JVC RX-6032VSL Service Manual

RX-6032VSL
3-8
Item
Parts number Parts name Area
Electrical parts list (Front board)
Remarks
Block No. 02
A
D1408 MTZJ7.5C-T2 ZENER DIODE
D1409 MA152WK-X SI DIODE
D1411 1SS355-X DIODE
D1412 1SS355-X DIODE
D1501 11ES2-T4 DIODE
FOR 6030
EP401 QNZ0136-001Z EARTH PLATE
FL401 QQR0590-001 FILTER
FL402 QQR0590-001 FILTER
FW501 QUM213-10DGZ4 PARA RIBON WIRE
FOR 6030
HS401 E70306-001 HEAT SINK
HS402 E70306-001 HEAT SINK
HS403 E70306-001 HEAT SINK
HS404 E70306-001 HEAT SINK
HS405 E70306-001 HEAT SINK
HS434 E70306-001 HEAT SINK
HS435 E70306-001 HEAT SINK
IC421 BA15218F-XE IC
IC422 BA15218F-XE IC
IC423 TC9162AF-X IC
IC427 BA15218F-XE IC
IC428 M62446AFP-X IC
IC581 MM74HC4053SJ-X I.C
FOR 6030
IC582 NJM2580M-X I.C
FOR 6030
IC701 MN101C35DME IC
IC702 IC-PST9139-T IC
IC703 GP1UM281XK IR DETECT UNIT
J 101 QNS0022-001 JACK
JS701 QSW1017-002 JOG VOLUME
JS702 QSW1016-001 ROTARY ENCODER
J1501 QNN0391-001 PIN JACK
FOR 6030
Q
701 UN2214-X TRANSISTOR
Q
702 UN2215-X TRANSISTOR
Q
703 DTC144WKA-X TRANSISTOR
Q
704 UN2214-X TRANSISTOR
AVCOMPULINK
Q
707 UN2214-X TRANSISTOR
Q
708 UN2214-X TRANSISTOR
Q
709 UN2214-X TRANSISTOR
Q
711 UN2113-X TRANSISTOR
Q
1401 KTA1046/Y/ TRANSISTOR
A
Q
1402 2SD2395/EF/ TRANSISTOR
A
Q
1403 2SD2395/EF/ TRANSISTOR
A
Q
1404 2SD2395/EF/ TRANSISTOR
A
Q
1405 2SD2395/EF/ TRANSISTOR
A
Q
1406 KTC3203/OY/-T TRANSISTOR
A
Q
1407 KTC3203/OY/-T TRANSISTOR
A
Q
1408 KTA1271/OY/-T TRANSISTOR
A
Q
1409 2SK301/PQ/-T FET
Q
1410 2SK301/PQ/-T FET
Q
1411 2SK301/PQ/-T FET
Q
1412 2SK301/PQ/-T FET
Q
1413 2SC3576-JVC-T TRANSISTOR
Q
1414 2SC3576-JVC-T TRANSISTOR
Q
1415 KRA104M-T D.TRANSISTOR
Q
1416 KRC104M-T D.TRANSISTOR
Q
1417 2SC3576-JVC-T TRANSISTOR
Q
1418 2SC3576-JVC-T TRANSISTOR
Q
1419 2SC3576-JVC-T TRANSISTOR
Q
1420 KRA104M-T D.TRANSISTOR
Q
1421 2SC3576-JVC-T TRANSISTOR
Q
1422 2SC3576-JVC-T TRANSISTOR
Q
1423 KRA104M-T D.TRANSISTOR
Q
1424 KRA104M-T D.TRANSISTOR
Q
1425 2SC3576-JVC-T TRANSISTOR
Q
1426 2SC3576-JVC-T TRANSISTOR
Q
1431 KRC104M-T D.TRANSISTOR
Q
1432 KRC104M-T D.TRANSISTOR
Q
1433 KRC104M-T D.TRANSISTOR
Q
1434 2SD2395/EF/ TRANSISTOR
A
Q
1435 2SD2395/EF/ TRANSISTOR
A
R 101 QRL027J-471 UNF OMF.RES.
