Pin No. Pin Name Note Equivalent Circuit Description
16 V
CC
V = V
CC
V
CC
pin
21 RECOUT(L)
10 RECOUT(R)
REC output
26 PBOUT(L)
5 PBOUT(R)
V = V
CC
/2
PB output
28 EQOUT(L)
3 EQOUT(R)
V = 2.9 V
V
CC
GND
EQ output
35 REC-RETURN REC Return
34 BIN(L)
37 BIN(R)
V = 0 V
PB-NF
BIN
REC Return
V
CC
120 k
PB B deck input
32 AIN(L)
39 AIN(R)
V = 0 V
PB-NF
AIN
GND
V
CC
120 k
PB A deck input
24 RECIN(L)
7RECIN(R)
V = V
CC
/2 REC-EQ input
27 TAI(L)
4TAI(R)
V = V
CC
/2
V
CC
/2
V
CC
100 k
Tape input
 Pin Description, Equivalent Circuit
(VCC = 12V, Ta = 25˚C, No Signal, The value in the table shows typical value.)
