JVC MX-KC4 Service Manual

1-24 (No.MB350)
3.2.3 Removing the main speaker
(See Fig.4)
• Prior to performing the following procedure, remove the front
cabinet.
(1) Remove the four screws V attaching the main speaker.
If necessary, disconnect the wire connected to the sub
speaker terminal and the speaker.
Fig.4
Main speaker
Speaker wire
VV
