JVC RX-6010VBK Service Manual

RX-6010VBK/RX-6012VSL
3-13
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 03
A
Item
Parts number Parts name Area
Remarks
A
R 795 NRSA63J-221X MG RESISTOR
R 796 NRSA63J-221X MG RESISTOR
R 797 NRSA63J-221X MG RESISTOR
R 798 NRSA63J-221X MG RESISTOR
R 799 NRSA63J-221X MG RESISTOR
R1401 QRZ9005-100X F RESISTOR
A
10 1/0W
R1402 QRJ146J-182X UNF C RESISTOR
A
1.8K 5% 1/4W
R1403 QRZ9005-120X F RESISTOR
A
12 1/0W
R1404 QRJ146J-272X UNF C RESISTOR
A
2.7K 5% 1/4W
R1405 QRZ9005-120X F RESISTOR
A
12 1/0W
R1406 QRK126J-682X UNF C RESISTOR
A
6.8K 5% 1/2W
R1407 QRZ9006-4R7X F RESISTOR
A
4.7 1/0W
R1408 QRZ9006-4R7X F RESISTOR
A
4.7 1/0W
R1409 QRJ146J-272X UNF C RESISTOR
A
2.7K 5% 1/4W
R1410 QRZ9006-4R7X F RESISTOR
A
4.7 1/0W
R1411 QRJ146J-182X UNF C RESISTOR
A
1.8K 5% 1/4W
R1412 QRZ9005-100X F RESISTOR
A
10 1/0W
R1413 QRJ146J-102X UNF C RESISTOR
A
1.0K 5% 1/4W
R1414 QRZ9005-100X F RESISTOR
A
10 1/0W
R1415 QRJ146J-222X UNF C RESISTOR
A
2.2K 5% 1/4W
R1416 QRZ9005-100X F RESISTOR
A
10 1/0W
R1417 QRJ146J-222X UNF C RESISTOR
A
2.2K 5% 1/4W
R1418 QRZ9005-680X F RESISTOR
A
68 1/0W
R1419 QRZ9005-680X F RESISTOR
A
68 1/0W
R1435 NRSA63J-154X MG RESISTOR
R1436 NRSA63J-154X MG RESISTOR
R1437 NRSA63J-102X MG RESISTOR
R1438 NRSA63J-102X MG RESISTOR
R1439 NRSA63J-103X MG RESISTOR
R1440 NRSA63J-103X MG RESISTOR
R1442 NRSA63J-104X MG RESISTOR
R1444 NRSA63J-103X MG RESISTOR
R1445 NRSA63J-102X MG RESISTOR
R1446 NRSA63J-104X MG RESISTOR
R1447 NRSA63J-102X MG RESISTOR
R1448 NRSA63J-103X MG RESISTOR
R1449 NRSA63J-102X MG RESISTOR
R1450 NRSA63J-103X MG RESISTOR
R1451 NRSA63J-104X MG RESISTOR
R1452 NRSA63J-104X MG RESISTOR
R1453 NRSA63J-102X MG RESISTOR
R1454 NRSA63J-104X MG RESISTOR
R1455 NRSA63J-104X MG RESISTOR
R1456 QRJ146J-220X UNF C RESISTOR
A
22 5% 1/4W
R1457 NRSA63J-472X MG RESISTOR
R1458 NRSA63J-472X MG RESISTOR
R1459 QRZ9005-680X F RESISTOR
A
68 1/0W
R1460 QRZ9005-680X F RESISTOR
A
68 1/0W
R1461 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R1462 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R1463 NRSA63J-104X MG RESISTOR
R1464 NRSA63J-104X MG RESISTOR
R1465 NRSA63J-102X MG RESISTOR
R1470 NRSA63J-391X MG RESISTOR
R1471 NRSA63J-391X MG RESISTOR
R1472 NRSA63J-103X MG RESISTOR
R1473 NRSA63J-103X MG RESISTOR
R1474 NRSA63J-102X MG RESISTOR
R1480 NRSA63J-104X MG RESISTOR
R1490 NRSA63J-273X MG RESISTOR
R1492 NRSA63J-102X MG RESISTOR
R1493 NRSA63J-102X MG RESISTOR
R1494 NRSA63J-102X MG RESISTOR
R1495 NRSA63J-103X MG RESISTOR
R1496 NRSA63J-103X MG RESISTOR
R1497 NRSA63J-511X MG RESISTOR
R1498 NRSA63J-511X MG RESISTOR
R1499 NRSA63J-104X MG RESISTOR
S 721 QSW0683-001Z PUSH SWITCH TUNING+
S 722 QSW0683-001Z PUSH SWITCH TUNING-
S 723 QSW0683-001Z PUSH SWITCH PRESET+
S 724 QSW0683-001Z PUSH SWITCH PRESET-
S 725 QSW0683-001Z PUSH SWITCH FM MODE
S 726 QSW0683-001Z PUSH SWITCH MEMORY
S 727 QSW0683-001Z PUSH SWITCH POWER
S 728 QSW0683-001Z PUSH SWITCH SURROUND
S 729 QSW0683-001Z PUSH SWITCH DSP MODE
S 732 QSW0683-001Z PUSH SWITCH SPK1
S 740 QSW0683-001Z PUSH SWITCH TV/DBS
S 741 QSW0683-001Z PUSH SWITCH FM/AM
S 742 QSW0683-001Z PUSH SWITCH ADJUST
S 743 QSW0683-001Z PUSH SWITCH SETTING
S 744 QSW0683-001Z PUSH SWITCH +
S 745 QSW0683-001Z PUSH SWITCH -
S 751 QSW0683-001Z PUSH SWITCH DIGITAL
S 752 QSW0683-001Z PUSH SWITCH ANALOG
S 754 QSW0683-001Z PUSH SWITCH DVD
S 755 QSW0683-001Z PUSH SWITCH CD
S 756 QSW0683-001Z PUSH SWITCH VCR
S 757 QSW0683-001Z PUSH SWITCH TAPE/CDR
X 701 QAX0246-001Z RESONATOR
(System control & Audio board)
