JVC RX-6032VSL Service Manual

RX-6032VSL
3-5
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
A
C 419 QCBB1HK-223Y C CAPACITOR
.022MF 10% 50V
C 420 QCBB1HK-223Y C CAPACITOR
.022MF 10% 50V
C 421 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 422 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 423 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 424 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 425 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 426 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 427 QCBB1HK-221Y C CAPACITOR
220PF 10% 50V
C 428 QCBB1HK-221Y C CAPACITOR
220PF 10% 50V
C 429 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 430 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 431 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 432 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 433 QCBB1HK-221Y C CAPACITOR
220PF 10% 50V
C 434 QCBB1HK-221Y C CAPACITOR
220PF 10% 50V
C 435 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 436 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 440 QCBB1HK-221Y C CAPACITOR
220PF 10% 50V
C 441 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 442 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 443 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 444 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 445 QCBB1HK-223Y C CAPACITOR
.022MF 10% 50V
C 446 QCBB1HK-223Y C CAPACITOR
.022MF 10% 50V
C 451 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 452 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 453 QCBB1HK-331Y C CAPACITOR
FOR 6030
C 454 QCBB1HK-331Y C CAPACITOR
FOR 6030
C 455 QCBB1HK-331Y C CAPACITOR
FOR 6030
C 456 QCBB1HK-331Y C CAPACITOR
FOR 6030
C 460 QCZ0202-155Z ML C CAPACITOR
1.5MF
C 461 QETN1HM-475Z E CAPACITOR
FOR 6030
C 463 QETN1HM-475Z E CAPACITOR
FOR 6030
C 481 QCBB1HK-223Y C CAPACITOR
FOR 6030
C 482 QCBB1HK-223Y C CAPACITOR
FOR 6030
C 551 QDX31EM-473Z C CAPACITOR
C 552 QEKC1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 555 QDX31EM-473Z C CAPACITOR
C 556 QETN0JM-477Z E CAPACITOR
470MF 20% 6.3V
C 557 QCS31HJ-470Z C CAPACITOR
47PF 5% 50V
C 558 QCS31HJ-470Z C CAPACITOR
47PF 5% 50V
C 559 QDX31EM-473Z C CAPACITOR
C 560 QEKC1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 561 QDX31EM-473Z C CAPACITOR
C 562 QETN0JM-477Z E CAPACITOR
470MF 20% 6.3V
C 563 QCS31HJ-470Z C CAPACITOR
47PF 5% 50V
C 564 QCS31HJ-470Z C CAPACITOR
47PF 5% 50V
C 581 QEKC1CM-476Z E CAPACITOR
47MF 20% 16V
C 582 QCZ0202-155Z ML C CAPACITOR
1.5MF
C 583 QEKC1CM-476Z E CAPACITOR
47MF 20% 16V
C 584 QCZ0202-155Z ML C CAPACITOR
1.5MF
CN311 QGB2510J1-14 CONNECTOR
CN312 QGB2510J1-14 CONNECTOR
CN321 QGB2510J1-14 CONNECTOR
CN331 QGB2510J1-14 CONNECTOR
CN332 QGB2510J1-14 CONNECTOR
CN351 QJK012-032403 SKT WIRE ASSY
CN371 QJP001-031201 SHI CR C-B WIRE
CN372 QJP002-021201 SHI CR C-B WIRE
CN373 QJP001-031201 SHI CR C-B WIRE
CN401 QGB2510K1-14 CONNECTOR
CN451 QGB2510K1-11 CONNECTOR
CN511 QGD2503F1-03 SOCKET
CN551 QGB2510K1-08 CONNECTOR
C1301 QFZ9076-104Z MM CAPACITOR
.10MF
C1302 QCE22HP-103 C CAPACITOR
.010MF +100:-0%
C1303 QCE22HP-103 C CAPACITOR
.010MF +100:-0%
C1304 QEZ0341-688 E CAPACITER
6800MF
C1305 QEZ0341-688 E CAPACITER
6800MF
C1306 QETN1EM-476Z E CAPACITOR
47MF 20% 25V
C1308 QETN1HM-476Z E CAPACITOR
47MF 20% 50V
C1309 QEKC1HM-106Z E CAPACITOR
10MF 20% 50V
C1310 QEKC1CM-476Z E CAPACITOR
47MF 20% 16V
C1311 QEKC1HM-226Z E CAPACITOR
22MF 20% 50V
C1351 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1352 QEKC1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1353 QEKC1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1354 QEKC1HM-475Z E CAPACITOR
4.7MF 20% 50V
D1301 30DF2-FC DIODE
A
D1302 30DF2-FC DIODE
A
D1303 30DF2-FC DIODE
A
D1304 30DF2-FC DIODE
A
D1305 MTZJ18C-T2 Z.DIODE
D1306 MTZJ30C-T2 ZENER DIODE
D1307 1SS133-T2 SI DIODE
D1308 1SS133-T2 SI DIODE
D1309 MTZJ20C-T2 Z.DIODE
D1352 1SS133-T2 SI DIODE
D1353 1SS133-T2 SI DIODE
D1354 1SS133-T2 SI DIODE
D1355 1SS133-T2 SI DIODE
D1356 MTZJ5.1C-T2 ZENER DIODE
D1357 1SS133-T2 SI DIODE
D1358 1SS133-T2 SI DIODE
D1359 1SS133-T2 SI DIODE
D1360 1SS133-T2 SI DIODE
EP301 QNZ0136-001Z EARTH PLATE
FW301 QUM215-25Z4Z4 PARA RIBON WIRE
FW302 QUM216-25Z4Z4 FLAT WIRE
FW303 QUM215-28DGZ4 PARA RIBON WIRE
FW341 QUM215-20DGZ4 SOCKET
IC402 TC9164AN IC
IC403 BA15218N IC
IC451 BA15218 IC
FOR 6030
IC551 NJM2246D IC
IC552 NJM2246D IC
J 402 QNN0168-001 PIN JACK
CD
,
TAPE
(
R/P
)
J 403 QNN0168-001 PIN JACK
VCR
(
R/P
),
DBS
J 404 QNN0389-001 PIN JACK
DVD FL/FR
J 405 QNN0388-001 PIN JACK
FOR 6030
J 406 QNN0060-001 PIN JACK
J 551 QND0091-001 S JACK
M.OUT
,
DVD
J 552 QND0091-001 S JACK
VCR
(
R/P
)
Q
553 KTC3199/GL/-T TRANSISTOR
Q
554 KTC3199/GL/-T TRANSISTOR
Q
571 KTC3199/GL/-T TRANSISTOR
Q
572 KTC3199/GL/-T TRANSISTOR
Q
573 KRC107M-T D.TRANSISTOR
Q
574 KRC107M-T D.TRANSISTOR
Q
1301 KTA1046/Y/ TRANSISTOR
A
Q
1302 KTC3200/GL/-T TRANSISTOR
Q
1303 KTA1268/GL/-T TRANSISTOR
Q
1304 KTC3199/GL/-T TRANSISTOR
Q
1305 2SD2395/EF/ TRANSISTOR
Q
1306 KTA1023/OY/-T TRANSISTOR
Q
1307 KTC3200/GL/-T TRANSISTOR
Q
1351 KRC109M-T D.TRANSISTOR
Q
1352 KRC109M-T D.TRANSISTOR
Q
1353 KRC109M-T D.TRANSISTOR
Q
1354 KRC109M-T D.TRANSISTOR
Q
1355 KRC109M-T D.TRANSISTOR
Item
Parts number Parts name Area
Remarks
A
