JVC RC-BZ6

RC-BZ6BU
3-23
Item
Parts number Parts name Area
Electrical parts list ( System CPU board )
Remarks
Block No. 02
A
C 702 GJ116323691 C.CAPACITOR 24PF CH 2012 5%
C 703 GJ116324091 C.CAPACITOR 36PF CH 2012 5%
C 704 GJ116324091 C.CAPACITOR 36PF CH 2012 5%
C 705 GJ116323691 C.CAPACITOR 24PF CH 2012 5%
C 706 GJ116300991 C.CAPASISTOR 1000PF B 2012 1
C 707 GJ116303891 C.CAPACITOR 10000PF F 2012
C 708 GJ270112270332 E.CAPACITOR 10V M 220UF
C 710 GJ116302191 C.CAPASISTOR 10000PF B 2012
C 711 GJ112423391 E.CAPACITOR 16V M 10UF
C 712 GJ112425791 E.CAPACITOR 50V M 2.2UF
C 714 GJ116312191 C.CAPACITOR 150PF SL 2012 5
C 716 GJ116312191 C.CAPACITOR 150PF SL 2012 5
C 717 GJ116310191 C.CAPACITOR 22PF SL 2012 5%
C 718 GJ116323791 C.CAPACITOR 27PF CH 2012 5%
C 719 GJ116300991 C.CAPASISTOR 1000PF B 2012 1
C 720 GJ116300991 C.CAPASISTOR 1000PF B 2012 1
C 721 GJ116302191 C.CAPASISTOR 10000PF B 2012
C 722 GJ116311791 C.CAPACITOR 100PF SL 2012 5
C 723 GJ116311791 C.CAPACITOR 100PF SL 2012 5
C 724 GJ116311791 C.CAPACITOR 100PF SL 2012 5
C 725 GJ116311791 C.CAPACITOR 100PF SL 2012 5
C 727 GJ112678591 E.CAPACITOR 10V M 47UF
C 732 GJ116303891 C.CAPACITOR 10000PF F 2012
C 738 GJ116312191 C.CAPACITOR 150PF SL 2012 5
C 801 GJ116302191 C.CAPASISTOR 10000PF B 2012
C 802 GJ116302191 C.CAPASISTOR 10000PF B 2012
CN701 QGF1212F1-17 FFC/FPC CONNE 17PINS
CN703 QGF1212F1-13 FFC/FPC CONNE 13PINS
CN704 GJ156451711 CONNECTOR TIP-X02P-M1
D 702 1SS133Y DIODE GJ871999133
D 703 UZ5.1BSC-T2 ZENER DIODE GJ310030011405
D 704 1SS133Y DIODE GJ871999133
D 706 1SS133Y DIODE GJ871999133
D 707 1SS133Y DIODE GJ871999133
D 708 1SS133Y DIODE GJ871999133
D 851 LT0311G-41 LED GREEN STAND STAND BY/RED CO
D 852 LT0321-41 ON LED RTP ON /GREEN COLOR
DI701 QLD0045-001 LCD GJ373010272210
IC701 GJ313010671223 IC MICOM
IC703 GP1U281X IC REMOTE SENSOR
JS801 QSW0706-001 ROTARY ENCODER GJ299000480002
K 701 QQR0779-001Z INDUCTOR GJV
Q
Z0048009
K 702 QQR0779-001Z INDUCTOR GJV
Q
Z0048009
K 703 QQR0779-001Z INDUCTOR GJV
Q
Z0048009
L 701 3A839N INDUCTOR 10UH
L 702 3A839N INDUCTOR 10UH
PL701 QLL0051-001 LAMP 8V 105MA T3.4
(
Q
701 2SC2714/O/-X TRANSISTOR GJ312020341203
Q
702 2SC2714/O/-X TRANSISTOR GJ312020341203
Q
703 2SC2412K/R/-X TRANSISTOR GJ872992075
Q
704 DTC144EKA-X TRANSISTOR GJ872902759
Q
705 2SA1037AK/RS/-X TRANSISTOR GJ872902649
Q
706 DTC143TKA-X DIGI TRANSISTOR GJ872902756
Q
709 2SC2412K/R/-X TRANSISTOR GJ872992075
Q
851 2SA1037AK/RS/-X TRANSISTOR GJ872902649
Q
852 2SC2412K/R/-X TRANSISTOR GJ872992075
R 701 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 702 GJ121607191 C.RESISTOR 8.2K 1/10W 5%
R 703 GJ121607191 C.RESISTOR 8.2K 1/10W 5%
R 704 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 706 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 707 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 708 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 709 GJ121608191 C.RESISTOR 22K 1/10W 5%
R 710 GJ121609791 C.RESISTOR 100K 1/10W 5%
R 711 GJ121608191 C.RESISTOR 22K 1/10W 5%
R 712 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 713 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 714 GJ121608791 C.RESISTOR 39K 1/10W 5%
R 715 GJ121608591 C.RESISTOR 33K 1/10W 5%
R 716 GJ121608991 C.RESISTOR 47K 1/10W 5%
R 717 GJ121608591 C.RESISTOR 33K 1/10W 5%
R 718 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 719 GJ121609791 C.RESISTOR 100K 1/10W 5%
R 720 GJ121609791 C.RESISTOR 100K 1/10W 5%
R 721 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 722 GJ121609791 C.RESISTOR 100K 1/10W 5%
R 723 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 724 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 725 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 726 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 727 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 728 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 729 GJ121608991 C.RESISTOR 47K 1/10W 5%
R 730 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 731 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 732 GJ121609791 C.RESISTOR 100K 1/10W 5%
R 733 GJ121609791 C.RESISTOR 100K 1/10W 5%
R 734 GJ121609791 C.RESISTOR 100K 1/10W 5%
R 735 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 737 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 738 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 739 GJ121608191 C.RESISTOR 22K 1/10W 5%
R 740 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 742 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 746 GJ121608191 C.RESISTOR 22K 1/10W 5%
R 748 GJ121608191 C.RESISTOR 22K 1/10W 5%
R 749 GJ121608991 C.RESISTOR 47K 1/10W 5%
R 750 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 751 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 752 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 753 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 754 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 755 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 756 GJ121608191 C.RESISTOR 22K 1/10W 5%
R 758 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 759 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 760 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 761 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 762 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 763 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 767 GJ121606591 C.RESISTOR 4.7K 1/10W 5%
R 768 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 769 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 770 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 772 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 773 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 774 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 775 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 776 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 777 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 778 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 779 GJ121604991 C.RESISTOR 1K 1/10W 5%
R 785 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
R 790 GJ121606591 C.RESISTOR 4.7K 1/10W 5%
R 796 GJ121609791 C.RESISTOR 100K 1/10W 5%
Item
Parts number Parts name Area
Remarks
A
