3-14(No.YA422)
DC-DC P.W. BOARD ASS'Y (SFL-9148A-H2)
SUB POWER P.W. BOARD ASS'Y (SFL-9709A-H2)
R9568 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9570 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R9571 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9572 NRSA02J-562X MG RESISTOR 5.6k
Ω
1/10W J
R9574 NRSA63J-473X MG RESISTOR 47k
Ω
1/16W J
R9575 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L9201 QQL26AM-5R6Z CHOKE COIL 5.6uH M
L9501 QQR1662-001 CHOKE COIL
L9502 QQR1513-001 CHOKE COIL
T9201 QQS0381-001 SW TRANSF
T9501 QQS0347-003 SW TRANSF
T9502 QQS0347-003 SW TRANSF
CP9201 QMFZ052-2R0-E FUSE 2A AC250V
CP9501 QMFZ043-2R0Z-J1 FUSE 2A AC250V
F9001 QMF5AD2-6R3-J1 FUSE 6.3A AC250V
K9502 QQR0621-002Z FERRITE BEADS
K9503 QQR0621-002Z FERRITE BEADS
K9552 NQR0499-002X FERRITE BEADS
K9553 NQR0499-002X FERRITE BEADS
K9554 NQR0499-002X FERRITE BEADS
K9555 NQR0499-002X FERRITE BEADS
K9556 NQR0499-002X FERRITE BEADS
K9557 NQR0499-002X FERRITE BEADS
LF9001 QQR1655-001 LINE FILTER
LF9002 QQR1281-005 LINE FILTER
LF9003 QQR1654-001 LINE FILTER
PC9202 PS2581AL2/QW/-W PHOTO COUPLER
PC9501 PS2581AL2/QW/-W PHOTO COUPLER
PC9502 PS2581AL2/QW/-W PHOTO COUPLER
PC9503 PS2581AL2/QW/-W PHOTO COUPLER
RY9001 QSK0162-001 RELAY
RY9002 QSK0162-001 RELAY
VA9001 QAF0028-621 VARISTOR 620V
Ref No. Part No. Part Name Description Local
IC9601 MP1593DN-X IC
IC9602 MP1593DN-X IC
IC9603 LM393DR-X IC
IC9851 BA09FP-X IC
Q9601 2SC3928A/QR/-X TRANSISTOR
Q9651 2SC3928A/QR/-X TRANSISTOR
D9601 EC30HA04-X SB DIODE
D9602 1SS355W-X SI DIODE
D9603 UDZW3.0B-X Z DIODE
D9604 PTZ6.8B-X Z DIODE
D9605 EC30HA04-X SB DIODE
D9606 EC30HA04-X SB DIODE
D9652 EC30HA04-X SB DIODE
D9653 EC30HA04-X SB DIODE
D9654 PTZ6.8B-X Z DIODE
D9655 1SS355W-X SI DIODE
D9681 UDZW9.1B-X Z DIODE
D9682 1SS355W-X SI DIODE
C9601 NCJ41HK-335X-U C CAPACITOR 3.3uF 50V K
C9603 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9604 NCJ41CM-226X-M C CAPACITOR 22uF 16V M
C9605 NCJ41CM-226X-M C CAPACITOR 22uF 16V M
C9606 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9607 NCB31HK-222X C CAPACITOR 2200pF 50V K
C9608 NCB31HK-332X C CAPACITOR 3300pF 50V K
C9610 NEHM1HM-105X E CAPACITOR 1uF 50V M
C9651 NCJ41HK-335X-U C CAPACITOR 3.3uF 50V K
C9652 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9654 NCJ41CM-226X-M C CAPACITOR 22uF 16V M
C9655 NCJ41CM-226X-M C CAPACITOR 22uF 16V M
C9656 NCB31HK-104X C CAPACITOR 0.1uF 50V K
C9657 NDC31HJ-101X C CAPACITOR 100pF 50V J
C9658 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C9660 NBZ0008-107X SP E CAPACITOR 100uF 6.3V M
C9681 NEHM1HM-105X E CAPACITOR 1uF 50V M
C9682 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C9683 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C9684 NCB31EK-104X C CAPACITOR 0.1uF 25V K
C9851 NEHM1EM-336X E CAPACITOR 33uF 25V M
C9852 NEHM1EM-336X E CAPACITOR 33uF 25V M
R9601 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R9602 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R9603 NRSA63J-562X MG RESISTOR 5.6k
Ω
1/16W J
Ref No. Part No. Part Name Description Local
R9604 NRVA02D-473X CMF RESISTOR 47k
Ω
1/10W D
R9605 NRSA63D-104X MG RESISTOR 100k
Ω
1/16W D
