SPECIFICATION
*1: Measured on AC 110 V, 127 V, 220 V, and 240 V
*2: Corresponding to Linear PCM, Dolby Digital, and DTS Digital Surround (with sampling frequency -32 kHz, 44.1 kHz, 48 kHz)
Designs and specifications are subject to change without notice.
Amplifier
Output Power At Stereo operation Front channels 100 W*1 per channel, min. RMS, driven into 8 Ω, at 1 kHz with no
more than 0.8% total harmonic distortion (IEC268-3/DIN).
At Surround operation Front channels 100 W per channel, min. RMS, driven into 8 Ω, at 1 kHz with no more
than 0.8% total harmonic distortion.
Center channel 100 W, min. RMS, driven into 8 Ω, at 1 kHz with no more than 0.8%
total harmonic distortion.
Surround channels 100 W per channel, min. RMS, driven into 8 Ω, at 1 kHz with no more
than 0.8% total harmonic distortion.
Audio Audio Input Sensitivity/Im-
pedance (1 kHz)
CD, TAPE/CDR, VCR, TV SOUND, DVD:220 mV/47 kΩ
Audio Input (DIGITAL IN)*2 Coaxial DIGITAL 1 (DVD):0.5 V(p-p)/75 Ω
Audio Input Sensitivity/Im-
pedance (1 kHz)
Optical DIGITAL 2 (CD):-21 dBm to -15 dBm (660 nm ±30 nm)
Recording Output Level TAPE/CDR, VCR:220 mV
Signal-to-Noise Ratio('66
IHF/DIN)
CD, TAPE/CDR, VCR, TV SOUND, DVD:87 dB/62 dB
Frequency Response (8 Ω) CD, TAPE/CDR, VCR, TV SOUND, DVD:20 Hz to 50 kHz (+1 dB, -3 dB)
Equalization (5 bands) 63 Hz, 250 Hz, 1 kHz, 4 kHz, 16 kHz:±8 dB (in 2 dB steps)
Video Video Input Sensitivity/Im-
pedance
Composite video DVD, VCR:1 V(p-p)/75 Ω
Video Output Level Composite video VCR, MONITOR OUT:1 V(p-p)/75 Ω
Synchronization Negative
Signal-to-Noise Ratio 45 dB
FM tuner (IHF)
Tuning Range 87.50 MHz to 108.00 MHz
Usable Sensitivity Monaural:12.8 dBf (1.2 µV/75 Ω)
50 dB Quieting Sensitivity Monaural:16.0 dBf (1.7 µV/75 Ω)
Stereo:37.5 dBf (20.5 µV/75 Ω)
Stereo Separation at OUT (REC) 35 dB at 1 kHz
AM tuner
Tuning Range 531 kHz to 1 602 kHz (at 9 kHz intervals)
530 kHz to 1 600 kHz (at 10 kHz intervals)
General
Power Requirements AC 110 V/127 V/220 V/230 V - 240 V , adjustable with the voltage selector, 50 Hz/60 Hz
Power Consumption 210 W (at operation) 4.5 W (in standby mode)
Dimensions (W × H × D) 435 mm × 146.5 mm × 369.5 mm
Mass 8.0 kg
