JVC RC-BZ6BU Service Manual

RC-BZ5LB/BZ5RD
3-4
Item Parts number Parts name Area
A
Parts list ( Cassette mechanism assembly )
Q'ty Description
Block No. M2MM
1 192114316T BASE ASSY 1
2 19211409T SWITCH ACTUATOR 1
3 19211408T LOCK CAM 1
4 19211403T REC BUTT.LEVER 1
5 19211419T PLAY BUTT.LEVER 1
6 19211404T REW BUTT. LEVER 1
7 19211405T FF BUTTON LEVER 1
8 19211406T STOP BUTT.LEVER 1
9 19211460T PAUSE BUT.LEVER 1
10 19211413AT SPRING 1 PAUSE LEVER
11 19211455T PAUSE LEVER (E) 1
12 19211412T SPRING 1 PAUSE LEVER
13 19211411T PAUSE STOPPER 1
14 19211414T TORSION SPRING 1
15 192101501T CHASSIS ASS'Y 1
16 19211416T TORSION SPRING 1
17 19211417T TORSION SPRING 1
19 182101159T E.KICK LEVER 1
20 19211420T STOPPER 1
21 19211421T TORSION SPRING 1 REC BUTTON
22 19211415T TORSION SPRING 1 BUTTON LEVER
23 MSW-1541T LEAF SWITCH 1 MSW-1541T
24 18210150T TENSION SPRING 1 PLAY BUTTON
25 19210311T HEAD PANEL 1
26 19210304AT HEAD BASE 1
27 19210309T PANEL P SPRING 1
28 19210305T MAGNET HEAD ARM 1
29 18210307T AZIMUTH SPRING 1 AZIMUTH
30 19211418AT SPRING 1 M CONTROL
31 19210310T MG ARM SPRING 1 MG ARM
32 192104309T P.ROLLER ARM 1
35 19212604AT SENSING LEVER 1
36 19212605T TORSION SPRING 1 GEAR PLATE
37 192126502T GEAR PLATE 1
38 19212602T CAM GEAR 1
40 192107304T R.F.CLUTCH 1
41 19210703T REW/F.F. BELT 1
43 192109303T FLYWHEEL ASSY 1
45 18211070T F.FORWARD GEAR 1
46 18211099T BACK TENSION SP 1
47 192105304T S. REEL ASS'Y 1
48 192105303T T. REEL ASS'Y 1
49 19210506T SENSOR 1
51 18211289AT MOTOR BRACKET 1
53 19211202T COLLAR SCREW 2 SP MOTOR 3X6
54 19211201T MOTOR PULLEY 1
55 19210904T MAIN BELT 1
56 19211203T MB SCREW 1 SP M B 2X
Item Parts number Parts name Area
A
Parts list ( Cassette mechanism assembly )
Q'ty Description
Block No. M2MM
58 19211301T EJ. SLIDE LEVER 1
59 18211093T PACK SPRING 1
60 18211069T REC.SAF.LEVER 1
62 MS15R-AA2N1 R/P HEAD 1
63 PH-K380-MS1-6A ERASE HEAD 1
64 60020217T MOTOR 1
66 9P0420031T TAPPING SCREW 1 PACK SPRING
68 9B1020051T TAPPING SCREW 2 (M2 X 5)
69 9C0720451T TAPPING SCREW 2 (M2 X 4.5)
70 9B0120031T SCREW(+)BIND 1 (M2 X 3)
71 9P0120061T SCREW 1 (M2 X 6)
72 9F0820071T SCREW AZIMUTH 1 (M2 X 7)
75 9W0230010T P.CUT WASHER 1 (12X3.8X0.3)
76 9W0250010T P.CUT WASHER 1 (1.45X3.8X0.5)
77 9W0140010T P.CUT WASHER 1 (2X3.5X0.4)
78 9W0113020T P.CUT WASHER 1 (2X3.5X0.4)
80 19210201T REC ARM 1
81 19211437T P ARM COLLAR 2
82 64010138T LEAF SWITCH 1
83 9P0420041T SCREW 1 (M2 X 4)
84 9P0420051T SCREW 1 (M2 X 5)
85 19211434T P.ROLLER ARM 1
86 9P0820301T TAPPING SCREW 1 (M2 X 3)
