMPONENT)
J407 QNN0652-001 PIN JACK IN(HDMI-1)
J408 QNZ0726-001 AV JACK OUT(S/V/L/R)
J410 QNZ0561-001 D CONNECTOR PC IN
K661 NQR0499-002X FERRITE BEADS
K3501 NQR0389-003X FERRITE BEADS
K3502 NQR0389-003X FERRITE BEADS
LC3501 NQR0431-001X EMI FILTER 0.22uF 50V Z
TU3001 QAU0390-001 TUNER
X661 NAX0857-001X C RESONATOR 25.00MHz
X3501 QAX0773-001Z CRYSTAL 18.432000MHz
Ref No. Part No. Part Name Description Local
IC6201 PQ20WZ11-X IC
IC6501 RC4558D-X IC
IC6621 LM393DR-X IC
IC6661 TDA8928ST/N1 IC
Q6611 2SC3928A/QR/-X TRANSISTOR
Q6612 2SC3928A/QR/-X TRANSISTOR
Q6613 2SA1530A/QR/-X TRANSISTOR
Q6661 UN2112-X DIGI TRANSISTOR
Q6662 2SC3928A/QR/-X TRANSISTOR
Q6663 UN2212-X DIGI TRANSISTOR
D6201 1SS355W-X SI DIODE
D6501 UDZW6.2B-X Z DIODE
D6663 UDZW3.3B-X Z DIODE
D6664 1SS355W-X SI DIODE
D6671 UDZW20B-X Z DIODE
D6672 UDZW20B-X Z DIODE
D6673 UDZW20B-X Z DIODE
D6674 UDZW20B-X Z DIODE
C6201 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C6202 NEHL1EM-336X E CAPACITOR 33uF 25V M
C6203 NEHL1EM-336X E CAPACITOR 33uF 25V M
C6204 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C6205 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C6501 NENA1CM-475X BP E CAPACITOR 4.7uF 16V M
C6502 NENA1CM-475X BP E CAPACITOR 4.7uF 16V M
C6503 NDC31HJ-100X C CAPACITOR 10pF 50V J
C6504 NDC31HJ-100X C CAPACITOR 10pF 50V J
C6505 NEHL1CM-476X E CAPACITOR 47uF 16V M
C6506 NEHL1CM-476X E CAPACITOR 47uF 16V M
C6507 NEHL1HM-105X E CAPACITOR 1uF 50V M
C6508 NEHL1HM-105X E CAPACITOR 1uF 50V M
C6601 NDC31HJ-101X C CAPACITOR 100pF 50V J
C6602 NDC31HJ-101X C CAPACITOR 100pF 50V J
C6611 NEHL0JM-226X E CAPACITOR 22uF 6.3V M
C6621 NCB31HK-332X C CAPACITOR 3300pF 50V K
C6622 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C6623 NEHL1EM-226X E CAPACITOR 22uF 25V M
C6624 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6625 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C6626 NCB31HK-222X C CAPACITOR 2200pF 50V K
C6627 NCB31HK-104X C CAPACITOR 0.1uF 50V K
Ref No. Part No. Part Name Description Local
