JVC RX-6032VSL Service Manual

RX-6032VSL
3-18
Item
Parts number Parts name Area
Electrical parts list (Tuner board)
Remarks
Block No. 05
A
AT101 QNB0014-001 ANT TERMINAL
BK 1 LV31618-001A SHIELD BKT
C 101 NCB21HK-103X C CAPACITOR
C/M B
C 103 NCB21HK-223X C CAPACITOR
C/M B
C 105 NCB21HK-223X C CAPACITOR
C/M B
C 107 QEKC1CM-226Z E CAPACITOR
22MF 20% 16V
C 111 NCB21HK-473X C CAPACITOR
C/M B
C 112 NDC21HJ-120X C CAPACITOR
C/M B
C 121 NDC21HJ-120X C CAPACITOR
C/M B
C 122 NDC21HJ-120X C CAPACITOR
C/M B
C 123 NCB21HK-473X C CAPACITOR
C/M B
C 126 NCS21HJ-101X C CAPACITOR
C/M B
C 128 QENC1HM-474Z NP E CAPACITOR
.47MF 20% 50V
C 129 NCB21HK-102X C CAPACITOR
C/M B
C 130 QEKC1AM-107Z E CAPACITOR
100MF 20% 10V
C 133 QEKC1CM-226Z E CAPACITOR
22MF 20% 16V
C 134 NCB21HK-222X C CAPACITOR
C 135 NCB21HK-223X C CAPACITOR
C/M B
C 136 QEKC1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 137 NCB21HK-331X C CAPACITOR
C/M B
C 138 NCB21HK-473X C CAPACITOR
C/M B
C 139 NCB21HK-333X C CAPACITOR
C/M B
C 140 NCB21HK-333X C CAPACITOR
C/M B
C 141 NCB21HK-473X C CAPACITOR
C/M B
C 143 NCB21HK-223X C CAPACITOR
C/M B
C 144 NCB21HK-473X C CAPACITOR
C/M B
C 146 QEKC1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 147 QEKC1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 148 QEKC1HM-224Z E CAPACITOR
.22MF 20% 50V
C 149 QEKC1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 150 QEKC1CM-226Z E CAPACITOR
22MF 20% 16V
C 156 QDGB1HK-102Y C CAPACITOR
C/M B
C 157 NCB21HK-473X C CAPACITOR
C/M B
C 158 QEKC1CM-226Z E CAPACITOR
22MF 20% 16V
C 161 QEKC1CM-106Z E CAPACITOR
10MF 20% 16V
C 162 QEKC1CM-106Z E CAPACITOR
10MF 20% 16V
C 163 NCB21HK-223X C CAPACITOR
C/M B
C 164 NCB21HK-473X C CAPACITOR
C/M B
C 168 QEKC1HM-105Z E CAPACITOR
1.0MF 20% 50V
C 184 QEKC1CM-107Z E CAPACITOR
100MF 20% 16V
C 185 QEKC1CM-106Z E CAPACITOR
10MF 20% 16V
C 186 QEKC1CM-106Z E CAPACITOR
10MF 20% 16V
CF101 QAX0419-001Z C FILTER
CF102 QAX0604-001Z C FILTER
CF103 QAX0519-001Z C FILTER
CN111 QGB2501K2-12 CONNECTOR
D 121 1SS133-T2 SI DIODE
D 123 1SS133-T2 SI DIODE
D 124 1SS133-T2 SI DIODE
D 125 1SS133-T2 SI DIODE
D 129 1SS133-T2 SI DIODE
IC102 LA1838 IC
IC121 LC72136N IC
Q
102 2SC535/BC/-T TRANSISTOR
Q
103 2SC461/BC/-T TRANSISTOR
Q
121 KRA103M-T TRANSISTOR
FM+B
R 103 NRSA02J-221X MG RESISTOR
C/M B
R 104 NRSA02J-272X MG RESISTOR
C/M B
R 105 NRSA02J-391X MG RESISTOR
C/M B
R 106 NRSA02J-102X MG RESISTOR
C/M B
R 107 NRSA02J-391X MG RESISTOR
C/M B
R 108 NRSA02J-332X MG RESISTOR
C/M B
R 109 NRSA02J-221X MG RESISTOR
C/M B
R 115 NRSA02J-104X MG RESISTOR
C/M B
R 119 NRSA02J-103X MG RESISTOR
C/M B
R 122 NRSA02J-472X MG RESISTOR
C/M B
R 124 NRSA02J-222X MG RESISTOR
C/M B
R 126 NRSA02J-562X MG RESISTOR
C/M B
R 127 NRSA02J-822X MG RESISTOR
C/M B
R 128 NRSA02J-472X MG RESISTOR
C/M B
R 129 NRSA02J-222X MG RESISTOR
C/M B
R 130 QRZ9005-680X F RESISTOR
68 1/4W
R 132 NRSA02J-393X MG RESISTOR
C/M B
R 133 NRSA02J-392X MG RESISTOR
C/M B
R 134 NRSA02J-102X MG RESISTOR
C/M B
R 140 NRSA02J-183X MG RESISTOR
C/M B
R 141 NRSA02J-102X MG RESISTOR
C/M B
R 142 NRSA02J-470X MG RESISTOR
C/M B
R 143 NRSA02J-562X MG RESISTOR
C/M B
R 144 NRSA02J-332X MG RESISTOR
C/M B
R 145 NRSA02J-103X MG RESISTOR
C/M B
R 146 NRSA02J-392X MG RESISTOR
C/M B
R 147 NRSA02J-332X MG RESISTOR
C/M B
R 150 NRSA02J-331X MG RESISTOR
C/M B
R 157 NRSA02J-682X MG RESISTOR
C/M B
R 158 NRSA02J-682X MG RESISTOR
C/M B
R 161 NRSA02J-102X MG RESISTOR
C/M B
R 162 NRSA02J-102X MG RESISTOR
C/M B
R 182 NRSA02J-103X MG RESISTOR
R 183 NRSA02J-103X MG RESISTOR
R 184 NRSA02J-103X MG RESISTOR
RF101 QAU0124-002 FRONT END
T 111 QQR0796-001 COIL BLOCK
T 142 QQR0973-001 IFT
X 121 QAX0402-001 CRYSTAL
Item
Parts number Parts name Area
Remarks
A
