JVC RX-6032VSL Service Manual

RX-6032VSL
3-11
Item
Parts number Parts name Area
Electrical parts list (Power amp. board)
Remarks
Block No. 03
A
A
C 201 QFLC2AJ-104Z M CAPACITOR
.10MF 5% 100V
C 202 QFLC2AJ-104Z M CAPACITOR
.10MF 5% 100V
C 203 QFLC2AJ-104Z M CAPACITOR
.10MF 5% 100V
C 204 QETM1VM-228 E CAPACITOR
2200MF 20% 35V
C 205 QETM1VM-108 E CAPACITOR
1000MF 20% 35V
C 206 QFLC1HJ-473Z M CAPACITOR
.047MF 5% 50V
C 207 QFLC1HJ-473Z M CAPACITOR
.047MF 5% 50V
C 208 QFLC2AJ-472Z M CAPACITOR
4700PF 5% 100V
C 209 QETN1EM-477Z E CAPACITOR
470MF 20% 25V
C 210 QCZ9104-472 C.CAPACITOR
4700PF
C 212 QETN1CM-477Z E CAPACITOR
470MF 20% 16V
C 213 QETM0JM-228 E CAPACITOR
2200MF 20% 6.3V
C 218 QETN1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 301 QEHR1HM-106Z E CAPACITOR
10MF 20% 50V
C 302 QEHR1HM-106Z E CAPACITOR
10MF 20% 50V
C 303 QCS31HJ-271Z C CAPACITOR
270PF 5% 50V
C 304 QCS31HJ-271Z C CAPACITOR
270PF 5% 50V
C 305 QCS31HJ-221Z C CAPACITOR
220PF 5% 50V
C 306 QCS31HJ-221Z C CAPACITOR
220PF 5% 50V
C 307 QCB31HK-152Z C CAPACITOR
1500PF 10% 50V
C 308 QCB31HK-152Z C CAPACITOR
1500PF 10% 50V
C 309 QETN1EM-107Z E CAPACITOR
100MF 20% 25V
C 310 QETN1EM-107Z E CAPACITOR
100MF 20% 25V
C 311 QCS31HJ-100Z C CAPACITOR
10PF 5% 50V
C 312 QCS31HJ-100Z C CAPACITOR
10PF 5% 50V
C 313 QFLC1HJ-103Z M CAPACITOR
.010MF 5% 50V
C 314 QFLC1HJ-103Z M CAPACITOR
.010MF 5% 50V
C 315 QCS32HJ-220Z C CAPACITOR
22PF 5% 500V
C 316 QCS32HJ-220Z C CAPACITOR
22PF 5% 500V
C 317 QEHR1VM-476Z E CAPACITOR
47MF 20% 35V
C 318 QEHR1VM-476Z E CAPACITOR
47MF 20% 35V
C 319 QETN1JM-107Z E CAPACITOR
100MF 20% 63V
C 320 QETN1JM-107Z E CAPACITOR
100MF 20% 63V
C 321 QCS32HJ-470Z C CAPACITOR
47PF 5% 500V
C 322 QCS32HJ-470Z C CAPACITOR
47PF 5% 500V
C 323 QCS32HJ-470Z C CAPACITOR
47PF 5% 500V
C 324 QCS32HJ-470Z C CAPACITOR
47PF 5% 500V
C 325 QFLC1HJ-473Z M CAPACITOR
.047MF 5% 50V
C 326 QFLC1HJ-473Z M CAPACITOR
.047MF 5% 50V
C 327 QFLC1HJ-473Z M CAPACITOR
.047MF 5% 50V
C 328 QFLC1HJ-473Z M CAPACITOR
.047MF 5% 50V
C 501 QEKC1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 503 QETN0JM-477Z E CAPACITOR
470MF 20% 6.3V
C 504 QCS31HJ-470Z C CAPACITOR
47PF 5% 50V
C 505 QEKC1HM-475Z E CAPACITOR
4.7MF 20% 50V
C 506 QETN0JM-477Z E CAPACITOR
470MF 20% 6.3V
C 507 QCS31HJ-470Z C CAPACITOR
47PF 5% 50V
C 511 QETN1CM-108Z E CAPACITOR
1000MF 20% 16V
C 512 QCBB1HK-223Y C CAPACITOR
.022MF 10% 50V
C 521 QCBB1HK-221Y C CAPACITOR
220PF 10% 50V
C 522 QCZ0202-155Z ML C CAPACITOR
1.5MF
C 801 QEHR1HM-106Z E CAPACITOR
10MF 20% 50V
C 802 QEHR1HM-106Z E CAPACITOR
10MF 20% 50V
C 803 QCS31HJ-271Z C CAPACITOR
270PF 5% 50V
C 804 QCS31HJ-271Z C CAPACITOR
270PF 5% 50V
C 805 QCS31HJ-221Z C CAPACITOR
220PF 5% 50V
C 806 QCS31HJ-221Z C CAPACITOR
220PF 5% 50V
