3-21
Q438 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q504 KTA1267GR TRANSISTOR BI2KTA1267GP00
Q505 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q506 KTA1267GR TRANSISTOR BI2KTA1267GP00
Q507 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q508 2SC1815 TRANSISTOR
BI2SC1815GRP00
0
Q509 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q701 KTA1266GR TRANSISTOR BI2KTA1266GP00
Q703 KTC3205 TRANSISTOR BI2KTC3205P0008
Q704 2SC1815 TRANSISTOR
BI2SC1815GRP00
0
D301 1SS133 FR DIODE
BI31SS133M000V
7
D302 1SS133 FR DIODE
BI31SS133M000V
7
D303 1SS133 FR DIODE
BI31SS133M000V
7
D304 1SS133 FR DIODE
BI31SS133M000V
7
D305 1SS133 FR DIODE
BI31SS133M000V
7
D306 UZ4.7BSA Z DIODE BI3UZ4.7BSAM000
D307 1SS133 FR DIODE
BI31SS133M000V
7
D308 1SS133 FR DIODE
BI31SS133M000V
7
D309 1SS133 FR DIODE
BI31SS133M000V
7
D401 MC2836 DIODE BI3MC2836A002H
D402 UZ4.7BSA Z DIODE BI3UZ4.7BSAM000
D403 1SS133 FR DIODE
BI31SS133M000V
7
D404 1SS133 FR DIODE
BI31SS133M000V
7
D405 UZ4.7BSA Z DIODE BI3UZ4.7BSAM000
D406 1SS133 FR DIODE
BI31SS133M000V
7
D407 1SS133 FR DIODE
BI31SS133M000V
7
D501 1SS133 FR DIODE
BI31SS133M000V
7
D502 1SS133 FR DIODE
BI31SS133M000V
7
D503 1SS133 FR DIODE
BI31SS133M000V
7
D504 1SS133 FR DIODE
BI31SS133M000V
7
D505 1SS133 FR DIODE
BI31SS133M000V
7
D508 1SS133 FR DIODE
BI31SS133M000V
7
D509 1SS133 FR DIODE
BI31SS133M000V
7
D510 1N4002 DIODE BI31N4002M000V3
D511 1SS133 FR DIODE
BI31SS133M000V
7
D516 UZ11BSC Z DIODE
BI3UZ11BSCM000
0
D517 UZ9.1BSC Z DIODE
BI3UZ91BSCM000
V
D710 UZ3.6BSB Z DIODE BI3UZ3.6BSBM000
D711 UZ3.6BSB Z DIODE BI3UZ3.6BSBM000
D712 1SS133 FR DIODE
BI31SS133M000V
7
D713 1SS133 FR DIODE
BI31SS133M000V
7
D801 1SS133 FR DIODE
BI31SS133M000V
7
C301 BICC104500KA04 C CAPACITOR 0.1uF 50V
C302 BICC104500KA04 C CAPACITOR 0.1uF 50V
C303 BICC223500KA04 C CAPACITOR 0.022uF 50V
C304 BICE107100MP01 E CAPACITOR 100uF 10V
C305 BICE108100MP01 E CAPACITOR 1000uF 10V
C306 BICE476250MP01 E CAPACITOR 47uF 25V
C307 BICC104500KA04 C CAPACITOR 0.1uF 50V
C308 BICC104500KA04 C CAPACITOR 0.1uF 50V
C311 BICC270500JA04 C CAPACITOR 27pF 50V

Symbol
No.
