JVC RX-6032VSL Service Manual

RX-6032VSL
3-9
Item
Parts number Parts name Area
Electrical parts list (Front board)
Remarks
Block No. 02
A
R 742 NRSA63J-272X MG RESISTOR
FOR S739
(
6030
)
R 743 NRSA63J-103X MG RESISTOR
R 744 NRSA63J-102X MG RESISTOR
R 745 NRSA63J-102X MG RESISTOR
R 746 NRSA63J-122X MG RESISTOR
R 747 NRSA63J-152X MG RESISTOR
R 748 NRSA63J-222X MG RESISTOR
R 749 NRSA63J-272X MG RESISTOR
R 750 NRSA63J-103X MG RESISTOR
R 751 NRSA63J-102X MG RESISTOR
R 752 NRSA63J-102X MG RESISTOR
R 753 NRSA63J-122X MG RESISTOR
R 754 NRSA63J-152X MG RESISTOR
R 757 NRSA63J-103X MG RESISTOR
R 758 NRSA63J-103X MG RESISTOR
R 759 NRSA63J-103X MG RESISTOR
R 760 NRSA63J-103X MG RESISTOR
R 761 NRSA63J-103X MG RESISTOR
R 762 NRSA63J-102X MG RESISTOR
R 768 NRSA63J-103X MG RESISTOR
R 769 NRSA63J-102X MG RESISTOR
R 770 NRSA63J-102X MG RESISTOR
R 771 NRSA63J-122X MG RESISTOR
R 772 NRSA63J-222X MG RESISTOR
R 773 NRSA63J-272X MG RESISTOR
R 775 NRSA63J-103X MG RESISTOR
R 776 NRSA63J-152X MG RESISTOR
R 779 NRSA63J-103X MG RESISTOR
R 783 NRSA63J-221X MG RESISTOR
R 784 NRSA63J-221X MG RESISTOR
R 785 NRSA63J-221X MG RESISTOR
R 786 NRSA63J-221X MG RESISTOR
R 787 NRSA63J-221X MG RESISTOR
R 788 NRSA63J-221X MG RESISTOR
R 789 NRSA63J-221X MG RESISTOR
R 790 NRSA63J-221X MG RESISTOR
R 791 NRSA63J-221X MG RESISTOR
R 792 NRSA63J-221X MG RESISTOR
R 793 NRSA63J-221X MG RESISTOR
R 794 NRSA63J-221X MG RESISTOR
R 795 NRSA63J-221X MG RESISTOR
R 796 NRSA63J-221X MG RESISTOR
R 797 NRSA63J-221X MG RESISTOR
R 798 NRSA63J-221X MG RESISTOR
R 799 NRSA63J-221X MG RESISTOR
R 871 NRSA63J-103X MG RESISTOR
R 872 NRSA63J-103X MG RESISTOR
R 873 NRSA63J-103X MG RESISTOR
R 874 NRSA63J-103X MG RESISTOR
R 875 NRSA63J-103X MG RESISTOR
R 876 NRSA63J-103X MG RESISTOR
R 877 NRSA63J-103X MG RESISTOR
R1401 QRZ9005-100X F RESISTOR
A
10 1/4W
R1402 QRJ146J-182X UNF C RESISTOR
A
1.8K 5% 1/4W
R1403 QRZ9005-120X F RESISTOR
A
12 1/4W
R1404 QRJ146J-272X UNF C RESISTOR
A
2.7K 5% 1/4W
R1405 QRZ9005-120X F RESISTOR
A
12 1/4W
R1406 QRK126J-682X C RESISTOR
A
6.8K 5% 1/2W
R1407 QRZ9006-4R7X F RESISTOR
A
4.7 1/4W
R1408 QRZ9006-4R7X F RESISTOR
A
4.7 1/4W
R1409 QRJ146J-272X UNF C RESISTOR
A
2.7K 5% 1/4W
R1410 QRZ9006-4R7X F RESISTOR
A
4.7 1/4W
R1411 QRJ146J-182X UNF C RESISTOR
A
1.8K 5% 1/4W
R1412 QRZ9005-100X F RESISTOR
A
10 1/4W