R9606 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R9607 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R9608 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R9609 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R9610 NRSA63J-223X MG RESISTOR 22k
Ω
1/16W J
R9651 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R9652 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R9653 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
R9654 NRSA63D-473X MG RESISTOR 47k
Ω
1/16W D
R9655 NRSA63D-104X MG RESISTOR 100k
Ω
1/16W D
R9656 NRSA63D-103X MG RESISTOR 10k
Ω
1/16W D
R9657 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R9658 NRSA63J-182X MG RESISTOR 1.8k
Ω
1/16W J
R9659 NRSA63J-183X MG RESISTOR 18k
Ω
1/16W J
R9660 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R9661 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R9663 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R9681 NRS12BJ-332W MG RESISTOR 3.3k
Ω
1/2W J
R9682 NRSA63D-472X MG RESISTOR 4.7k
Ω
1/16W D
R9683 NRSA63J-682X MG RESISTOR 6.8k
Ω
1/16W J
R9684 NRSA63D-472X MG RESISTOR 4.7k
Ω
1/16W D
R9685 NRSA63D-273X MG RESISTOR 27k
Ω
1/16W D
R9686 NRSA63D-472X MG RESISTOR 4.7k
Ω
1/16W D
R9901 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
R9924 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
L9602 NQLC8CM-150X COIL 15uH M
L9652 NQLC8CM-150X COIL 15uH M
L9653 NQR0562-003X CHOKE COIL
Ref No. Part No. Part Name Description Local
IC9001 STR-W6765-F5 SW IC
IC9051 TL431/A/-T IC
D9001 MTZJ33B-T2 Z DIODE
D9004 FR105GT-T3 SI DIODE
D9005 1SS133-T2 SI DIODE
D9006 FR105GT-T3 SI DIODE
D9008 SARS01-T2 FR DIODE
D9009 SARS01-T2 FR DIODE
D9011 1SS133-T2 SI DIODE
D9021 D2SBA60 BRIDGE DIODE
D9022 FR105GT-T3 SI DIODE
D9023 1SS133-T2 SI DIODE
D9051 RU3AM-LFC4 SI DIODE
D9053 FMX-22S SI DIODE
D9054 FR105GT-T3 SI DIODE
D9055 MTZJ33B-T2 Z DIODE
D9056 RK16-T3 SB DIODE
D9071 RU3AM-LFC4 SI DIODE
C9001 QEZ0199-127 E CAPACITOR 120uF 400V M
C9002 QFP32JK-332 PP CAPACITOR 3300pF 630V K
C9003 QCZ0354-471Z C CAPACITOR 470pF 2kV K
C9004 QCS31HJ-471Z C CAPACITOR 470pF 50V J
C9006 QCB31HK-821Z C CAPACITOR 820pF 50V K
C9008 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C9010 QEHR1HM-335Z E CAPACITOR 3.3uF 50V M
C9011 QEHR1HM-226Z E CAPACITOR 22uF 50V M
C9012 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C9024 QFZ9075-224 MPP CAPACITOR 0.22uF AC275V M
C9051 QECR1EM-687Z E CAPACITOR 680uF 25V M
C9054 QECQ1EM-188 E CAPACITOR 1800uF 25V M
C9055 QEHR2AM-106Z E CAPACITOR 10uF 100V M
C9057 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C9060 QECQ1EM-188 E CAPACITOR 1800uF 25V M
C9061 QECQ1CM-128 E CAPACITOR 1200uF 16V M
C9072 QECR1EM-687Z E CAPACITOR 680uF 25V M
C9073 QEHR1HM-105Z E CAPACITOR 1uF 50V M
C9076 QEHR1HM-106Z E CAPACITOR 10uF 50V M
C9078 QFLC1HJ-222Z M CAPACITOR 2200pF 50V J
C9903 QCZ9071-102 C CAPACITOR 1000pF AC400V M
R9001 QRK126J-221X UNF C RESISTOR 220
Ω
1/2W J
R9002 QRT01EJ-R39X MF RESISTOR 0.39
Ω
1W J
R9003 QRT01EJ-R82X MF RESISTOR 0.82
Ω
1W J
R9004 QRL02EJ-473X OMF RESISTOR 47k
Ω
2W J
R9006 QRE121J-102Y C RESISTOR 1k
Ω
1/2W J
R9008 QRE121J-564Y C RESISTOR 560k
Ω
1/2W J
R9009 QRL03EJ-220X OMF RESISTOR 22
Ω
3W J
R9010 QRE121J-151Y C RESISTOR 150
Ω
1/2W J
R9011 QRE141J-332Y C RESISTOR 3.3k
Ω
1/4W J
Ref No. Part No. Part Name Description Local
