JVC RC-BZ5RD Service Manual

RC-BZ5LB/BZ5RD
3-10
Item
Parts number Parts name Area
Remarks
A
R 641 GJ250085632103 CARBON RESISTOR CF 1/6W J 56K
R 642 GJ250081232103 CARBON RESISTOR CF 1/6W J 12K
R 643 GJ250088222103 CARBON RESISTOR CF 1/6W J 8.2K
R 644 GJ250082232103 CARBON RESISTOR CF 1/6W J 22K
R 645 GJ250082232103 CARBON RESISTOR CF 1/6W J 22K
R 646 GJ250082222103 CARBON RESISTOR CF 1/6W J 2.2K
R 647 GJ250084722103 CARBON RESISTOR CF 1/6W J 4.7K
R 651 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 652 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 653 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 654 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 659 GJ250082712103 CARBON RESISTOR CF 1/6W J 270
R 661 GJ250086832103 CF RESISTOR CF 1/6W J 68K
R 663 GJ250081242103 CARBON RESISTOR CF 1/6W J 120K
R 664 GJ250084712103 CARBON RESISTOR CF 1/6W J 470
R 666 GJ250082202103 CARBON RESISTOR CF 1/6W J 22
R 671 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 672 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 696 GJ250082222103 CARBON RESISTOR CF 1/6W J 2.2K
R 697 GJ250084742103 CARBON RESISTOR CF 1/6W J 470K
R 901 GJ250084722103 CARBON RESISTOR CF 1/6W J 4.7K
R 902 GJ250085632103 CARBON RESISTOR CF 1/6W J 56K
R 903 GJ250081012103 CARBON RESISTOR CF 1/6W J 100
R 904 GJ250088212103 CARBON RESISTOR CF 1/6W J 820
R 906 GJ250085632103 CARBON RESISTOR CF 1/6W J 56K
R 907 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 908 GJ250083322103 CARBON RESISTOR CF 1/6W J 3.3K
R 909 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 910 GJ250081042103 CARBON RESISTOR CF 1/6W J 100K
R 911 GJ250084722103 CARBON RESISTOR CF 1/6W J 4.7K
R 912 GJ250081022103 CARBON RESISTOR CF 1/6W J 1K
R 913 GJ250085622103 CARBON RESISTOR CF 1/6W J 5.6K
R 914 QRZ0077-4R7X FUSE RESISTOR
A
1/4W J 4.7 TAPE
R 915 GJ250081012103 CARBON RESISTOR CF 1/6W J 100
R 916 GJ250088212103 CARBON RESISTOR CF 1/6W J 820
R 917 GJ250082202103 CARBON RESISTOR CF 1/6W J 22
R 919 GJ250085632103 CARBON RESISTOR CF 1/6W J 56K
R 920 GJ250084722103 CARBON RESISTOR CF 1/6W J 4.7K
R 922 GJ250081032103 CARBON RESISTOR CF 1/6W J 10K
R 998 GJ251273352201 C RESISTOR 1/2W 3.3M 5%
R 999 GJ250083312103 CARBON RESISTOR 1/6W J 330
S 301 MSW-17820MVD0 LEAF SWITCH GJ390140041114
S 303 SK-23E01-G9 SLIDE SWITCH SLIDE SIDE
T 2 GJ123388511 IFT 7MM BLACKPCFAZ-
T 9 GJ336570400003 POWER TRANS.
A
EI-57 AC120V
T 301 OH-812320 BIAS OSC COIL GJ321000140101
TC 2 QAT3722-200ZM T CAPACITOR TRIMMER 20PF EC
TP 2 VMZ0015-002 POST PIN FM ANT PIN SOCK
WR 1 GJ354003940105 WIRE CN308 TO DECK
WR 2 GJ354003960205 WIRE POWER TO BATT.
WR 3 GJ354003980205 WIRE CN309 TO SPEAKE
WR 4 GJ354003990405 WIRE FW301 TO POWER
WR 5 GJ354004000105 WIRE CN301 TO HEAD
WR 6 GJ351004020105 WIRE CN602 TO CD ME.
X 1 QAX0402-001 CRYSTAL 75KHZ +/-20PPM
X 651 CSA16.93MXZ040T CERA LOCK CER CSA
ZD 1 MTZ3.0JB Z.DIODE GJ871998307
ZD903 MTZJ6.2B-T2 ZENER DIODE GJ871992342
ZD904 MTZJ5.6B Z DIODE GJ310030011305
ZD905 MTZJ7.5C-T2 ZENER DIODE GJ310030015005
Electrical parts list ( Main board )
Block No. 01
www.freeservicemanuals.info
11/28/2017
Digitized in Heiloo Netherlands
