RX-6032VSL
3-14
Item
Parts number Parts name Area
Electrical parts list (Power amp. board)
Remarks
Block No. 03
A
R 951 QRJ125J-330 UNF.C.RESISTOR
A
33 5% 1/2W
R 953 QRL027J-100 UNF.OMF.RES.
A
10 5% 1/2W
R 955 QRE141J-332Y C RESISTOR
3.3K 5% 1/4W
R 957 QRE141J-332Y C RESISTOR
3.3K 5% 1/4W
R 959 QRE141J-332Y C RESISTOR
3.3K 5% 1/4W
R 961 QRE141J-332Y C RESISTOR
3.3K 5% 1/4W
R 963 QRE141J-272Y C RESISTOR
2.7K 5% 1/4W
RY202 QSK0142-001 RELAY
A
RY203 QSK0109-001 RELAY
A
T 202 QQT0317-001 POWER TRANSF
A
TA201 QNZ0079-001Z TAB
TA202 QNZ0079-001Z TAB
TH301 QAD0012-202 BATTERY PACK
A
TH302 QAD0012-202 BATTERY PACK
A
TH801 QAD0012-202 BATTERY PACK
A
TH802 QAD0012-202 BATTERY PACK
A
TH901 QAD0012-202 BATTERY PACK
A
VR301 QVP0008-102Z SEMI V RESISTOR
VR302 QVP0008-102Z SEMI V RESISTOR
