JVC RC-BZ5RD Service Manual

RC-BZ5LB/BZ5RD
3-12
Item
Parts number Parts name Area
Remarks
A
S 856 QSW0707-001Z TACT SWITCH GJ390110171110
S 857 QSW0707-001Z TACT SWITCH GJ390110171110
S 858 QSW0707-001Z TACT SWITCH GJ390110171110
S 865 QSW0707-001Z TACT SWITCH GJ390110171110
S 866 GJ390030152203 SWITCH PUSH SW PSG-22F0US-
Q
3.5
VR302 QVQ0121-A54 MAIN VOL GJ299000490002
WR701 GJ354004030205 WIRE CN704 TO CD DO.
WR702 GJ354004040105 WIRE CN702 TO MAIN
X 701 QAX0410-001Z CERA LOCK MIZCRHF 4.19MHZ
Electrical parts list ( System CPU board )
Block No. 02