C 807 QCB31HK-152Z C CAPACITOR
1500PF 10% 50V
C 808 QCB31HK-152Z C CAPACITOR
1500PF 10% 50V
C 809 QETN1EM-107Z E CAPACITOR
100MF 20% 25V
C 810 QETN1EM-107Z E CAPACITOR
100MF 20% 25V
C 811 QCS31HJ-100Z C CAPACITOR
10PF 5% 50V
C 812 QCS31HJ-100Z C CAPACITOR
10PF 5% 50V
C 813 QFLC1HJ-103Z M CAPACITOR
.010MF 5% 50V
C 814 QFLC1HJ-103Z M CAPACITOR
.010MF 5% 50V
C 815 QCS32HJ-330Z C CAPACITOR
33PF 5% 500V
C 816 QCS32HJ-330Z C CAPACITOR
33PF 5% 500V
C 817 QEHR1HM-225Z E CAPACITOR
2.2MF 20% 50V
C 818 QEHR1HM-225Z E CAPACITOR
2.2MF 20% 50V
C 819 QEHR2AM-106Z E CAPACITOR
10MF 20% 100V
C 820 QEHR2AM-106Z E CAPACITOR
10MF 20% 100V
C 821 QCS32HJ-470Z C CAPACITOR
47PF 5% 500V
C 822 QCS32HJ-470Z C CAPACITOR
47PF 5% 500V
C 823 QCS32HJ-470Z C CAPACITOR
47PF 5% 500V
C 824 QCS32HJ-470Z C CAPACITOR
47PF 5% 500V
C 825 QFLC1HJ-473Z M CAPACITOR
.047MF 5% 50V
C 826 QFLC1HJ-473Z M CAPACITOR
.047MF 5% 50V
C 827 QFLC1HJ-473Z M CAPACITOR
.047MF 5% 50V
C 828 QFLC1HJ-473Z M CAPACITOR
.047MF 5% 50V
C 829 QETN1HM-476Z E CAPACITOR
47MF 20% 50V
C 830 QETN1HM-476Z E CAPACITOR
47MF 20% 50V
C 901 QEHR1HM-106Z E CAPACITOR
10MF 20% 50V
C 903 QCS31HJ-271Z C CAPACITOR
270PF 5% 50V
C 905 QCS31HJ-221Z C CAPACITOR
220PF 5% 50V
C 907 QCB31HK-152Z C CAPACITOR
1500PF 10% 50V
C 909 QETN1EM-107Z E CAPACITOR
100MF 20% 25V
C 911 QCS31HJ-100Z C CAPACITOR
10PF 5% 50V
C 913 QFLC1HJ-103Z M CAPACITOR
.010MF 5% 50V
C 915 QCS32HJ-330Z C CAPACITOR
33PF 5% 500V
C 917 QEHR1HM-225Z E CAPACITOR
2.2MF 20% 50V
C 919 QEHR2AM-106Z E CAPACITOR
10MF 20% 100V
C 921 QCS32HJ-470Z C CAPACITOR
47PF 5% 500V
C 923 QCS32HJ-470Z C CAPACITOR
47PF 5% 500V
C 925 QFLC1HJ-473Z M CAPACITOR
.047MF 5% 50V
C 927 QFLC1HJ-473Z M CAPACITOR
.047MF 5% 50V
C 929 QETN1HM-476Z E CAPACITOR
47MF 20% 50V
CN201 QGF1205C1-14 CONNECTOR
CN203 QGD2504C1-05Z CONNECTOR
CN241 QGD2504C1-05Z CONNECTOR
CN251 QGA3901F2-03 CONNECTOR
CN291 QGB2510J1-04 CONNECTOR
CN292 QGB2510K1-04 CONNECTOR
CN301 QGB2510K1-14 CONNECTOR
CN302 QGB2510K1-14 CONNECTOR
CN492 QGB2510K1-04 CONNECTOR
CN501 QGB2510K1-07 CONNECTOR
CN801 QGB2510K1-14 CONNECTOR
CN802 QGB2510K1-14 CONNECTOR
CN901 QGB2510K1-14 CONNECTOR
D 201 10E2-FD DIODE
A
D 202 11ES2-T4 DIODE
A
D 203 10E2-FD DIODE
A
D 204 11ES2-T4 DIODE
A
D 206 11ES2-T4 DIODE
A
D 207 11ES2-T4 DIODE
A
D 208 11ES2-T4 DIODE
A
D 209 11ES2-T4 DIODE
A
D 210 1SS133-T2 SI DIODE
D 211 MTZJ6.8C-T2 ZENER DIODE
D 212 11ES2-T4 DIODE
D 217 MTZJ6.2C-T2 ZENER DIODE
D 218 1SS133-T2 SI DIODE
D 219 11ES2-T4 DIODE
D 220 11ES2-T4 DIODE
D 221 1SS133-T2 SI DIODE
D 301 1SS133-T2 SI DIODE
D 302 1SS133-T2 SI DIODE
D 303 SLR-342MC-T LED
D 304 SLR-342MC-T LED
D 305 1SS133-T2 SI DIODE
D 306 1SS133-T2 SI DIODE
D 307 1SS133-T2 SI DIODE
Item
Parts number Parts name Area
Remarks
A
