JVC RX-6032VSL Service Manual

RX-6032VSL
3-7
Item
Parts number Parts name Area
Electrical parts list (Front board)
Remarks
Block No. 02
A
BK701 LV42093-001A FL HOLDER(L)
BK702 LV42092-001A FL HOLDER(R)
C 101 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 102 QCBB1HK-331Y C CAPACITOR
330PF 10% 50V
C 701 QEKC0JM-107Z E CAPACITOR
100MF 20% 6.3V
C 702 QCZ0202-155Z ML C CAPACITOR
1.5MF
C 703 QEKC1HM-225Z E CAPACITOR
2.2MF 20% 50V
C 704 NCB31CK-223X C CAPACITOR
C 705 QEKC0JM-107Z E CAPACITOR
100MF 20% 6.3V
C 706 NCB21HK-331X C CAPACITOR
C 707 QEKC1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 708 QEKC1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 709 QEKC1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 713 NCB21HK-103X C CAPACITOR
C 714 NCB21HK-103X C CAPACITOR
C 715 NCB21HK-103X C CAPACITOR
C 716 NCB21HK-103X C CAPACITOR
C 717 NCB21HK-103X C CAPACITOR
C 718 NCB21HK-103X C CAPACITOR
C 719 NCB21HK-103X C CAPACITOR
C 720 NCB31CK-104X C CAPACITOR
C 721 NCB31CK-104X C CAPACITOR
C 722 QCZ0202-155Z ML C CAPACITOR
1.5MF
C 723 NCB31CK-104X C CAPACITOR
C 724 NCB31CK-104X C CAPACITOR
C 725 QEKC1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 730 NCB31CK-104X C CAPACITOR
CN101 QGD2503F1-03 SOCKET
CN402 QGF1205C1-25 CONNECTOR
CN411 QGB2501J1-12 CONNECTOR
CN421 QGB2510J1-14 CONNECTOR
CN431 QGB2510J1-11 CONNECTOR
CN441 QGB2510J1-07 CONNECTOR
CN461 QGB2510J1-08 CONNECTOR
S-VIDEO 6030
CN471 QGA2501C1-03 3P CONNECTOR
CN472 QGA2501C1-02 2P CONNECTOR
CN473 QGA2501C1-03 3P CONNECTOR
CN481 QGB2510J1-20 CONNECTOR
CN491 QGB2510J1-04 CONNECTOR
CN701 QGF1205F1-14 CONNECTOR
CN702 QGF1205F1-25 CONNECTOR
CN704 WJS0020-002A SKT.WIRE ASS'Y
CN714 QGA2001F1-03 CONNECTOR
C1401 QETN1HM-476Z E CAPACITOR
47MF 20% 50V
C1402 QETN1EM-107Z E CAPACITOR
100MF 20% 25V
C1403 QETN1EM-107Z E CAPACITOR
100MF 20% 25V
C1404 QETN1EM-107Z E CAPACITOR
100MF 20% 25V
C1405 QETN1EM-107Z E CAPACITOR
100MF 20% 25V
C1406 QETN1EM-107Z E CAPACITOR
100MF 20% 25V
C1407 QCF31HZ-223Z C CAPACITOR
.022MF +80:-20%
C1408 QETN1EM-476Z E CAPACITOR
47MF 20% 25V
C1409 QETN1EM-476Z E CAPACITOR
47MF 20% 25V
C1410 NCB31CK-223X C CAPACITOR
C1411 NCB31CK-223X C CAPACITOR
C1412 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1413 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1414 NCS31HJ-101X C CAPACITOR
C1415 NCS31HJ-101X C CAPACITOR
C1416 QETN1HM-474Z E CAPACITOR
.47MF 20% 50V
C1417 QETN1HM-474Z E CAPACITOR
.47MF 20% 50V
C1418 QFLC1HJ-223Z M CAPACITOR
.022MF 5% 50V
C1419 QFLC1HJ-223Z M CAPACITOR
.022MF 5% 50V
C1422 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1423 QEKC1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1424 QEKC1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1425 QEKC1CM-106Z E CAPACITOR
