JVC RC-BZ6

RC-BZ6BU
3-24
Item
Parts number Parts name Area
Remarks
A
R 797 GJ121606591 C.RESISTOR 4.7K 1/10W 5%
R 851 GJ121605391 C.RESISTOR 1.5K 1/10W 5%
R 852 GJ121605591 C.RESISTOR 1.8K 1/10W 5%
R 853 GJ121605991 C.RESISTOR 2.7K 1/10W 5%
R 854 GJ121606391 C.RESISTOR 3.9K 1/10W 5%
R 855 GJ121606991 C.RESISTOR 6.8K 1/10W 5%
R 856 GJ121607591 C.RESISTOR 12K 1/10W 5%
R 857 GJ121608791 C.RESISTOR 39K 1/10W 5%
R 858 GJ121606791 C.RESISTOR 5.6K 1/10W 5%
R 859 GJ121607991 C.RESISTOR 18K 1/10W 5%
R 860 GJ121603791 C.RESISTOR 330 1/10W 5%
R 861 GJ121604591 C.RESISTOR 680 1/10W 5%
R 862 GJ121607391 C.RESISTOR 10K 1/10W 5%
R 864 GJ121606791 C.RESISTOR 5.6K 1/10W 5%
R 865 GJ121605791 C.RESISTOR 2.2K 1/10W 5%
S 851 QSW0707-001Z TACT SWITCH GJ390110171110
S 852 QSW0707-001Z TACT SWITCH GJ390110171110
S 853 QSW0707-001Z TACT SWITCH GJ390110171110
S 854 QSW0707-001Z TACT SWITCH GJ390110171110
S 855 QSW0707-001Z TACT SWITCH GJ390110171110
S 856 QSW0707-001Z TACT SWITCH GJ390110171110
S 857 QSW0707-001Z TACT SWITCH GJ390110171110
S 858 QSW0707-001Z TACT SWITCH GJ390110171110
S 865 QSW0707-001Z TACT SWITCH GJ390110171110
S 866 PS-22F23-A3.3NS PUSH SWITCH GJ390030152203
WR701 GJ354004030205 WIRE CN704 TO CD DOR
X 701 QAX0410-001Z CERA LOCK MIZCRHF 4.19MHZ
X 702 QAX0401-001 CRYSTAL 32.768KHZ
Electrical parts list ( System CPU board )
Block No. 02
