JVC RX-6032VSL Service Manual

RX-6032VSL
3-6
Item
Parts number Parts name Area
Electrical parts list (Main board)
Remarks
Block No. 01
A
Q
1356 KRC109M-T D.TRANSISTOR
Q
1357 KRC109M-T D.TRANSISTOR
Q
1358 KRC109M-T D.TRANSISTOR
R 421 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 422 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 423 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 424 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 425 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 426 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 429 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 430 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 431 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 432 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 435 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 436 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 440 QRE141J-102Y C RESISTOR
1.0K 5% 1/4W
R 441 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 442 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 443 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 444 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 445 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 446 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 449 QRJ146J-271X UNF C RESISTOR
A
270 5% 1/4W
R 450 QRJ146J-271X UNF C RESISTOR
A
270 5% 1/4W
R 451 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 452 QRE141J-471Y C RESISTOR
470 5% 1/4W
R 453 QRE141J-471Y C RESISTOR
FOR 6030
R 454 QRE141J-471Y C RESISTOR
FOR 6030
R 455 QRE141J-471Y C RESISTOR
FOR 6030
R 456 QRE141J-471Y C RESISTOR
FOR 6030
R 458 QRJ146J-271X UNF C RESISTOR
FOR 6030
R 459 QRJ146J-271X UNF C RESISTOR
FOR 6030
R 462 QRE141J-104Y C RESISTOR
FOR 6030
R 464 QRE141J-104Y C RESISTOR
FOR 6030
R 551 QRE141J-750Y C RESISTOR
75 5% 1/4W
R 552 QRE141J-750Y C RESISTOR
75 5% 1/4W
R 555 QRE141J-750Y C RESISTOR
75 5% 1/4W
R 556 QRE141J-750Y C RESISTOR
75 5% 1/4W
R 557 QRE141J-473Y C RESISTOR
47K 5% 1/4W
R 558 QRE141J-473Y C RESISTOR
47K 5% 1/4W
R 559 QRE141J-750Y C RESISTOR
75 5% 1/4W
R 560 QRE141J-750Y C RESISTOR
75 5% 1/4W
R 561 QRE141J-750Y C RESISTOR
75 5% 1/4W
R 562 QRE141J-750Y C RESISTOR
75 5% 1/4W
R 563 QRE141J-473Y C RESISTOR
47K 5% 1/4W
R 564 QRE141J-473Y C RESISTOR
47K 5% 1/4W
R 565 QRE141J-431Y C RESISTOR
430 5% 1/4W
R 566 QRE141J-241Y C RESISTOR
240 5% 1/4W
R 571 QRE141J-431Y C RESISTOR
430 5% 1/4W
R 572 QRE141J-241Y C RESISTOR
240 5% 1/4W
R 573 QRE141J-751Y C RESISTOR
750 5% 1/4W
R 574 QRE141J-751Y C RESISTOR
750 5% 1/4W
R 581 QRJ146J-6R8X UNF C RESISTOR
6.8 5% 1/4W
RY302 QSK0109-001 RELAY
A
RY303 QSK0109-001 RELAY
A
RY304 QSK0109-001 RELAY
A
R1301 QRL027J-332 UNF.OMF.RES.
A
3.3K 5% 1/2W
R1302 QRZ9005-100X F RESISTOR
A
10 1/4W
R1303 QRJ146J-562X UNF C RESISTOR
A
5.6K 5% 1/4W
R1304 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R1305 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R1306 QRE141J-823Y C RESISTOR
82K 5% 1/4W
R1307 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R1308 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R1309 QRE141J-103Y C RESISTOR
10K 5% 1/4W
R1310 QRE141J-103Y C RESISTOR
10K 5% 1/4W
R1311 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R1312 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R1313 QRZ9005-100X F RESISTOR
A
10 1/4W
R1314 QRJ146J-103X UNF C RESISTOR
A
10K 5% 1/4W
R1315 QRJ146J-2R2X UNF C RESISTOR
A
2.2 5% 1/4W
R1316 QRJ146J-102X UNF C RESISTOR
A
1.0K 5% 1/4W
R1317 QRJ146J-223X UNF C RESISTOR
A
22K 5% 1/4W
R1318 QRE141J-223Y C RESISTOR
22K 5% 1/4W
R1319 QRE141J-473Y C RESISTOR
47K 5% 1/4W
R1352 QRJ146J-680X UNF C RESISTOR
A
68 5% 1/4W
R1353 QRJ146J-680X UNF C RESISTOR
A
68 5% 1/4W
R1354 QRJ146J-680X UNF C RESISTOR
A
68 5% 1/4W
R1355 QRJ146J-392X UNF C RESISTOR
A
3.9K 5% 1/4W
R1356 QRE141J-472Y C RESISTOR
4.7K 5% 1/4W
R1357 QRE141J-223Y C RESISTOR
22K 5% 1/4W
R1358 QRE141J-682Y C RESISTOR
6.8K 5% 1/4W
R1359 QRE141J-472Y C RESISTOR
4.7K 5% 1/4W
R1360 QRE141J-472Y C RESISTOR
4.7K 5% 1/4W
R1361 QRE141J-472Y C RESISTOR
4.7K 5% 1/4W
R1362 QRE141J-472Y C RESISTOR
4.7K 5% 1/4W
R1363 QRE141J-472Y C RESISTOR
4.7K 5% 1/4W
R1364 QRE141J-223Y C RESISTOR
22K 5% 1/4W
R1365 QRE141J-682Y C RESISTOR
6.8K 5% 1/4W
R1366 QRE141J-223Y C RESISTOR
22K 5% 1/4W
R1367 QRE141J-682Y C RESISTOR
6.8K 5% 1/4W
ST304 QNB0103-002 SPK TERMINAL
5030/6030 C/R
ST305 QNB0001-002 SPK TERMINAL
5030/6030 FRONT
Item
Parts number Parts name Area
Remarks
A
