JVC RX-6032VSL Service Manual

RX-6032VSL
3-12
Item
Parts number Parts name Area
Electrical parts list (Power amp. board)
Remarks
Block No. 03
A
D 308 1SS133-T2 SI DIODE
D 309 1SS133-T2 SI DIODE
D 310 1SS133-T2 SI DIODE
D 591 MTZJ6.2C-T2 ZENER DIODE
D 801 1SS133-T2 SI DIODE
D 802 1SS133-T2 SI DIODE
D 805 1SS133-T2 SI DIODE
D 806 1SS133-T2 SI DIODE
D 807 1SS133-T2 SI DIODE
D 808 1SS133-T2 SI DIODE
D 809 1SS133-T2 SI DIODE
D 810 1SS133-T2 SI DIODE
D 901 1SS133-T2 SI DIODE
D 905 1SS133-T2 SI DIODE
D 907 1SS133-T2 SI DIODE
D 909 1SS133-T2 SI DIODE
EP 1 E409182-001SM GRAND TERMINAL
EP201 QNZ0136-001Z EARTH PLATE
FC211 QNG0020-001Z FUSE CLIP
F201
FC212 QNG0020-001Z FUSE CLIP
F201
FC221 QNG0020-001Z FUSE CLIP
F202
FC222 QNG0020-001Z FUSE CLIP
F202
FC231 QNG0020-001Z FUSE CLIP
F203
FC232 QNG0020-001Z FUSE CLIP
F203
FW201 QUM217-14Z4Z4 PARA RIBON WIRE
FW251 QUM213-08DGZ4 PARA RIBON WIRE
IC501 NJM2246D IC
J 501 QNN0011-001 PIN JACK
M.OUT
,
DVD
J 502 QNN0011-001 PIN JACK
VCR
(
R/P
)
J 521 QNS0073-001 JACK
J 591 QNS0073-001 JACK
L 301 QQLZ005-R45 INDUCTOR
L 302 QQLZ005-R45 INDUCTOR
L 801 QQLZ005-R45 INDUCTOR
L 802 QQLZ005-R45 INDUCTOR
L 901 QQLZ005-R45 INDUCTOR
PW101 QUB112-14PPPP SIN TWIST WIRE
WITH PW311
PW102 QUB116-16PPPP PIN WIRE
WITH PW302
PW103 QUB112-34PPPP SIN TWIST WIRE
WITH PW203
PW104 QUB111-34PPPP SIN TWIST WIRE
WITH PW204
PW105 QUB116-26PPPP SIN TWIST WIRE
WITH PW205
Q
202 KRC105M-T D.TRANSISTOR
Q
203 KTC3203/OY/-T TRANSISTOR
Q
205 KTC3200/GL/-T TRANSISTOR
Q
206 KRC105M-T D.TRANSISTOR
Q
208 KRC105M-T D.TRANSISTOR
Q
209 KRC105M-T D.TRANSISTOR
Q
210 KRC105M-T D.TRANSISTOR
Q
301 2SC2240/L/-T TRANSISTOR
Q
302 2SC2240/L/-T TRANSISTOR
Q
303 2SC2240/L/-T TRANSISTOR
Q
304 2SC2240/L/-T TRANSISTOR
Q
305 KTA1268/GL/-T TRANSISTOR
Q
306 KTA1268/GL/-T TRANSISTOR
Q
307 KTC3200/GL/-T TRANSISTOR
Q
308 KTC3200/GL/-T TRANSISTOR
Q
309 2SD637/QR/ TRANSISTOR
Q
310 2SD637/QR/ TRANSISTOR
Q
311 KTC3200/GL/-T TRANSISTOR
Q
312 KTC3200/GL/-T TRANSISTOR
Q
313 KTA1268/GL/-T TRANSISTOR
Q
314 KTA1268/GL/-T TRANSISTOR
Q
315 2SD2389/OPY/-F6 TRANSISTOR
A
Q
316 2SD2389/OPY/-F6 TRANSISTOR
A
Q
317 2SB1559/OPY/-F6 TRANSISTOR
A
Q
318 2SB1559/OPY/-F6 TRANSISTOR
A
Q
319 KTA1268/GL/-T TRANSISTOR
Q
320 KTA1268/GL/-T TRANSISTOR
Q
501 KTA1267/YG/-T TRANSISTOR
Q
502 KTC3199/GL/-T TRANSISTOR
Q
503 KRC101M-T TRANSISTOR
Q
504 KTA1267/YG/-T TRANSISTOR
Q
505 KTC3199/GL/-T TRANSISTOR
Q