A
470 5% 1/2W
R 102 QRL027J-471 UNF OMF.RES.
A
470 5% 1/2W
R 475 NRSA63J-203X MG RESISTOR
R 476 NRSA63J-273X MG RESISTOR
R 477 QRZ9006-4R7X F RESISTOR
4.7 1/4W
R 478 QRJ146J-2R2X UNF C RESISTOR
2.2 5% 1/4W
R 479 QRJ146J-2R2X UNF C RESISTOR
2.2 5% 1/4W
R 480 NRSA63J-512X MG RESISTOR
R 481 NRSA63J-104X MG RESISTOR
R 482 NRSA63J-104X MG RESISTOR
R 483 NRSA63J-102X MG RESISTOR
R 484 NRSA63J-104X MG RESISTOR
R 485 NRSA63J-102X MG RESISTOR
R 486 NRSA63J-104X MG RESISTOR
R 487 NRSA63J-102X MG RESISTOR
R 488 NRSA63J-104X MG RESISTOR
R 489 NRSA63J-103X MG RESISTOR
R 490 NRSA63J-103X MG RESISTOR
R 491 NRSA63J-512X MG RESISTOR
R 492 NRSA63J-301X MG RESISTOR
DVD MULTI 6030
R 493 NRSA63J-0R0X MG RESISTOR
DVD MULTI 6030
R 494 NRSA63J-0R0X MG RESISTOR
DVD MULTI 6030
R 495 NRSA63J-0R0X MG RESISTOR
DVD MULTI 6030
R 496 NRSA63J-102X MG RESISTOR
DVD MULTI 6030
R 701 NRSA63J-472X MG RESISTOR
R 702 NRSA63J-223X MG RESISTOR
R 704 NRSA63J-471X MG RESISTOR
R 705 NRSA63J-103X MG RESISTOR
R 706 NRSA63J-103X MG RESISTOR
AVCOMPULINK
R 707 NRSA63J-103X MG RESISTOR
R 708 NRSA63J-103X MG RESISTOR
R 709 NRSA63J-103X MG RESISTOR
R 710 NRSA63J-103X MG RESISTOR
R 711 NRSA63J-104X MG RESISTOR
R 712 NRSA63J-103X MG RESISTOR
R 713 NRSA63J-103X MG RESISTOR
R 714 NRSA63J-103X MG RESISTOR
R 715 NRSA63J-103X MG RESISTOR
R 716 NRSA63J-103X MG RESISTOR
R 717 NRSA63J-103X MG RESISTOR
R 718 NRSA63J-103X MG RESISTOR
R 719 NRSA63J-221X MG RESISTOR
R 720 NRSA63J-222X MG RESISTOR
R 721 NRSA63J-103X MG RESISTOR
R 722 NRSA63J-102X MG RESISTOR
R 723 NRSA63J-102X MG RESISTOR
R 724 NRSA63J-122X MG RESISTOR
R 725 NRSA63J-152X MG RESISTOR
R 726 NRSA63J-222X MG RESISTOR
R 727 NRSA63J-272X MG RESISTOR
R 728 NRSA63J-103X MG RESISTOR
R 729 NRSA63J-102X MG RESISTOR
R 730 NRSA63J-102X MG RESISTOR
R 731 NRSA63J-122X MG RESISTOR
R 732 NRSA63J-152X MG RESISTOR
R 733 NRSA63J-222X MG RESISTOR
R 734 NRSA63J-272X MG RESISTOR
R 736 NRSA63J-103X MG RESISTOR
R 737 NRSA63J-102X MG RESISTOR
R 738 NRSA63J-102X MG RESISTOR
R 739 NRSA63J-122X MG RESISTOR
R 740 NRSA63J-152X MG RESISTOR
R 741 NRSA63J-222X MG RESISTOR
Item
Parts number Parts name Area
Remarks
A
