JVC RX-6032VSL User Manual

9
English
Rear panel
DVD
RX-6030VBK/RX-6032VSL
Å To surround left/right audio output
ı To center audio output
Ç To subwoofer audio output
Î To front left/right audio output
‰ To composite video output
Ï To S-video output
Ì To component video output
Å To audio output
ı To composite video output
To use software encoded with Dolby Digital or DTS Digital
Surround, connect the DVD player using one of the DIGITAL IN
terminals (see page 10).
DVD player
DVD player
RIGHT LEFT
AUDIO
DVD
IN
MONITOR
OUT
DVD
IN
OUT
(REC)
VCR
IN
(PLAY)
DVD
B
A
R
L
RX-5030VBK/RX-5032VSL
AM
LOOP
AM
EXT
ANTENNA
COAXIAL
FM 75
SUBWOOFER
OUT
DVD
IN
RIGHT LEFT
FRONT
SUB
WOOFER
CENTER
AUDIO
RIGHT
SURR
(REAR)
LEFT
VIDEO S-VIDEO
YPB PR
DVD
IN
MONITOR OUT
VCR
IN
MONITOR
OUT
DVD
IN
OUT
(REC)
VCR
IN
(PLAY)
DVD
F
G
ED
A B C
Rear panel
• To use software encoded with Dolby Digital or DTS
Digital Surround, connect the DVD player using one of
the DIGITAL IN terminals (see page 10).
• When you connect the DVD player with stereo output
jacks, connect using Î.
• When you connect the DVD player with its analog
discrete output (5.1 channel reproduction) jacks,
connect using Å to Î (see “Using DVD MULTI Playback
Mode” on page 28).
EN01-10_RX-60_5030[C]f 02.12.24, 18:409