R1413 QRJ146J-102X UNF C RESISTOR
A
1.0K 5% 1/4W
R1414 QRZ9005-100X F RESISTOR
A
10 1/4W
R1415 QRJ146J-222X UNF C RESISTOR
A
2.2K 5% 1/4W
R1416 QRZ9005-100X F RESISTOR
A
10 1/4W
R1417 QRJ146J-222X UNF C RESISTOR
A
2.2K 5% 1/4W
R1418 QRZ9005-680X F RESISTOR
A
68 1/4W
R1419 QRZ9005-680X F RESISTOR
A
68 1/4W
R1420 NRSA63J-103X MG RESISTOR
R1421 NRSA63J-272X MG RESISTOR
R1422 NRSA63J-103X MG RESISTOR
R1423 NRSA63J-272X MG RESISTOR
R1424 NRSA63J-472X MG RESISTOR
R1425 NRSA63J-472X MG RESISTOR
R1426 NRSA63J-513X MG RESISTOR
R1427 NRSA63J-513X MG RESISTOR
R1428 NRSA63J-103X MG RESISTOR
R1429 NRSA63J-103X MG RESISTOR
R1430 NRSA63J-103X MG RESISTOR
R1431 NRSA63J-103X MG RESISTOR
R1432 NRSA63J-103X MG RESISTOR
R1433 NRSA63J-103X MG RESISTOR
R1434 NRSA63J-103X MG RESISTOR
R1435 NRSA63J-154X MG RESISTOR
R1436 NRSA63J-154X MG RESISTOR
R1437 NRSA63J-102X MG RESISTOR
R1438 NRSA63J-102X MG RESISTOR
R1439 NRSA63J-103X MG RESISTOR
R1440 NRSA63J-103X MG RESISTOR
R1442 NRSA63J-104X MG RESISTOR
FOR 6030
R1443 NRSA63J-103X MG RESISTOR
R1444 NRSA63J-103X MG RESISTOR
R1445 NRSA63J-102X MG RESISTOR
R1446 NRSA63J-104X MG RESISTOR
R1447 NRSA63J-102X MG RESISTOR
R1448 NRSA63J-103X MG RESISTOR
R1449 NRSA63J-102X MG RESISTOR
R1450 NRSA63J-103X MG RESISTOR
R1451 NRSA63J-104X MG RESISTOR
R1452 NRSA63J-104X MG RESISTOR
R1453 NRSA63J-102X MG RESISTOR
R1455 NRSA63J-104X MG RESISTOR
R1456 QRJ146J-220X UNF C RESISTOR
A
22 5% 1/4W
R1457 NRSA63J-472X MG RESISTOR
R1458 NRSA63J-472X MG RESISTOR
R1459 QRZ9005-680X F RESISTOR
A
68 1/4W
R1460 QRZ9005-680X F RESISTOR
A
68 1/4W
R1461 QRJ146J-2R2X UNF C RESISTOR
2.2 5% 1/4W
R1462 QRJ146J-2R2X UNF C RESISTOR
2.2 5% 1/4W
R1463 NRSA63J-104X MG RESISTOR
R1464 NRSA63J-104X MG RESISTOR
R1465 NRSA63J-102X MG RESISTOR
R1466 NRSA63J-104X MG RESISTOR
R1467 NRSA63J-104X MG RESISTOR
R1470 NRSA63J-391X MG RESISTOR
R1471 NRSA63J-391X MG RESISTOR
R1472 NRSA63J-103X MG RESISTOR
R1473 NRSA63J-103X MG RESISTOR
R1474 NRSA63J-102X MG RESISTOR
R1480 NRSA63J-104X MG RESISTOR
R1490 NRSA63J-273X MG RESISTOR
R1492 NRSA63J-102X MG RESISTOR
R1493 NRSA63J-102X MG RESISTOR
R1494 NRSA63J-102X MG RESISTOR
R1495 NRSA63J-103X MG RESISTOR
R1496 NRSA63J-103X MG RESISTOR
R1497 NRSA63J-511X MG RESISTOR
R1498 NRSA63J-511X MG RESISTOR
R1499 NRSA63J-104X MG RESISTOR
Item
Parts number Parts name Area
Remarks
A