Part No. Part Name Description Local
C312 BICC240500JA04 C CAPACITOR 24pF
C313 BICC330500JA04 C CAPACITOR 33pF 50V
C314 BICC102500KA04 C CAPACITOR 1000pF 50V
C315 BICC220500JA04 C CAPACITOR 22pF 50V
C316 BICC220500JA04 C CAPACITOR 22pF 50V
C317 BICC104500KA02 C CAPACITOR 0.1uF 50V
C318 BICE105500MP01 E CAPACITOR 1uF 50V
C319 BICC104500KA02 C CAPACITOR 0.1uF 50V
C322 BICC101500JA04 C CAPACITOR 100pF 50V
C323 BICC101500JA04 C CAPACITOR 100pF 50V
C324 BICC101500JA04 C CAPACITOR 100pF 50V
C325 BICC101500JA04 C CAPACITOR 100pF 50V
C326 BICC101500JA04 C CAPACITOR 100pF 50V
C401 BICC122500KA04 C CAPACITOR 1200pF 50V
C402 BICC122500KA04 C CAPACITOR 1200pF 50V
C403 BICC470500JA04 C CAPACITOR 47pF 50V
C404 BICC470500JA04 C CAPACITOR 47pF 50V
C405 BICE226100MP01 E CAPACITOR 22uF 10V
C406 BICE226100MP01 E CAPACITOR 22uF 10V
C407 BICE225500MP01 E CAPACITOR 2.2uF 50V
C408 BICC471500KA04 C CAPACITOR 470pF 50V
C409 BICC103500KA04 C CAPACITOR 0.01uF 50V
C410 BICC103500KA04 C CAPACITOR 0.01uF 50V
C411 BICC181500JA04 C CAPACITOR 180pF 50V
C412 BICC181500JA04 C CAPACITOR 180pF 50V
C413 BICE107100MP01 E CAPACITOR 100uF 10V
C414 BICC561500KA04 C CAPACITOR 560pF 50V
C415 BICC561500KA04 C CAPACITOR 560pF 50V
C416 BICC332500KA04 C CAPACITOR 3300pF 50V
C417 BICE227160MP01 E CAPACITOR 220uF 16V
C418 BICE225500MP01 E CAPACITOR 2.2uF 50V
C419 BICC332500KA04 C CAPACITOR 3300pF 50V
C420 BICE104500MP01 E CAPACITOR 0.1uF 50V
C421 BICC101500JA04 C CAPACITOR 100pF 50V
C422 BICE474500MP01 E CAPACITOR 0.47uF 50V
C423 BICC104500KA04 C CAPACITOR 0.1uF 50V
C424 BICC104500KA04 C CAPACITOR 0.1uF 50V
C425 BICE104500MP01 E CAPACITOR 0.1uF 50V
C426 BICC122500KA04 C CAPACITOR 1200pF 50V
C427 BICC181500JA04 C CAPACITOR 180pF 50V
C428 BICE227160MP01 E CAPACITOR 220uF 16V
C429 BICC122500KA04 C CAPACITOR 1200pF 50V
C430 BICC102500KA04 C CAPACITOR 1000pF 50V
C431 BICE107100MP01 E CAPACITOR 100uF 10V
C432 BICC103500KA04 C CAPACITOR 0.01uF 50V
C433 BICC222500KA04 C CAPACITOR 2200pF 50V
C434 BICC181500JA04 C CAPACITOR 180pF 50V
C435 BICC103500KA04 C CAPACITOR 0.01uF 50V
C436 BICC103500KA04 C CAPACITOR 0.01uF 50V
C437 BICC682500KA04 C CAPACITOR 6800pF 50V
C438 BICC104500KA04 C CAPACITOR 0.1uF 50V
C439 BICC103500KA04 C CAPACITOR 0.01uF 50V
C440 BICE227160MP01 E CAPACITOR 220uF 16V
C441 BICC272500KA04 C CAPACITOR 2700pF
C444 BICC222500KA04 C CAPACITOR 2200pF 50V
C445 BICE474500MP01 E CAPACITOR 0.47uF 50V
C446 BICC103500KA04 C CAPACITOR 0.01uF 50V
C447 BICE107160MP01 E CAPACITOR 100uF 16V
C448 BICC682500KA04 C CAPACITOR 6800pF 50V
C449 BICC103500KA04 C CAPACITOR 0.01uF 50V
C450 BICE475500MP01 E CAPACITOR 4.7uF 50V
C451 BICE107160MP01 E CAPACITOR 100uF 16V
C453 BICC102500KA04 C CAPACITOR 1000pF 50V
C454 BICC102500KA04 C CAPACITOR 1000pF 50V
C458 BICE476160MP01 E CAPACITOR 47uF 16V
C459 BICE224500MP01 E CAPACITOR 0.22uF 50V
C460 BICE224500MP01 E CAPACITOR 0.22uF 50V
C496 BICC683160KA04 C CAPACITOR 0.068uF 16V
C497 BICC683160KA04 C CAPACITOR 0.068uF 16V
C501 BICE226250MP01 E CAPACITOR 22uF 25V
C502 BICE107100MP01 E CAPACITOR 100uF10V
C503 BICM682101KP01 M CAPACITOR 6800pF 100V
C518 BICC272500KA04 C CAPACITOR 2700pF
C520 BICC272500KA04 C CAPACITOR 2700pF
C521 BICC561500KA04 C CAPACITOR 560pF 50V
C524 BICE105500MP01 E CAPACITOR 1uF 50V
C525 BICE475500MP01 E CAPACITOR 4.7uF 50V

Symbol
No.
Part No. Part Name Description Local
