JVC RX-6010VBK Service Manual

RX-6010VBK/RX-6012VSL
3-14
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 04
A
Item
Parts number Parts name Area
Remarks
A
C 601 NCB31HK-102X C CAPACITOR
C 602 NCB31HK-102X C CAPACITOR
C 603 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 604 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 605 NCF31CZ-104X C CAPACITOR
C 606 NCF31CZ-104X C CAPACITOR
C 607 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C 608 NCF31CZ-104X C CAPACITOR
C 609 NCF31CZ-104X C CAPACITOR
C 610 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 611 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 612 NCB31CK-103X C CAPACITOR
C 621 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 622 NCS31HJ-101X C CAPACITOR
C 623 NCF31AZ-105X C CAPACITOR
C 624 NCF31CZ-104X C CAPACITOR
C 626 NCF31AZ-105X C CAPACITOR
C 627 NCF31AZ-105X C CAPACITOR
C 628 NCB31CK-103X C CAPACITOR
C 631 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 632 NCB31CK-103X C CAPACITOR
C 633 NCF31CZ-104X C CAPACITOR
C 634 NCF31CZ-104X C CAPACITOR
C 635 NCF31CZ-104X C CAPACITOR
C 636 NCB31CK-473X C CAPACITOR
C 638 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 639 NCB31CK-103X C CAPACITOR
C 641 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 642 NCB31CK-103X C CAPACITOR
C 643 NCB31AK-474X C CAPACITOR
C 644 NCB31CK-103X C CAPACITOR
C 645 NCS31HJ-101X C CAPACITOR
C 646 NCB31CK-103X C CAPACITOR
C 647 NCS31HJ-220X C CAPACITOR
C 648 NCS31HJ-180X C CAPACITOR
C 649 NCS31HJ-121X C CAPACITOR
C 653 NCB31CK-104X C CAPACITOR
C 654 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 661 NCB31CK-103X C CAPACITOR
C 671 NCB31CK-103X C CAPACITOR
C 672 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 673 NCB31CK-103X C CAPACITOR
C 677 NCS31HJ-101X C CAPACITOR
C 679 NCS31HJ-101X C CAPACITOR
C 681 NCB31CK-103X C CAPACITOR
C 682 NCB31CK-103X C CAPACITOR
C 683 NCB31CK-103X C CAPACITOR
C 684 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 685 QETN1CM-476Z E CAPACITOR 47MF 20% 16V
C 686 QETN1CM-476Z E CAPACITOR 47MF 20% 16V
C 687 NCB31CK-103X C CAPACITOR
C 688 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 689 NCB31CK-103X C CAPACITOR
C 690 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 693 NCB31CK-103X C CAPACITOR
C 694 NCF31CZ-104X C CAPACITOR
CN681 QGB2510K1-20 B TO B CONNE
C2500 QETN1CM-226Z E CAPACITOR 22MF 20% 16V
C2503 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2504 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2507 NCS31HJ-330X C CAPACITOR
C2508 NCS31HJ-330X C CAPACITOR
C2512 NCF31CZ-104X C CAPACITOR
C2513 NCB31HK-122X C CAPACITOR
C2514 NCB31HK-122X C CAPACITOR
C2515 NCS31HJ-121X C CAPACITOR
C2516 NCS31HJ-121X C CAPACITOR
C2517 NCS31HJ-391X C CAPACITOR
C2518 NCS31HJ-391X C CAPACITOR
C2525 NCB31HK-102X C CAPACITOR
C2526 NCB31HK-102X C CAPACITOR
C2527 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2528 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2531 NCS31HJ-560X C CAPACITOR
C2532 NCS31HJ-560X C CAPACITOR
C2533 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2534 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2539 NCF31CZ-104X C CAPACITOR
C2540 NCF31CZ-104X C CAPACITOR
C2551 NCS31HJ-560X C CAPACITOR
C2552 NCS31HJ-560X C CAPACITOR
C2555 NCF31CZ-104X C CAPACITOR
C2556 NCF31CZ-104X C CAPACITOR
C2561 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C2562 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C2563 NCS31HJ-220X C CAPACITOR
C2564 NCS31HJ-220X C CAPACITOR
C2569 NCF31CZ-104X C CAPACITOR
C2570 NCF31CZ-104X C CAPACITOR
C2575 NCB31HK-102X C CAPACITOR
C2576 NCB31HK-102X C CAPACITOR
C2577 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2578 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2581 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C2582 QETN1CM-106Z E CAPACITOR 10MF 20% 16V
C2583 NCS31HJ-220X C CAPACITOR
C2584 NCS31HJ-560X C CAPACITOR
C2585 NCF31CZ-104X C CAPACITOR
C2586 NCF31CZ-104X C CAPACITOR
C2587 NCS31HJ-560X C CAPACITOR
C2588 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C2589 NCF31CZ-104X C CAPACITOR
C2590 NCF31CZ-104X C CAPACITOR
C2592 NCB31HK-223X C CAPACITOR
C2594 NCF31CZ-104X C CAPACITOR
C2595 NCB31HK-102X C CAPACITOR
C2597 QETN1HM-106Z E CAPACITOR 10MF 20% 50V
C2598 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
D 607 1SS355-X DIODE
D 608 1SS355-X DIODE
IC601 AK4527BVQ IC
IC609 BA15218F-XE IC
IC610 BA15218F-XE IC
IC611 BU4066BCF-X IC
IC621 TC7SU04FU-X IC
IC622 TC7SU04FU-X IC
IC631 TC9446F-014 IC
IC641 W24L010AJ-12-X IC
IC650 BA15218F-XE IC
IC651 BA15218F-XE IC
IC652 IMX9-W TRANSISTOR
IC661 BA15218F-XE IC
IC662 IMX9-W TRANSISTOR
IC671 UPD784215AGC103 IC
IC672 TC7SET32FU-X IC
IC681 PQ3DZ53-X IC
(DSP board)