801 2SC2240/L/-T TRANSISTOR
Q
802 2SC2240/L/-T TRANSISTOR
Q
803 2SC2240/L/-T TRANSISTOR
Q
804 2SC2240/L/-T TRANSISTOR
Q
805 KTA1268/GL/-T TRANSISTOR
Q
806 KTA1268/GL/-T TRANSISTOR
Q
809 2SD637/QR/ TRANSISTOR
Q
810 2SD637/QR/ TRANSISTOR
Q
811 KTC3200/GL/-T TRANSISTOR
Q
812 KTC3200/GL/-T TRANSISTOR
Q
813 KTA1268/GL/-T TRANSISTOR
Q
814 KTA1268/GL/-T TRANSISTOR
Q
815 2SD2389/OPY/-F6 TRANSISTOR
A
Q
816 2SD2389/OPY/-F6 TRANSISTOR
A
Q
817 2SB1559/OPY/-F6 TRANSISTOR
A
Q
818 2SB1559/OPY/-F6 TRANSISTOR
A
Q
819 KTA1268/GL/-T TRANSISTOR
Q
820 KTA1268/GL/-T TRANSISTOR
Q
901 2SC2240/L/-T TRANSISTOR
Q
903 2SC2240/L/-T TRANSISTOR
Q
905 KTA1268/GL/-T TRANSISTOR
Q
909 2SD637/QR/ TRANSISTOR
Q
911 KTC3200/GL/-T TRANSISTOR
Q
913 KTA1268/GL/-T TRANSISTOR
Q
915 2SD2389/OPY/-F6 TRANSISTOR
A
Q
917 2SB1559/OPY/-F6 TRANSISTOR
A
Q
919 KTA1268/GL/-T TRANSISTOR
R 1 QRZ9037-335 F RESISTOR
A
3.3M 1/0W
R 201 QRJ146J-2R7X UNF C RESISTOR
A
2.7 5% 1/4W
R 203 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 204 QRJ146J-821X UNF C RESISTOR
A
820 5% 1/4W
R 208 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 209 QRE141J-104Y C RESISTOR
100K 5% 1/4W
R 210 QRJ146J-680X UNF C RESISTOR
A
68 5% 1/4W
R 221 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 301 QRE141J-222Y C RESISTOR
2.2K 5% 1/4W
R 302 QRE141J-222Y C RESISTOR
2.2K 5% 1/4W
R 303 QRE141J-563Y C RESISTOR
56K 5% 1/4W
R 304 QRE141J-563Y C RESISTOR
56K 5% 1/4W
R 305 QRE141J-123Y C RESISTOR
12K 5% 1/4W
R 306 QRE141J-123Y C RESISTOR
12K 5% 1/4W
R 307 QRE141J-272Y C RESISTOR
2.7K 5% 1/4W
R 308 QRE141J-272Y C RESISTOR
2.7K 5% 1/4W
R 309 QRE141J-101Y C RESISTOR
100 5% 1/4W
R 310 QRE141J-101Y C RESISTOR
100 5% 1/4W
R 311 QRJ146J-391X UNF C RESISTOR
390 5% 1/4W
R 312 QRJ146J-391X UNF C RESISTOR
390 5% 1/4W
R 313 QRE141J-563Y C RESISTOR
56K 5% 1/4W
R 314 QRE141J-563Y C RESISTOR
56K 5% 1/4W
R 315 QRJ146J-331X UNF C RESISTOR
A
330 5% 1/4W
R 316 QRJ146J-331X UNF C RESISTOR
A
330 5% 1/4W
R 317 QRE141J-473Y C RESISTOR
47K 5% 1/4W
R 318 QRE141J-473Y C RESISTOR
47K 5% 1/4W
R 319 QRJ146J-331X UNF C RESISTOR
330 5% 1/4W
R 320 QRJ146J-331X UNF C RESISTOR
330 5% 1/4W
R 321 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 322 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 323 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
R 324 QRJ146J-100X UNF C RESISTOR
A
10 5% 1/4W
Item
Parts number Parts name Area
Remarks
A
