Connection
Do not connect the AC power cord until all other connections have been made.
USB
AUDIO
i Pod
DC IN
SPEAKERS
RIGHT LEFT WOOFER
6-16Ω 8-16Ω
23V 2.5A
INPUT
SPEAKERS
RIGHT LEFT WOOFER
6-16Ω 8-16Ω
Subwoofer
Unit
To a wall outlet
Plug the AC power cord
only after all connections
are complete.
AC adaptor
USB AUDIO
terminal
iPod terminal
DC IN
23V 2.5A
Main speaker
Speaker cord (1.5m) Speaker cord (1.5m)
AC adaptor
AC power
cord
Main speaker
Speaker cord (2.5m)
