3-19
D601 1N4003 DIODE BI31N4003LEM000
D602 1N4003 DIODE BI31N4003LEM000
D603 1N4003 DIODE BI31N4003LEM000
D605 1N4003 DIODE BI31N4003LEM000
D606 1N4003 DIODE BI31N4003LEM000
D607 UZ12BSC Z DIODE
BI3UZ12BSCM000
V
D609 UZ30BSD Z DIODE
BI3UZ30BSDM000
0
D610 UZ6.2BSB Z DIODE BI3UZ6.2BSBM000
D611 UZ5.6BSB Z DIODE BI3UZ5.6BSBM000
D613 1N4003 DIODE BI31N4003LEM000
D614 RS402M SELEN RECTIFIER BI3RS402M1
D615 GBU6J DIODE BI3GBU6J1V
D616 UZ12BSC Z DIODE
BI3UZ12BSCM000
V
D617 UZ12BSC Z DIODE
BI3UZ12BSCM000
V
D618 1SS133 FR DIODE
BI31SS133M000V
7
D619 1SS133 FR DIODE
BI31SS133M000V
7
D620 1SS133 FR DIODE
BI31SS133M000V
7
D621 1SS133 FR DIODE
BI31SS133M000V
7
D622 1SS133 FR DIODE
BI31SS133M000V
7
D623 1SS133 FR DIODE
BI31SS133M000V
7
D624 1SS133 FR DIODE
BI31SS133M000V
7
D625 1SS133 FR DIODE
BI31SS133M000V
7
D626 1SS133 FR DIODE
BI31SS133M000V
7
D631 1SS133 FR DIODE
BI31SS133M000V
7
C101 BICE108250MP01 E CAPACITOR 1000uF 25V
C102 BICE107100MP01 E CAPACITOR 100uF 10V
C113 BICE107100MP01 E CAPACITOR 100uF 10V
C114 BICE105500MP01 E CAPACITOR 1uF 50V
C115 BICE476160MP01 E CAPACITOR 47uF 16V
C116 BICE107160MP01 E CAPACITOR 100uF 16V
C117 BICE107160MP01 E CAPACITOR 100uF 16V
C118 BICE107160MP01 E CAPACITOR 100uF 16V
C601 BICC104250ZA04 C CAPACITOR 0.1uF 25V
C602 BICC104250ZA04 C CAPACITOR 0.1uF 25V
C603 BICC104250ZA04 C CAPACITOR 0.1uF 25V
C604 BICC104250ZA04 C CAPACITOR 0.1uF 25V
C605 BICE47825M0 E CAPACITOR 4700uF 25V
C606 BICE105500MP01 E CAPACITOR 1uF 50V
C607 BICE107250MP01 E CAPACITOR 100uF 25V
C608 BICC104250ZA04 C CAPACITOR 0.1uF 25V
C609 BICE107160MP01 E CAPACITOR 100uF 16V
C610 BICE476630MP01 E CAPACITOR 47uF 63V
C611 BICE226500MP01 E CAPACITOR 22uF 50V
C612 BICC103500KA04 C CAPACITOR 0.01uF 50V
C613 BICE226500MP01 E CAPACITOR 22uF 50V
C614 BICE106250MP01 E CAPACITOR 10uF 25V
C615 BICC103500KA04 C CAPACITOR 0.01uF 50V
C616 BICE477100MP01 E CAPACITOR 470uF 10V
C617 BICM682101KP01 M CAPACITOR 6800pF 100V
C618 BICM682101KP01 M CAPACITOR 6800pF 100V
C619 BICM682101KP01 M CAPACITOR 6800pF 100V
C620 BICM682101KP01 M CAPACITOR 6800pF 100V
C621 BICM682101KP01 M CAPACITOR 6800pF 100V
C622 BICM682101KP01 M CAPACITOR 6800pF 100V
C623 BICE47850MSNY3 E CAPACITOR 4700uF 50V
C624 BICE47850MSNY3 E CAPACITOR 4700uF 50V
C625 BICE33871M2Y E CAPACITOR 3300uF 71V
C626 BICE33871M2Y E CAPACITOR 3300uF 71V
C627 BICM682101KP01 M CAPACITOR 6800pF 100V
C628 BICM682101KP01 M CAPACITOR 6800pF 100V
C631 BICE107101MP01 E CAPACITOR 100uF 100V
C632 BICE107101MP01 E CAPACITOR 100uF 100V
C633 BICC101500JA04 C CAPACITOR 100pF 50V
C634 BICC101500JA04 C CAPACITOR 100pF 50V
Symbol
No.
