JVC RX-6032VSL Service Manual

RX-6032VSL
3-10
Item
Parts number Parts name Area
Electrical parts list (Front board)
Remarks
Block No. 02
A
R1500 NRSA63J-474X MG RESISTOR
R1501 NRSA63J-750X MG RESISTOR
FOR 6030
R1502 NRSA63J-750X MG RESISTOR
FOR 6030
R1503 NRSA63J-750X MG RESISTOR
FOR 6030
R1504 NRSA63J-750X MG RESISTOR
FOR 6030
R1505 NRSA63J-750X MG RESISTOR
FOR 6030
R1506 NRSA63J-750X MG RESISTOR
FOR 6030
R1507 NRSA63J-750X MG RESISTOR
FOR 6030
R1508 NRSA63J-473X MG RESISTOR
FOR 6030
R1509 NRSA63J-750X MG RESISTOR
FOR 6030
R1510 NRSA63J-473X MG RESISTOR
FOR 6030
R1511 NRSA63J-750X MG RESISTOR
FOR 6030
R1512 NRSA63J-473X MG RESISTOR
FOR 6030
R1513 NRSA63J-105X MG RESISTOR
FOR 6030
S 721 QSW0683-001Z PUSH SWITCH
TUNING+
S 722 QSW0683-001Z PUSH SWITCH
TUNING-
S 723 QSW0683-001Z PUSH SWITCH
PRESET+
S 724 QSW0683-001Z PUSH SWITCH
PRESET-
S 725 QSW0683-001Z PUSH SWITCH
FM MODE
S 726 QSW0683-001Z PUSH SWITCH
MEMORY
S 727 QSW0683-001Z PUSH SWITCH
POWER
S 728 QSW0683-001Z PUSH SWITCH
SURR/DSP-OFF
S 729 QSW0683-001Z PUSH SWITCH
SURR MODE
S 730 QSW0683-001Z PUSH SWITCH
DSP MODE
S 731 QSW0683-001Z PUSH SWITCH
SUBWOOFER
S 732 QSW0683-001Z PUSH SWITCH
SPK1
S 734 QSW0683-001Z PUSH SWITCH
DVD
(
5030
)
S 735 QSW0683-001Z PUSH SWITCH
CD
(
7020
)
S 736 QSW0683-001Z PUSH SWITCH
DVD
(
6030
)
S 738 QSW0683-001Z PUSH SWITCH
VCR
(
6030
)
S 739 QSW0683-001Z PUSH SWITCH
FM
(
6030
)
S 740 QSW0683-001Z PUSH SWITCH
TV/DBS
(
COM
)
S 741 QSW0683-001Z PUSH SWITCH
AM
(
6030
)
S 742 QSW0683-001Z PUSH SWITCH
ADJUST
S 743 QSW0683-001Z PUSH SWITCH
SETTING
S 744 QSW0683-001Z PUSH SWITCH
SET
S 745 QSW0683-001Z PUSH SWITCH
EXIT
S 746 QSW0683-001Z PUSH SWITCH
DIMMER
S 751 QSW0683-001Z PUSH SWITCH
DIGITAL
S 752 QSW0683-001Z PUSH SWITCH
ANALOG
S 757 QSW0683-001Z PUSH SWITCH
TAPE/CDR
(
6020
)
X 701 QAX0246-001Z C RESONATOR
