JVC MX-JD5 User Manual

3-18
Front board
Block No. [0][3]
TW400 QUB230-06A4A4 WIRE
TW444 QUB230-12HPHP S.WIRE
X510 QAX0768-001Z C OSCILLATOR
X801 QAX0724-001Z CRYSTAL 12.000000MHz
 Symbol No. Part No. Part Name Description Local
IC900 SN74HCU04N FL DRIVER
IC920 PT6305 FL DRIVER
IC930 GP1UM281XK IR DETECT UNIT 38kHz
IC970 BU9253AS IC
JD5U
N,JD5
US,JD
5UX
IC971 RC4580IP IC
JD5U
N,JD5
US,JD
5UX
Q926 KRA102M-T DIGI TRANSISTOR
Q933 KRC102M-T DIGI TRANSISTOR
Q934 KRC102M-T DIGI TRANSISTOR
Q935 KRC102M-T DIGI TRANSISTOR
Q936 KRC102M-T DIGI TRANSISTOR
Q937 KRC102M-T DIGI TRANSISTOR
Q938 KRC102M-T DIGI TRANSISTOR
Q980 KRA111M-T DIGI TRANSISTOR
JD5U
N,JD5
US,JD
5UX
Q981 KRA111M-T DIGI TRANSISTOR
JD5U
N,JD5
US,JD
5UX
Q982 KRA111M-T DIGI TRANSISTOR
JD5U
N,JD5
US,JD
5UX
Q987 2SC3576-JVC-T TRANSISTOR
JD5U
N,JD5
US,JD
5UX
 Q2010 KTC2026/OY/ TRANSISTOR
Q2011 KTC3199/GL/-T TRANSISTOR
D925 SLA-362LT-T LED
D926 SLI-343URC3F LED
D933 SLA-362LT-T LED
D934 SLA-362LT-T LED
D935 SLA-362LT-T LED
D936 SLA-362LT-T LED
D937 SLA-362LT-T LED
D938 SLA-362LT-T LED
D957 1SS133-T2 DIODE
JD5U
E,JD5
UW
D958 1SS133-T2 DIODE
JD5U
E,JD5
UW
D971 MTZJ5.1B-T2 Z DIODE
JD5U
N,JD5
US,JD
5UX
D991 MTZJ2.4B-T2 Z DIODE
JD5U
N,JD5
US,JD
5UX
D992 1SS133-T2 DIODE
JD5U
N,JD5
US,JD
5UX
 D2010 1N5402M-20 DIODE
 D2011 1N5402M-20 DIODE
 D2012 1N5402M-20 DIODE
 D2013 1N5402M-20 DIODE
 Symbol No. Part No. Part Name Description Local
D2015 1N4003S-T5 SI DIODE
D2016 1N4003S-T5 SI DIODE
D2017 1N4003S-T5 SI DIODE
D2018 MTZJ20B-T2 Z DIODE
D2019 MTZJ18B-T2 Z DIODE
D2020 MTZJ6.8B-T2 Z DIODE
C903 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C904 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C905 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C920 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C921 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C922 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C923 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C924 QEKC1HM-226Z E CAPACITOR 22uF 50V M
C925 QETN1HM-226Z E CAPACITOR 22uF 50V M
C926 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C930 QETN1HM-106Z E CAPACITOR 10uF 50V M
C931 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C957 QCBB1HK-222Y C CAPACITOR 2200pF 50V K
JD5U
E,JD5
UW
C970 QCBB1HK-101Y C CAPACITOR 100pF 50V K
JD5U
N,JD5
US,JD
5UX
C971 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
JD5U
N,JD5
US,JD
5UX
C972 QETN1CM-107Z E CAPACITOR 100uF 16V M
JD5U
N,JD5
US,JD
5UX
C973 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
JD5U
N,JD5
US,JD
5UX
C974 QDXB1CM-472Y C CAPACITOR 4700pF 16V M
JD5U
N,JD5
US,JD
5UX
C975 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
JD5U
N,JD5
US,JD
5UX
C976 QEKC1CM-226Z E CAPACITOR 22uF 16V M
JD5U
N,JD5
US,JD
5UX
C977 QEKC1HM-474Z E CAPACITOR 0.47uF 50V M
JD5U
N,JD5
US,JD
5UX
C978 QDXB1CM-332Y C CAPACITOR 3300pF 16V M
JD5U
N,JD5
US,JD
5UX
C979 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
JD5U
N,JD5
US,JD
5UX
C980 QEKC1HM-475Z E CAPACITOR 4.7uF 50V M
JD5U
N,JD5
US,JD
5UX
C981 QEKC1HM-224Z E CAPACITOR 0.22uF 50V M
JD5U
N,JD5
US,JD
5UX
C982 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
JD5U
N,JD5
US,JD
5UX
C983 QCBB1HK-151Y C CAPACITOR 150pF 50V K
JD5U
N,JD5
US,JD
5UX
C984 QCBB1HK-331Y C CAPACITOR 330pF 50V K
JD5U
N,JD5
US,JD
5UX
 Symbol No. Part No. Part Name Description Local
