JVC NX-G5 - Specifications

55
Specifications
Amplifier section—CA-NXG7/CA-NXG3 (NX-G3)
Output Power:
CA-NXG7: 240 W (120 W + 120 W) at 8 Ω
(10% THD)
CA-NXG3: 40 W (20 W + 20 W) at 4 Ω
(10% THD)
Audio Input: AUDIO IN:
Stereo min. (∅ 3.5 mm)
500 mV/47 kΩ (at “AUDIO LVL3”)
250 mV/47 kΩ (at “AUDIO LVL2”)
125 mV/47 kΩ (at “AUDIO LVL1”)
Digital output: OPTICAL DIGITAL OUTPUT:
–21 dBm to –15 dBm (660 nm
±30 nm)
Digital input: USB REC/PLAY
VIDEO OUT:
Color system: NTSC/PAL (interlaced/
progressive)
VIDEO (Composite): 1 V(p-p)/75 Ω
COMPONENT: (Y) 1 V(p-p)/75 Ω
(P
B/PR) 0.7 V(p-p)/75 Ω
Speaker impedance:
CA-NXG7: 8 Ω – 16 Ω
CA-NXG3: 4 Ω – 16 Ω
Tuner section
FM tuning range: 87.50 MHz – 108.00 MHz
AM (MW) tuning range:
531 kHz – 1 710 kHz (at 9 kHz)
530 kHz – 1 710 kHz (at 10 kHz)
For Saudi Arabia: 531 kHz – 1 602 kHz (at 9 kHz)
530 kHz – 1 600 kHz (at 10 kHz)
Disc player section
Region codes: Middle East: 2
South East Asia: 3
Central and South America,
Australia: 4
Playable disc:
• DVD Video/CD/VCD/SVCD
• CD-R/CD-RW (CD/SVCD/VCD/MP3/WMA/
WAV/JPEG/MPEG-1/MPEG-2/ASF/DivX
format)
• DVD-R/-RW (DVD-VR/DVD Video/MP3/
WMA/WAV/JPEG/MPEG-1/MPEG-2/ASF/
DivX format)
• +R (DVD Video/MP3/WMA/WAV/JPEG/
MPEG-1/MPEG-2/ASF/DivX format)
• +RW (MP3/WMA/WAV/JPEG/MPEG-1/MPEG-
2/ASF/DivX format)
• DVD-ROM (MP3/WMA/WAV format)
Dynamic range: 80 dB
Horizontal resolution: 500 lines
Wow and flutter: Immeasurable
USB section
Playable files: MP3/WMA/WAV/JPEG/MPEG-1/
MPEG-2/ASF/DivX format
USB specification: Compatible with USB 2.0 Full Speed
Compatible device: Mass storage class
Compatible system: FAT16, FAT32
Bus power supply: DC 5 V
500 mA
General—CA-NXG7
Power requirements:
AC 220 V /AC 230 V – AC 240 V,
(adjustable with the voltage
selector), 50 Hz / 60 Hz
For Saudi Arabia: AC 220 V
, 50 Hz / 60 Hz
For Australia: AC 240 V
, 50 Hz
Power consumption:
70 W (at operation)
13 W (at standby)
1.3 W or less (at ECO mode)
Dimensions (approx.):
250 mm × 158 mm × 259 mm
(W/H/D)
Mass (approx.): 5.0 kg
General—CA-NXG3 (NX-G3)
Power requirements:
AC 110 V – AC 240 V
, 50 Hz /
60 Hz
For Australia: AC 240 V
, 50 Hz
Power consumption:
35 W (at operation)
3.5 W (at standby)
1.0 W or less (at ECO mode)
Dimensions (approx.):
250 mm × 158 mm × 259 mm
(W/H/D)
Mass (approx.): 3.0 kg
Speakers—SP-NXG5 (NX-G3)
Type: 2-way 2-speaker bass reflex type
(Magnetically shielded)
Speaker units: Tweeter: 4 cm cone x 1
Woofer: 12 cm cone x 1
Impedance: 4 Ω
Power handling capacity: 20 W
Frequency Range: 50 Hz - 28 000 Hz
Dimensions (approx.):
155 mm × 250 mm × 168 mm
(W/H/D)
Mass (approx.): 2.1 kg each
Supplied Accessories
See page 4.
Design and specifications are subject to change
without notice.
