RX-7010RBK/RX-7012RSL
3-12
Item
Parts number Parts name Area
Electrical parts list
Remarks
Block No. 03
A
Item
Parts number Parts name Area
Remarks
A
BK701 LV42093-001A FL HOLDER(L)
BK702 LV42092-001A FL HOLDER(R)
C 451 NCB31HK-331X C CAPACITOR
C 452 NCB31HK-331X C CAPACITOR
C 453 NCB31HK-331X C CAPACITOR
C 454 NCB31HK-331X C CAPACITOR
C 455 NCB31HK-331X C CAPACITOR
C 456 NCB31HK-331X C CAPACITOR
C 459 QFLC1HJ-104Z M CAPACITOR .10MF 5% 50V
C 460 QCZ0202-155Z ML C CAPACITOR 1.5MF
C 701 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 702 QCZ0202-155Z ML C CAPACITOR 1.5MF
C 703 QETN1HM-225Z E CAPACITOR 2.2MF 20% 50V
C 704 NCB31CK-223X C CAPACITOR
C 705 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 706 NCB21HK-331X C CAPACITOR
C 707 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 708 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 709 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C 713 NCB21HK-103X C CAPACITOR
C 714 NCB21HK-103X C CAPACITOR
C 715 NCB21HK-103X C CAPACITOR
C 716 NCB21HK-103X C CAPACITOR
C 717 NCB21HK-103X C CAPACITOR
C 718 NCB21HK-103X C CAPACITOR
C 719 NCB21HK-103X C CAPACITOR
C 720 NCB31CK-104X C CAPACITOR
C 721 NCB31CK-104X C CAPACITOR
C 722 QCZ0202-155Z ML C CAPACITOR 1.5MF
C 730 NCB31CK-104X C CAPACITOR
CN402 QGF1205C1-25 CONNECTOR
CN403 QGA2001C1-04 4P PLUG ASSY
CN411 QGB2501J1-12 CONNECTOR
CN412 QGB2501J1-04 CONNECTOR
CN421 QGB2510J1-14 CONNECTOR
CN431 QGB2510J1-11 CONNECTOR
CN441 QGB2510J1-07 CONNECTOR
CN451 QGB2510K1-11 CONNECTOR
CN461 QGB2510J1-07 CONNECTOR
CN471 QGA2501C1-03 3P CONNECTOR
CN472 QGA2501C1-02 2P CONNECTOR
CN473 QGA2501C1-03 3P CONNECTOR
CN481 QGB2510J1-20 CONNECTOR
CN491 QGB2510J1-04 CONNECTOR
CN701 QGF1205F1-14 CONNECTOR
CN702 QGF1205F1-25 CONNECTOR
CN703 WJS0021-001A SIN CR C-B WIRE
CN704 WJS0020-001A SKT WIRE ASS'Y
CN714 QGA2001C1-03 3P PLUG ASSY
C1401 QETN1HM-476Z E CAPACITOR 47MF 20% 50V
C1402 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C1403 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C1404 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C1405 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C1406 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C1407 QCF31HZ-223Z C CAPACITOR .022MF +80:-20%
C1408 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C1409 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C1410 NCB31CK-223X C CAPACITOR
C1411 NCB31CK-223X C CAPACITOR
C1412 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1413 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1414 NCB31HK-101X C CAPACITOR
C1415 NCB31HK-101X C CAPACITOR
C1416 QETN1HM-474Z E CAPACITOR .47MF 20% 50V
C1417 QETN1HM-474Z E CAPACITOR .47MF 20% 50V
C1418 QFLC1HJ-223Z M CAPACITOR .022MF 5% 50V
C1419 QFLC1HJ-223Z M CAPACITOR .022MF 5% 50V
C1420 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1421 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1422 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1423 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1424 QEKC1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1425 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C1426 NCB31CK-223X C CAPACITOR
C1427 QFVF1HJ-334Z MF CAPACITOR .33MF 5% 50V
C1428 QFLC1HJ-153Z M CAPACITOR .015MF 5% 50V
C1429 QCB31HK-822Z C CAPACITOR 8200PF 10% 50V
C1430 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1431 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1432 NCB31CK-223X C CAPACITOR
C1433 QFVF1HJ-334Z MF CAPACITOR .33MF 5% 50V
C1434 QFLC1HJ-153Z M CAPACITOR .015MF 5% 50V
C1435 QCB31HK-822Z C CAPACITOR 8200PF 10% 50V
C1436 NCB31CK-223X C CAPACITOR
C1437 QCZ0202-155Z ML C CAPACITOR 1.5MF
C1438 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C1439 QFLC1HJ-562Z M CAPACITOR 5600PF 5% 50V
C1440 QFLC1HJ-562Z M CAPACITOR 5600PF 5% 50V
C1443 QCZ0202-155Z ML C CAPACITOR 1.5MF
C1444 NCB31CK-223X C CAPACITOR
C1445 NCB31CK-223X C CAPACITOR
C1446 NCB31HK-221X C CAPACITOR
C1447 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1453 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
C1459 QETN1HM-475Z E CAPACITOR 4.7MF 20% 50V
D 701 1SS355-X DIODE
D 702 1SS355-X DIODE
D 719 SLR-342VC-T LED
DI701 QLF0082-001 FL TUBE
D1401 MTZJ13C-T2 Z DIODE
D1402 MTZJ6.2C-T2 Z DIODE
D1403 MTZJ5.6C-T2 Z DIODE
D1404 MTZJ5.6C-T2 Z DIODE
D1405 MTZJ13C-T2 Z DIODE
D1406 MTZJ10C-T2 Z DIODE
D1407 MTZJ7.5C-T2 Z DIODE
D1408 MTZJ7.5C-T2 Z DIODE
D1409 1SS355-X DIODE
D1410 1SS355-X DIODE
D1411 1SS355-X DIODE
D1412 1SS355-X DIODE
D1413 1SR35-400A-T5 DIODE
EP401 QNZ0136-001Z EARTH PLATE
FL401 QQR0590-001 FILTER
FL402 QQR0590-001 FILTER
HS401 E70306-001 HEAT SINK
HS402 E70306-001 HEAT SINK
HS403 E70306-001 HEAT SINK
HS404 E70306-001 HEAT SINK
HS405 E70306-001 HEAT SINK
HS434 E70306-001 HEAT SINK
HS435 E70306-001 HEAT SINK
IC421 BA15218F-XE IC
IC422 BA15218F-XE IC
IC423 TC9162AF-X IC
(System control & Audio board)
