3-20
Power trans board (MX-KC45A)
Block No. [0][8]
Main board
(MX-KC45UW,MX-KC45UY.MX-KC45UJ)
Block No. [0][9]
R639 BIRC1530105A00 C RESISTOR 15K
Ω
1/10W
R640 BIRC0470045N00 C RESISTOR 4.7
Ω
1/4W
R641 BIRC0470045N00 C RESISTOR 4.7
Ω
1/4W
R642 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R643 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R644 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R645 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R646 BIRC4710105A00 C RESISTOR 470
Ω
1/10W
R647 BIRC4740105A00 C RESISTOR 470K
Ω
1/10W
R648 BIRC0470045N00 C RESISTOR 4.7
Ω
1/4W
R649 BIRC0470045N00 C RESISTOR 4.7
Ω
1/4W
R650 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R651 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R652 BIRC1040105A00 C RESISTOR 100K
Ω
1/10W
R653 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R654 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R655 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R656 BIRC1500085M00 C RESISTOR 15
Ω
1/8W
R657 BIRC6840105A00 C RESISTOR 680K
Ω
1/10W
R658 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
R659 BIRC2220105A00 C RESISTOR 2.2K
Ω
1/10W
R660 BIRC3920105A00 C RESISTOR 3.9K
Ω
1/10W
R661 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R662 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R663 BIRC1030105A00 C RESISTOR 10K
Ω
1/10W
R664 BIRC1020105A00 C RESISTOR 1K
Ω
1/10W
R665 BIRM1020N25N00 M RESISTOR 1K
Ω
2W
R666 BIRM1020N25N00 M RESISTOR 1K
Ω
2W
R669 BIRC1220105A00 C RESISTOR 1.2K
Ω
1/10W
R671 BIRC1030085M00 C RESISTOR 10K
Ω
1/8W J
R672 BIRC3300045M00 C RESISTOR 33
Ω
1/4W
R679 BIRC0000105A00 C RESISTOR 0
Ω
1/10W
R681 BIRC3330085M00 C RESISTOR 33K
Ω
1/8W
R682 BIRC3330085M00 C RESISTOR 33K
Ω
1/8W
R683 BIRC4730085M00 C RESISTOR 47K
Ω
1/8W
R684 BIRC4730105A00 C RESISTOR 47K
Ω
1/10W
L601 BI2601141 COIL 3.0uH
L602 BI2601141 COIL 3.0uH
CN202 BI12S40047 CONNECTOR 4P
CN602 BI12S20016 CONNECTOR 2P
CN603 BI12S300471V CONNECTOR 3P
CN902 BI12S60127X CONNECTOR 6P
CN903 BI12S80060V CONNECTOR 8P
CW601 BI12S240004V FFC CONNECTOR 24P
JK601 BI2301571X TERMINAL SPK 4P
RF601 BIRF3300025N00 FUSE RESISTOR 33
Ω
1/2W
RY601 BI8RL00191V RELAY
DC12V ME-7C-
012-3H
Symbol
No.
Part No. Part Name Description Local
Q901 DTC114YS DIGI TRNSISTOR BI2DTC114YK011
D901 1SS133 FR DIODE
BI31SS133M000V
7
D902 1SS133 FR DIODE
BI31SS133M000V
7
D903 1SS133 FR DIODE
BI31SS133M000V
7
D904 1SS133 FR DIODE
BI31SS133M000V
7
D905 1SS133 FR DIODE
BI31SS133M000V
7
D906 1SS133 FR DIODE
BI31SS133M000V
7
C901 BICH223250ZM01 C CPCITOR 0.022uF 25V
C902 BICH223250ZM01 C CPCITOR 0.022uF 25V
Symbol
No.
Part No. Part Name Description Local
C903 BICH223250ZM01 C CPCITOR 0.022uF 25V
C904 BICH223250ZM01 C CPCITOR 0.022uF 25V
C905 BICE477250MP01 E CPCITOR 470uF 25V
C907 BICE335500MP01 E CPCITOR 3.3uF 50V
C951 BICT224275MX T CPCITOR 0.22uF 275V
R901 BIRC1000085M00 C RESISTOR 10
Ω
1/8W
R902 BIRC4720085M00 C RESISTOR 4.7K
Ω
1/8W
CW902 BI12P60176X CONNECTOR WIRE 6P to MP CN902
CW903 BI12P80121X CONNECTOR WIRE 8P to MP CN903
PT902 BI211011151001 POWER TRNS EI28SI
RY901 BI8RL00331X RELY RELYDC9V
Symbol
No.
Part No. Part Name Description Local
IC301 BI120971X IC S3C825AC63
IC302 BI116691X IC BU4051B
IC401 BI112721X IC BD3881FV
IC403 BI101851X IC NJM78L05
IC701 BI116431X IC SIL9226X0
IC702 BI118221X IC BA5927FM
IC801 BI118171X IC BH18FB1WG
IC802 BI110891X IC KIA7808AP
IC803 BI117401X IC K4S161622H
IC804 BI120281X IC S5L8310
Q50 2SC3052 TRANSISTOR BI2SC3052FA013H
Q302 2SC3052 TRANSISTOR BI2SC3052FA013H
Q303 DTC114YK DIGI TRANSISTOR
BI2DTC114YKA01
8
Q304 2SC1815 TRANSISTOR
BI2SC1815GRP00
0
Q401 2SJ460 TRANSISTOR BI2SJ460P0001
Q402 2SJ460 TRANSISTOR BI2SJ460P0001
Q403 2SK2541 TRANSISTOR BI2SK2541P0001
Q404 2SK2541 TRANSISTOR BI2SK2541P0001
Q405 2SJ460 TRANSISTOR BI2SJ460P0001
Q406 2SJ460 TRANSISTOR BI2SJ460P0001
Q407 2SK2541 TRANSISTOR BI2SK2541P0001
Q408 2SK2541 TRANSISTOR BI2SK2541P0001
Q409 2SK2541 TRANSISTOR BI2SK2541P0001
Q410 SRA2202S TRANSISTOR BI2SRA2202SA00
Q411 KTA1267GR TRANSISTOR BI2KTA1BI267GP
Q412 DTC114YK DIGI TRANSISTOR
BI2DTC114YKA01
8
Q413 DTC114YK DIGI TRANSISTOR
BI2DTC114YKA01
8
Q414 2SC3052 TRANSISTOR BI2SC3052FA013H
Q415 KTA1273 TRANSISTOR BI2KTA1273P0008
Q416 2SC3052 TRANSISTOR BI2SC3052FA013H
Q417 KTA1273 TRANSISTOR BI2KTA1273P0008
Q418 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q419 KTA1273 TRANSISTOR BI2KTA1273P0008
Q420 2SC3052 TRANSISTOR BI2SC3052FA013H
Q421 2SC3052 TRANSISTOR BI2SC3052FA013H
Q422 2SC3052 TRANSISTOR BI2SC3052FA013H
Q423 KTA1267GR TRANSISTOR BI2KTA1267GP00
Q424 KTC3199G TRANSISTOR BI2KTC3199GP00
Q425 KTC3199G TRANSISTOR BI2KTC3199GP00
Q433 2SC3052 TRANSISTOR BI2SC3052FA013H
Q434 2SC5343 TRANSISTOR
BI2SC5343GP000
0
Q435 2SC5343 TRANSISTOR
BI2SC5343GP000
0
Q436 2SC5343 TRANSISTOR
BI2SC5343GP000
0
Q437 2SC3052 TRANSISTOR BI2SC3052FA013H
Symbol
No.
Part No. Part Name Description Local