10MF 20% 16V
C1426 NCB31CK-223X C CAPACITOR
C1427 QFVF1HJ-334Z MF CAPACITOR
.33MF 5% 50V
C1428 QFLC1HJ-153Z M CAPACITOR
.015MF 5% 50V
C1429 QCB31HK-822Z C CAPACITOR
8200PF 10% 50V
C1430 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1431 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1432 NCB31CK-223X C CAPACITOR
C1433 QFVF1HJ-334Z MF CAPACITOR
.33MF 5% 50V
C1434 QFLC1HJ-153Z M CAPACITOR
.015MF 5% 50V
C1435 QCB31HK-822Z C CAPACITOR
8200PF 10% 50V
C1436 NCB31CK-223X C CAPACITOR
C1437 QCZ0202-155Z ML C CAPACITOR
1.5MF
C1438 QETN0JM-477Z E CAPACITOR
470MF 20% 6.3V
C1439 QFLC1HJ-562Z M CAPACITOR
5600PF 5% 50V
C1440 QFLC1HJ-562Z M CAPACITOR
5600PF 5% 50V
C1443 QCZ0202-155Z ML C CAPACITOR
S-VIDEO 6030
C1444 NCB31CK-223X C CAPACITOR
C1445 NCB31CK-223X C CAPACITOR
C1446 NCB31HK-221X C CAPACITOR
C1447 QEKC1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1453 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1459 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1460 NCB31CK-223X C CAPACITOR
C1461 NCB31CK-223X C CAPACITOR
C1463 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1464 QETN1HM-475Z E CAPACITOR
4.7MF 20% 50V
C1465 QETN1HM-106Z E CAPACITOR
10MF 20% 50V
C1501 QEKC1AM-476Z E CAPACITOR
FOR 6030
C1502 QCF31HZ-103Z C CAPACITOR
FOR 6030
C1503 QETN1AM-107Z E CAPACITOR
FOR 6030
C1504 QCF31HZ-103Z C CAPACITOR
FOR 6030
C1505 QEKC1AM-476Z E CAPACITOR
FOR 6030
C1506 NCS31HJ-470X C CAPACITOR
FOR 6030
C1507 QEKC1HM-475Z E CAPACITOR
FOR 6030
C1508 NCS31HJ-470X C CAPACITOR
FOR 6030
C1509 QEKC1HM-475Z E CAPACITOR
FOR 6030
C1510 NCS31HJ-470X C CAPACITOR
FOR 6030
C1511 QEKC1AM-476Z E CAPACITOR
FOR 6030
C1512 NCS31HJ-470X C CAPACITOR
FOR 6030
C1513 QEKC1HM-475Z E CAPACITOR
FOR 6030
C1514 NCS31HJ-470X C CAPACITOR
FOR 6030
C1515 QEKC1HM-475Z E CAPACITOR
FOR 6030
C1516 NCS31HJ-470X C CAPACITOR
FOR 6030
C1517 QETN0JM-477Z E CAPACITOR
FOR 6030
C1518 NCS31HJ-101X C CAPACITOR
FOR 6030
C1519 QETN1AM-107Z E CAPACITOR
FOR 6030
C1520 NCS31HJ-101X C CAPACITOR
FOR 6030
C1521 QETN1AM-107Z E CAPACITOR
FOR 6030
C1522 NCS31HJ-101X C CAPACITOR
FOR 6030
C1523 QEKC1AM-107Z E CAPACITOR
FOR 6030
C1524 QEKC1CM-226Z E CAPACITOR
FOR 6030
C1525 QEKC1AM-476Z E CAPACITOR
FOR 6030
C1526 QEKC1AM-476Z E CAPACITOR
FOR 6030
C1530 QCZ0202-155Z ML C CAPACITOR
FOR 6030
D 701 1SS355-X DIODE
D 702 1SS355-X DIODE
AVCOMPULINK
D 703 SB007-03CP-X S.K DIODE
D 719 SLR-343VC/NPQ-T LED
DI701 QLF0098-001 FL TUBE
D1401 MTZJ13C-T2 ZENER DIODE
D1402 MTZJ6.2C-T2 ZENER DIODE
D1403 MTZJ5.6C-T2 ZENER DIODE
D1404 MTZJ5.6C-T2 ZENER DIODE
D1405 MTZJ13C-T2 ZENER DIODE
D1406 MTZJ10C-T2 Z.DIODE
D1407 MTZJ7.5C-T2 ZENER DIODE
