JVC RC-BZ6BU Service Manual

RC-BZ5LB/BZ5RD
3-3
1 GJ460340210101 LENS CD DOOR 1 RC-BZ5LB
GJ460340500101 LENS CD DOOR 1 RC-BZ5RD
2 GJ670000010330 D.SPACER 1 65X3.5
3 GJ670000010340 D.SPACER 1 65X3.5
4 GJ670000010350 D.SPACER 1 110-3.0
5 GJ460340120101 DOOR CD 1
6 VYH7313-005 MAGNET 1
7 LV30175-001A CLAMPER 1
8 GJ702224301242 SCREW TT3X12 2 FOR CD CASE
9 GJ460340160101 CD CASE 1
10 GJ460340020101 BUTTON 1 OPEN
11-1 GJ460340040101 BUTTON(A)MECHA. 1 PAUSE
11-2 GJ460340050101 BUTTON(B)MECHA. 1 STOP
11-3 GJ460340060101 BUTTON(C)MECHA. 1 FF
11-4 GJ460340070101 BUTTON(D)MECHA. 1 REW
11-5 GJ460340080101 BUTTON(E)MECHA. 1 PLAY
11-6 GJ460340090101 BUTTON(F)MECHA. 1 REC
12 --------------- CD UNIT EXL-M7B 1 GJA1005002001C
13 E75609-001 INSULATOR 2 CD MECHA RED
14 E75609-002 INSULATOR 2 CD MECHA PURPLE
15 GJ460340170101 HOLDER CD 1
16 GJ702244301012 SCREW TT3X10 20 SPEAKE/MAIN PCB
17 GJ460340200101 HOLDER 1 CONTROL BOARD
18 GJ781000090101 SHIELD PLATE 1
20 GJ460340270101 HOLDER (1)LCD 1
23 GJ460340230101 FUNCTION KNOB 1
24 LE10010-005A SPEAKER 2
25 GJ702244260812 SCREW TT2.6X8 2 COVER-FRONT
26 GJ460340030101 LENS 1 REMOTE SENSOR
27 GJ460340260101 LENS 1 LED
28 GJ460340400101 FRONT COVER 1
30 GJ0001-SPGR SPEAKER GRILLE 1 SHILD, RC-BZ5RD
GJ0003-SPGR SPEAKER GRILLE 1 SHILD, RC-BZ5LB
31 GJ460340250101 VOLUME KNOB 1
32 GJ460340490101 C.DOOR LENS 1 RC-BZ5RD
GJ460340190101 C.DOOR LENS 1 RC-BZ5LB
33 GJ460340220101 FRONT LENS 1 RC-BZ5LB
GJ460340480101 FRONT LENS 1 RC-BZ5RD
34 VYH8007-001 GEAR 2 DOOR
35 GJ460340180101 CASSETTE DOOR 1
36 LV40210-001A DOOR SPRING 1
37 GJ0002-SPGR SPEAKER GRILLE 1 SHILD, RC-BZ5RD
GJ0004-SPGR SPEAKER GRILLE 1 SHILD, RC-BZ5LB
38 GJ460340010101 FRONT CABINET 1
40 --------------- DECK MECHANISM 1 TN-21ZVC-1800
41 GJ702264301412 SCREW TT3X14 2
43 GJ711001340101 SPRING 1 ANT CONTACT
44 GJ460340100101 REAR CABINET 1
Item Parts number Parts name Area
A
Parts list ( General assembly )
Q'ty Description
Block No. M1MM
Item Parts number Parts name Area
A
Parts list ( General assembly )
Q'ty Description
Block No. M1MM
46 TA46174 T.PICK ANTENNA 1
47 VYH5657-006 BATTERY SPRING 1 SIZE D
48 LV20082-001A BATTERY COVER 1
49 VYH8008-001 HANDLE SUPPORT 2
50 GJ702244304512 SCREW TT3X45 8
51 GJ460340150101 HANDLE 1
52 GJ701224300852 SCREW M3X8 1 T. ANTENNA
54 GJ711001330201 SPRING 1
55 GJ702244300812 SCREW TT3X8 8 DECK/KEY P.C.B.
59 GJ782000090101 FOOT RUBBER 2
60 LV30176-001A HEAT SINK 1
61 QYSDSF3008Z SCREW 3 HEAT SINK
62 202-300002-00 CD COVER PLATE 1
63 GJ702224200642 SCREW TT2X6 4 CD COVER
64 VYH5483-001 BATTERY SPRING 1
65 QMF51N2-3R0-J1 FUSE
A
1 3A 125V F902
66 QMF51N2-3R0-J1 FUSE
A
1 3A 125V F903
67 GJ560340150101 NAME PLATE J,C1 RC-BZ5LB
GJ560340070101 NAME PLATE J,C1 RC-BZ5RD
68 GJ782000090101 RUBBER SPACER 1
69 GJ761000200100 SPACER 1
70 GJ500340240101 GEAR SPRING 1 CD DAMP