Part No. Part Name Description Local
C635 BICE107100MP01 E CAPACITOR 100uF 10V
C636 BICE107100MP01 E CAPACITOR 100uF 10V
C637 BICC030500CA04 C CAPACITOR 3pF 50V
C638 BICC030500CA04 C CAPACITOR 3pF 50V
C639 BICC102500JA04 C CAPACITOR 1000pF 50V
C640 BICC102500JA04 C CAPACITOR 1000pF 50V
C641 BICE475500MP01 E CAPACITOR 4.7uF 50V
C642 BICE475500MP01 E CAPACITOR 4.7uF 50V
C643 BICE475500MP01 E CAPACITOR 4.7uF 50V
C644 BICE105500MP01 E CAPACITOR 1uF 50V
C645 BICM104101KP01 M CAPACITOR 0.1uF 100V
C646 BICM104101KP01 M CAPACITOR 0.1uF 100V
C647 BICM104101KP01 M CAPACITOR 0.1uF 100V
C648 BICM104101KP01 M CAPACITOR 0.1uF 100V
C649 BICC121500JA04 C CAPACITOR 120pF 50V
C650 BICE476160MP01 E CAPACITOR 47uF 16V
C651 BICC223500KA04 C CAPACITOR 0.022uF 50V
C652 BICE226500MP01 E CAPACITOR 22uF 50V
C653 BICE227100MP01 E CAPACITOR 220uF 10V
C654 BICE106250MP01 E CAPACITOR 10uF 25V
C655 BICC153500KA04 C CAPACITOR 0.015uF 50V
C656 BICC153500KA04 C CAPACITOR 0.015uF 50V
R101 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R102 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R103 BIRC2230105A00 C RESISTOR 22K
Ω
1/10W
R104 BIRC2230105A00 C RESISTOR 22K
Ω
1/10W
R110 BIRC0220105A00 C RESISTOR 2.2
Ω
1/10W
R112 BIRC4710105A00 C RESISTOR 470
Ω
1/10W
R113 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R114 BIRC5600105A00 C RESISTOR 56
Ω
1/10W
R115 BIRC2240105A00 C RESISTOR 220K
Ω
1/10W
R116 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R117 BIRC4710105A00 C RESISTOR 470
Ω
1/10W
R118 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R119 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R120 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R121 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R123 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R124 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R600 BIRC8210105A00 C RESISTOR 820
Ω
1/10W
R601 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R602 BIRC5600105A00 C RESISTOR 56
Ω
1/10W
R605 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R606 BIRC3320105A00 C RESISTOR 3.3K
Ω
1/10W
R607 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R608 BIRC1010085N00 C RESISTOR 100
Ω
1/8W
R609 BIRC1010085N00 C RESISTOR 100
Ω
1/8W
R610 BIRC1540105A00 C RESISTOR 150K
Ω
1/10W
R611 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R612 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R613 BIRF1010025N00 FUSE RESISTOR 100
Ω
1/2W
R614 BIRF1010025N00 FUSE RESISTOR 100
Ω
1/2W
R615 BIRC1520025N00 C RESISTOR 1.5K
Ω
1/2W
R616 BIRC1520025N00 C RESISTOR 1.5K
Ω
1/2W
R617 BIRC5610105A00 C RESISTOR 560
Ω
1/10W
R618 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R619 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R620 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R621 BIRC5610105A00 C RESISTOR 560
Ω
1/10W
R622 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R623 BIRC3330105A00 C RESISTOR 33K
Ω
1/10W
R624 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R625 BIRC5630105A00 C RESISTOR 56K
Ω
1/10W
R626 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R627 BIRC4720105A00 C RESISTOR 4.7K
Ω
1/10W
R628 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R629 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R630 BIRC3920105A00 C RESISTOR 3.9K
Ω
1/10W
R631 BIRC3920105A00 C RESISTOR 3.9K
Ω
1/10W
R632 BIRM001530V M RESISTOR 0.15
Ω
3W
R633 BIRM001530V M RESISTOR 0.15
Ω
3W
R634 BIRM001530V M RESISTOR 0.15
Ω
3W
R635 BIRM001530V M RESISTOR 0.15
Ω
3W
R636 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R637 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R638 BIRC1530105A00 C RESISTOR 15K
Ω
1/10W
Symbol
No.
Part No. Part Name Description Local
