JVC RC-BZ5RD Service Manual

RC-BZ5LB/BZ5RD
3-11
Item
Parts number Parts name Area
Remarks
A
C 702 GJ116323691 C.CAPACITOR 24PF CH 2012 5%
C 703 GJ116324091 C.CAPACITOR 36PF CH 2012 Z
C 704 GJ116324091 C.CAPACITOR 36PF CH 2012 Z
C 705 GJ116323691 C.CAPACITOR 24PF CH 2012 5%
C 706 GJ116300991 C.CAPASISTOR 1000PF B 2012 1
C 707 GJ116303891 C.CAPACITOR 100000PF F 2012
C 708 GJ270112270332 E.CAPACITOR 10V M 220UF
C 710 GJ116302191 C.CAPASISTOR 10000PF B 2012
C 711 GJ112423391 E.CAPACITOR 16V M 10UF
C 712 GJ112425791 E.CAPACITOR 50V M 2.2UF
C 719 GJ116300991 C.CAPASISTOR 1000PF B 2012 1
C 720 GJ116300991 C.CAPASISTOR 1000PF B 2012 1
C 721 GJ116302191 C.CAPASISTOR 10000PF B 2012
C 722 GJ116311791 C.CAPACITOR 100PF SL 2012 5
C 723 GJ116311791 C.CAPACITOR 100PF SL 2012 5
C 724 GJ116311791 C.CAPACITOR 100PF SL 2012 5
C 725 GJ116311791 C.CAPACITOR 100PF SL 2012 5
C 727 GJ112678591 E.CAPACITOR 10V M 47UF
C 732 GJ116303891 C.CAPACITOR 100000PF F 2012
C 738 GJ116312191 C.CAPACITOR 150PF SL 2012 5
CN701 QGF1212F1-17 FFC/FPC CONNE 17PINS
CN702 GJ156450811 CONNECTOR 5 PIN
CN703 QGF1212F1-12 FFC CONNE 12PINS
CN704 GJ156451711 CONNECTOR 2PINS RA
D 702 1SS133Y DIODE GJ871999133
D 703 UZ5.1BSC-T2 ZENER DIODE MTZJ5.1B-T77
D 706 1SS133Y DIODE GJ871999133
D 707 1SS133Y DIODE GJ871999133
D 708 1SS133Y DIODE GJ871999133
D 851 LT0311G-41 LED GREEN STAND STAND BY/RED CO
D 852 LT0321-41 ON LED RTP ON /GREEN COLOR
DI701 GJ373010282311 LCD DLC-9833P
IC701 GJ313010671223 IC MICOM MN171603Y
K 701 QQR0779-001Z INDUCTOR GJV
Q
Z0048009
K 702 QQR0779-001Z INDUCTOR GJV
Q
Z0048009
K 703 QQR0779-001Z INDUCTOR GJV
Q
Z0048009
L 701 3A839N INDUCTOR 10UH K RADIAL L
L 702 3A839N INDUCTOR 10UH K RADIAL L
Q
701 2SC2714/O/-X TRANSISTOR GJ312020341203
Q
702 2SC2714/O/-X TRANSISTOR GJ312020341203
Q
703 2SC2412K/R/-X TRANSISTOR GJ872992075
Q
704 DTC144EKA-X TRANSISTOR GJ872902759
Q
705 2SA1037AK/RS/-X TRANSISTOR GJ872902649
Q
706 DTC143TKA-X DIGI TRANSISTOR GJ872902756
R 701 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 702 GJ121607191 C.RESISTOR 8.2K 1/10W 5%
R 703 GJ121607191 C.RESISTOR 8.2K 1/10W 5%
R 704 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 706 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 707 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 708 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 709 GJ121608191 C.RESISTOR 22K 1/10W 5%
R 710 GJ121609791 C.RESISTOR 100K 1/10W 5%
R 711 GJ121608191 C.RESISTOR 22K 1/10W 5%
R 712 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 714 GJ121608791 C.RESISTOR 39K 1/10W 5%
R 715 GJ121608591 C.RESISTOR 33K 1/10W 5%
R 716 GJ121608991 C.RESISTOR 47K 1/10W 5%
R 717 GJ121608591 C.RESISTOR 33K 1/10W 5%
R 718 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 719 GJ121609791 C.RESISTOR 100K 1/10W 5%
R 720 GJ121609791 C.RESISTOR 100K 1/10W 5%
R 721 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 723 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 724 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 725 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 726 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 727 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 728 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 729 GJ121608991 C.RESISTOR 47K 1/10W 5%
R 730 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 732 GJ121609791 C.RESISTOR 100K 1/10W 5%
R 733 GJ121609791 C.RESISTOR 100K 1/10W 5%
R 734 GJ121609791 C.RESISTOR 100K 1/10W 5%
R 735 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 738 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 739 GJ121608191 C.RESISTOR 22K 1/10W 5%
R 740 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 741 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 742 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 746 GJ121608191 C.RESISTOR 22K 1/10W 5%
R 748 GJ121608191 C.RESISTOR 22K 1/10W 5%
R 749 GJ121608991 C.RESISTOR 47K 1/10W 5%
R 750 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 751 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 752 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 753 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 754 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 756 GJ121608191 C.RESISTOR 22K 1/10W 5%
R 758 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 759 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 760 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 761 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 762 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 763 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 767 GJ121606591 C.RESISTOR 4.7K 1/10W 5%
R 768 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 770 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 772 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 773 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 774 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 775 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 776 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 777 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 778 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 779 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 785 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 796 GJ121609791 C.RESISTOR 100K 1/10W 5%
R 797 GJ121606591 C.RESISTOR 4.7K 1/10W 5%
R 851 GJ121605391 C.RESISTOR 1.5K 1/10W 5%
R 852 GJ121605591 C.RESISTOR 1.8K 1/10W 5%
R 853 GJ121605991 C.RESISTOR 2.7K 1/10W 5%
R 854 GJ121606391 C.RESISTOR 3.9K 1/10W 5%
R 855 GJ121606991 C.RESISTOR 6.8K 1/10W 5%
R 856 GJ121607591 C.RESISTOR 12K 1/10W 5%
R 857 GJ121608791 C.RESISTOR 39K 1/10W 5%
R 858 GJ121606791 C.RESISTOR 5.6K 1/10W 5%
R 859 GJ121607991 C.RESISTOR 18K 1/10W 5%
R 860 GJ121603791 C.RESISTOR 330 1/10W 5%
R 861 GJ121604591 C.RESISTOR 680 1/10W 5%
R 864 GJ121606791 C.RESISTOR 5.6K 1/10W 5%
S 851 QSW0707-001Z TACT SWITCH GJ390110171110
S 852 QSW0707-001Z TACT SWITCH GJ390110171110
S 853 QSW0707-001Z TACT SWITCH GJ390110171110
S 854 QSW0707-001Z TACT SWITCH GJ390110171110
S 855 QSW0707-001Z TACT SWITCH GJ390110171110
Electrical parts list ( System CPU board )
Block No. 02
Item
Parts number Parts name Area
Remarks
A
